Isis Developer Reference
|
Process cubes using a Filter Object. More...
#include <ProcessByQuickFilter.h>
Public Member Functions | |
ProcessByQuickFilter () | |
Constructs a FilterProcess object. | |
virtual void | StartProcess (void funct(Isis::Buffer &in, Isis::Buffer &out, Isis::QuickFilter &filter)) |
This method invokes the process on a line by line basis. | |
void | ProcessCube (void funct(Isis::Buffer &in, Isis::Buffer &out, Isis::QuickFilter &filter)) |
void | SetFilterParameters (int samples, int lines, double low=-DBL_MAX, double high=DBL_MAX, int minimum=0) |
This method allows the programmer to set the filter parameters. | |
virtual void | StartProcess (void funct()) |
In the base class, this method will invoked a user-specified function exactly one time. | |
virtual void | EndProcess () |
End the processing sequence and cleans up by closing cubes, freeing memory, etc. | |
virtual void | Finalize () |
Cleans up by closing cubes and freeing memory for owned cubes. | |
virtual Isis::Cube * | SetInputCube (const QString ¶meter, const int requirements=0) |
Opens an input cube specified by the user and verifies requirements are met. | |
virtual Isis::Cube * | SetInputCube (const QString &fname, const Isis::CubeAttributeInput &att, int requirements=0) |
Opens an input cube specified by the programmer and verifies requirements are met. | |
virtual void | SetInputCube (Isis::Cube *inCube, int requirements=0) |
Set the InputCube vector to an opened Cube which was dynamically allocated. | |
virtual Isis::Cube * | SetOutputCube (const QString ¶meter) |
Allocates a user-specified output cube whose size matches the first input cube. | |
virtual Isis::Cube * | SetOutputCube (const QString ¶meter, const int nsamps, const int nlines, const int nbands=1) |
Allocates a user specified output cube whose size is specified by the programmer. | |
virtual Isis::Cube * | SetOutputCube (const QString &fname, const Isis::CubeAttributeOutput &att, const int nsamps, const int nlines, const int nbands=1) |
Allocates a output cube whose name and size is specified by the programmer. | |
virtual Isis::Cube * | SetOutputCubeStretch (const QString ¶meter, UserInterface *ui=nullptr) |
Allocates a user-specified output cube whose size matches the first input cube. | |
virtual Isis::Cube * | SetOutputCubeStretch (const QString ¶meter, const int nsamps, const int nlines, const int nbands=1, UserInterface *ui=nullptr) |
Allocates a user specified output cube whose size is specified by the programmer. | |
void | AddInputCube (Cube *cube, bool owned=true) |
void | AddOutputCube (Cube *cube, bool owned=true) |
void | CheckRequirements (const Cube *cube, const int requirements) |
Checks to make sure the input cube meets the inputted requirements. | |
void | ClearCubes () |
Close owned cubes from the list and clear the list. | |
void | ClearInputCubes () |
Close owned input cubes from the list and clear the list. | |
void | ClearOutputCubes () |
Close owned output cubes from the list and clear the list. | |
void | PropagateLabels (const bool prop) |
This method allows the programmer to turn on/off the propagation of labels from the 1st input cube to any of the output cubes. | |
void | PropagateLabels (const QString &cube) |
This method allows the programmer to propagate labels from a specific secondary cube. | |
void | PropagateTables (const bool prop) |
This method allows the programmer to propagate input tables to the output cube (default is true) | |
void | PropagateTables (const QString &fromName, const QList< QString > &tableNames=QList< QString >()) |
Propagate the tables from the cube with the given filename to the output cube. | |
void | PropagatePolygons (const bool prop) |
This method allows the programmer to propagate input blobs to the output cube (default is true) | |
void | PropagateHistory (const bool prop) |
This method allows the programmer to propagate history to the output cube (default is true) | |
void | PropagateOriginalLabel (const bool prop) |
This method allows the programmer to propagate original labels to the output cube (default is true) | |
Isis::Progress * | Progress () |
This method returns a pointer to a Progress object. | |
QString | MissionData (const QString &mission, const QString &file, bool highestVersion=false) |
This method reads the mission specific data directory from the user preference file, makes sure that mission is available in the Isis installation, and the attaches the provided input file to the directory in order to create a full file specification. | |
void | WriteHistory (Cube &cube) |
Writes out the History blob to the cube. | |
void | CalculateStatistics () |
Calculates and stores off statistics on every band of every cube added to this process via the SetInputCube method. | |
std::vector< Isis::Statistics * > | BandStatistics (const unsigned index) |
Get the vector of Statistics objects for each band separately of a specified input cube. | |
Isis::Statistics * | CubeStatistics (const unsigned index) |
Get the Statistics object for all bands of a specified input cube. | |
Protected Attributes | |
Isis::Progress * | p_progress |
Pointer to a Progress object. | |
bool | p_propagateLabels |
Flag indicating if labels are be propagated to output cubes. | |
bool | p_propagateTables |
Flag indicating if tables are be propagated to output cubes. | |
bool | p_propagatePolygons |
Flag indicating if blobs are be propagated to output cubes. | |
bool | p_propagateHistory |
Flag indicating if history is to be propagated to output cubes. | |
bool | p_propagateOriginalLabel |
Flag indicating if original lable is to be propagated to output cubes. | |
std::vector< std::vector< Isis::Statistics * > > | p_bandStats |
Holds the calculated statistics for each band separately of every input cubei after the CalculateStatistics method is called. | |
std::vector< Isis::Statistics * > | p_cubeStats |
Holds the calculated statistics for every band together of every input cubei after the CalculateStatistics method is called. | |
std::vector< Isis::Cube * > | InputCubes |
A vector of pointers to opened Cube objects. | |
std::vector< Isis::Cube * > | OutputCubes |
A vector of pointers to allocated Cube objects. | |
QSet< Isis::Cube * > * | m_ownedCubes |
A list of cubes owned by this instant. | |
Process cubes using a Filter Object.
This class processes an entire cube using an Filter object. That is, it walks a Filter object line-by-line over an input cube. This allows for the development of programs which do spatial filters such as highpass, lowpass, and sharpen. Understanding the Filter class is essential in order to utilize this class. This class expects the user to define an NxM boxcar size. Using that information, a Filter object is created and loaded with the proper cube data in order to walk the NxM boxcar through the entire cube in a very efficient manner. Currently it is required that the following parameters be available in the application XML file: LINES - Defines the height of the boxcar to convolve over the cube SAMPLES - Defines the width of the boxcar to convoled over the cube MINIMUM - Defines the minimum number of pixels in the boxcar in order for statistics to be computed (see Filter class) LOW - Defines minimum valid pixel value to be included in statistics (see Filter class) HIGH - Defines maximum valid pixel value to be included in statistics (see Filter class)
If you would like to see ProcessByQuickFilter being used in implementation, see sharpen.cpp
Isis::ProcessByQuickFilter::ProcessByQuickFilter | ( | ) |
Constructs a FilterProcess object.
References SetFilterParameters().
|
inherited |
References Isis::Process::InputCubes, and Isis::Process::m_ownedCubes.
Referenced by Isis::Process::SetInputCube(), and Isis::Process::SetInputCube().
|
inherited |
References Isis::Process::m_ownedCubes, and Isis::Process::OutputCubes.
Referenced by Isis::ProcessPolygons::AppendOutputCube(), Isis::ProcessMapMosaic::RingsSetOutputCube(), Isis::ProcessMapMosaic::RingsSetOutputCube(), Isis::Process::SetOutputCube(), Isis::ProcessMapMosaic::SetOutputCube(), Isis::ProcessMapMosaic::SetOutputCube(), and Isis::ProcessMosaic::SetOutputCube().
|
inlineinherited |
Get the vector of Statistics objects for each band separately of a specified input cube.
index | The index of the input cube in InputCubes |
References Isis::Process::p_bandStats.
|
inherited |
Calculates and stores off statistics on every band of every cube added to this process via the SetInputCube method.
The newly calculated statistics are stored in two ways: as a vector where each entry is a single Statistics object for every band of a particular input cube, and as a vector where each entry is a vector of Statistics objects, for each band separately, of a particular input cube.
References Isis::Cube::bandCount(), Isis::Progress::CheckStatus(), Isis::Buffer::DoubleBuffer(), Isis::Process::InputCubes, Isis::Cube::lineCount(), Isis::Process::p_bandStats, Isis::Process::p_cubeStats, Isis::Cube::read(), Isis::LineManager::SetLine(), Isis::Progress::SetMaximumSteps(), Isis::Progress::SetText(), Isis::Buffer::size(), and Isis::toString().
|
inherited |
Checks to make sure the input cube meets the inputted requirements.
cube | Cube to check |
requirements | Use to specify requirements for the input file. The following requirments are checked against 1) ic_base::SizeMatch checks to make sure the input cube has the same bands, samples, and lines as the first input cube open using this method, 2) ic_base::SpatialMatch checks to make sure the input cube has the same samples and lines as the first input cube, 3) ic_base::Georeferenced checks to make sure latitude/longitudes can be obtained from the input cube, 4) ic_base::FullyGeoreferenced checks to make sure latitude/longitude, phase/incidence/emission, and other geometric parameters can be obtained from the input cube, 5) ic_base::OneBand checks to make sure the input cube has exactly one band. Note, that these requirements can be logically or'ed. For example, ic_base::SpatialMatch | ic_base::georeferenced. Defaults to 0 |
Isis::iException::Message |
References _FILEINFO_, Isis::AllMatchOrOne, Isis::Cube::bandCount(), Isis::BandMatchOrOne, Isis::Cube::fileName(), Isis::Process::InputCubes, Isis::Cube::lineCount(), Isis::OneBand, Isis::Cube::sampleCount(), Isis::SizeMatch, Isis::SpatialMatch, and Isis::IException::User.
Referenced by Isis::Process::SetInputCube(), and Isis::Process::SetInputCube().
|
inherited |
Close owned cubes from the list and clear the list.
References Isis::Process::ClearInputCubes(), Isis::Process::ClearOutputCubes(), and Isis::Process::m_ownedCubes.
Referenced by Isis::Process::Finalize().
|
inherited |
Close owned input cubes from the list and clear the list.
References Isis::Process::InputCubes, and Isis::Process::m_ownedCubes.
Referenced by Isis::Process::ClearCubes(), Isis::ProcessGroundPolygons::SetStatCubes(), and Isis::ProcessMapMosaic::StartProcess().
|
inherited |
Close owned output cubes from the list and clear the list.
References Isis::Process::m_ownedCubes, and Isis::Process::OutputCubes.
Referenced by Isis::Process::ClearCubes().
|
inlineinherited |
Get the Statistics object for all bands of a specified input cube.
index | The index of the input cube in InputCubes |
References Isis::Process::p_cubeStats.
|
virtualinherited |
End the processing sequence and cleans up by closing cubes, freeing memory, etc.
Reimplemented in Isis::ProcessByBoxcar, Isis::ProcessByBrick, Isis::ProcessByTile, Isis::ProcessGroundPolygons, Isis::ProcessImportPds, Isis::ProcessMosaic, and Isis::ProcessPolygons.
References Isis::Process::Finalize().
Referenced by Isis::ProcessByBoxcar::EndProcess(), Isis::ProcessByBrick::EndProcess(), Isis::ProcessMosaic::EndProcess(), Isis::ProcessPolygons::EndProcess(), Isis::ProcessExportPds4::WritePds4(), and Isis::Process::~Process().
|
virtualinherited |
Cleans up by closing cubes and freeing memory for owned cubes.
Clears the lists for all cubes.
Reimplemented in Isis::ProcessByBoxcar, Isis::ProcessByBrick, Isis::ProcessByTile, Isis::ProcessGroundPolygons, Isis::ProcessImportPds, and Isis::ProcessPolygons.
References Isis::Process::ClearCubes().
Referenced by Isis::Process::EndProcess(), Isis::ProcessByBoxcar::Finalize(), Isis::ProcessImportPds::Finalize(), and Isis::ProcessPolygons::Finalize().
|
inherited |
This method reads the mission specific data directory from the user preference file, makes sure that mission is available in the Isis installation, and the attaches the provided input file to the directory in order to create a full file specification.
mission | Name of the mission data directory |
file | Name of the file to attach to the end of the directory |
highestVersion | If set to true the method will return the highest version number of the given file. Therefore, file must contain question marks such as "file???.dat". See the FileName class for more information on versioned files. Defaults to false. |
References _FILEINFO_, Isis::FileName::expanded(), Isis::FileName::fileExists(), Isis::FileName::highestVersion(), Isis::IException::Io, Isis::FileName::original(), and Isis::Preference::Preferences().
|
inline |
References StartProcess().
|
inlineinherited |
This method returns a pointer to a Progress object.
References Isis::Process::p_progress.
Referenced by Isis::Equalization::applyCorrection(), Isis::HiEqualization::calculateStatistics(), and Isis::ProcessMapMosaic::StartProcess().
|
inherited |
This method allows the programmer to propagate history to the output cube (default is true)
prop | Flag indicating if history is to be propagated to output cubes. |
References Isis::Process::p_propagateHistory.
|
inherited |
This method allows the programmer to turn on/off the propagation of labels from the 1st input cube to any of the output cubes.
By default, propagation occurs automatically in the Process class when a call to either of the SetOutputCube methods is invoked. If the program * requires no propagation then utilize this method. This method can be invoked between successive calls of SetOutputCube so that some cube will have labels propagated while others will not.
prop | Flag indicating if labels are be propagated to output cubes. |
References Isis::Process::p_propagateLabels.
|
inherited |
This method allows the programmer to propagate labels from a specific secondary cube.
cube | IString containing the name of the cube containing the labels to propagate. |
References Isis::PvlObject::findObject(), and Isis::Process::OutputCubes.
|
inherited |
This method allows the programmer to propagate original labels to the output cube (default is true)
prop | Flag indicating if original labels is to be propagated to output cubes. |
References Isis::Process::p_propagateOriginalLabel.
|
inherited |
This method allows the programmer to propagate input blobs to the output cube (default is true)
prop | Flag indicating if input blobs are to be propagated to output cubes. |
References Isis::Process::p_propagatePolygons.
|
inherited |
This method allows the programmer to propagate input tables to the output cube (default is true)
prop | Flag indicating if input tables are to be propagated to output cubes. |
References Isis::Process::p_propagateTables.
|
inherited |
Propagate the tables from the cube with the given filename to the output cube.
This is done at the time this method is called, not during normal processing. The names of the tables to propagate can be provided through the second paramter, by specifing a list of table names. Not providing any list (or providing an empty list) will propagate all tables.
fromName | QString of the name of the cube containing the tables to propagate. |
tableNames | List of QStrings of the names of the tables to propagate; default is empty, which indicates that all tables will be propagated. |
References Isis::Cube::close(), Isis::Cube::label(), Isis::PvlObject::object(), Isis::Cube::open(), Isis::Process::OutputCubes, and Isis::Cube::read().
void Isis::ProcessByQuickFilter::SetFilterParameters | ( | int | samples, |
int | lines, | ||
double | low = -DBL_MAX, | ||
double | high = DBL_MAX, | ||
int | minimum = 0 ) |
This method allows the programmer to set the filter parameters.
If this method is not invoked then the parameters will be obtained from the user via the XML parameters indicate in the class description.
samples | Number of samples in the boxcar. Must be odd. |
lines | Number of lines in the boxcar. Must be odd. |
low | Minimum valid pixel value to include in statistical computations of the boxcar. Defaults to -DBL_MAX |
high | Maximum valid pixel value to include in statistical computations of the boxcar. Defaults to DBL_MAX |
minimum | Minimum number of valid pixels in the sample-by-line boxcar in order for statistical computations to be valid. Defaults to 0 |
Referenced by ProcessByQuickFilter().
|
virtualinherited |
Opens an input cube specified by the programmer and verifies requirements are met.
fname | Programmer specified work file. For example, "myfile.cub". |
att | The cube attributes to use when opening the input cube. |
requirements | Requirements to check that the input cube meets. See CheckRequirements(). |
Isis::iException::Message |
Reimplemented in Isis::ProcessByBrick, Isis::ProcessByBrick, and Isis::ProcessMosaic.
References Isis::Process::AddInputCube(), Isis::Process::CheckRequirements(), Isis::Cube::open(), Isis::ReadWrite, and Isis::Cube::setVirtualBands().
|
virtualinherited |
Opens an input cube specified by the user and verifies requirements are met.
parameter | User parameter to obtain file to open. Typically, the value is "FROM". For example, the user can specify on the command line FROM=myfile.cub and this method will attempt to open the cube "myfile.cub" if the parameter was set to "FROM". |
requirements | Requirements to check that the input cube meets. See CheckRequirements(). |
Isis::iException::Message |
Reimplemented in Isis::ProcessByBrick, Isis::ProcessByLine, Isis::ProcessBySpectra, Isis::ProcessMosaic, Isis::ProcessByBrick, and Isis::ProcessBySample.
References Isis::Application::GetUserInterface(), and Isis::Process::SetInputCube().
Referenced by Isis::ProcessByLine::SetInputCube(), Isis::ProcessBySample::SetInputCube(), Isis::ProcessByBrick::SetInputCube(), Isis::ProcessMosaic::SetInputCube(), Isis::Process::SetInputCube(), Isis::ProcessByLine::SetInputCube(), Isis::ProcessMosaic::SetInputCube(), Isis::ProcessByBrick::SetInputCube(), Isis::ProcessBySample::SetInputCube(), and Isis::ProcessGroundPolygons::SetStatCubes().
|
virtualinherited |
Set the InputCube vector to an opened Cube which was dynamically allocated.
This is used if there already exists a valid opened cube
inCube | - Pointer to input Cube |
requirements | Requirements to check that the input cube meets. See CheckRequirements(). |
Reimplemented in Isis::ProcessByBrick, and Isis::ProcessMosaic.
References _FILEINFO_, Isis::Process::AddInputCube(), Isis::Process::CheckRequirements(), Isis::Cube::isOpen(), and Isis::IException::User.
|
virtualinherited |
Allocates a output cube whose name and size is specified by the programmer.
fname | Name of the output cube to allocate |
att | The cube attributes to use when creating the output cube. |
ns | Number of samples to allocate |
nl | Number of lines to allocate |
nb | Number of bands to allocate |
Isis::iException::Message |
References _FILEINFO_, Isis::PvlObject::addObject(), Isis::Process::AddOutputCube(), Isis::AttachedLabel, Isis::Cube::create(), Isis::PvlObject::findObject(), Isis::Process::InputCubes, Isis::Cube::label(), Isis::Cube::labelSize(), Isis::Process::p_propagateLabels, Isis::Process::p_propagateOriginalLabel, Isis::Process::p_propagatePolygons, Isis::Process::p_propagateTables, Isis::Cube::pixelType(), Isis::IException::Programmer, Isis::Real, Isis::Cube::setBaseMultiplier(), Isis::Cube::setByteOrder(), Isis::Cube::setDimensions(), Isis::Cube::setFormat(), Isis::Cube::setLabelsAttached(), Isis::Cube::setLabelSize(), Isis::Cube::setMinMax(), Isis::Cube::setPixelType(), Isis::SignedInteger, Isis::SignedWord, Isis::UnsignedByte, Isis::UnsignedInteger, Isis::UnsignedWord, Isis::IException::User, Isis::Cube::write(), and Isis::Process::WriteHistory().
|
virtualinherited |
Allocates a user-specified output cube whose size matches the first input cube.
parameter | User specified output file. For example, "TO" is a popular user parameter. If the user specified TO=output.cub, then this routine would allocate the file output.cub with size specified by the first opened input cube. The output pixel type will be propagated from the first loaded input cube or will use the value in the application XML file for pixelType. |
Isis::iException::Message |
Reimplemented in Isis::ProcessMapMosaic, Isis::ProcessImport, and Isis::ProcessMosaic.
References _FILEINFO_, Isis::Process::InputCubes, Isis::IException::Programmer, and Isis::Process::SetOutputCube().
Referenced by Isis::ProcessByBrick::SetOutputCube(), Isis::ProcessImport::SetOutputCube(), Isis::Process::SetOutputCube(), Isis::ProcessImport::SetOutputCube(), Isis::Process::SetOutputCube(), Isis::ProcessImport::SetOutputCube(), Isis::Process::SetOutputCubeStretch(), Isis::ProcessPolygons::SetStatCubes(), and Isis::ProcessGroundPolygons::SetStatCubes().
|
virtualinherited |
Allocates a user specified output cube whose size is specified by the programmer.
parameter | User specified output file. For example, "TO" is a popular user parameter. If the user specified TO=output.cub, then this routine would allocate the file output.cub with size specified by the first opened input cube. The output pixel type will be propagated from the first loaded input cube or will use the value in the application XML file for pixelType. |
ns | Number of samples to allocate |
nl | Number of lines to allocate |
nb | Number of bands to allocate |
Isis::iException::Message |
References _FILEINFO_, Isis::Application::GetUserInterface(), Isis::IException::Programmer, and Isis::Process::SetOutputCube().
|
virtualinherited |
Allocates a user specified output cube whose size is specified by the programmer.
parameter | User specified output file. For example, "TO" is a popular user parameter. If the user specified TO=output.cub, then this routine would allocate the file output.cub with size specified by the first opened input cube. The output pixel type will be propagated from the first loaded input cube or will use the value in the application XML file for pixelType. |
ns | Number of samples to allocate |
nl | Number of lines to allocate |
nb | Number of bands to allocate |
ui | A user interface used to get the attributes needed. If null, the user interface will be obtained from the application. |
Isis::iException::Message |
References _FILEINFO_, Isis::Application::GetUserInterface(), Isis::IException::Programmer, and Isis::Process::SetOutputCube().
|
virtualinherited |
Allocates a user-specified output cube whose size matches the first input cube.
parameter | User specified output file. For example, "TO" is a popular user parameter. If the user specified TO=output.cub, then this routine would allocate the file output.cub with size specified by the first opened input cube. The output pixel type will be propagated from the first loaded input cube or will use the value in the application XML file for pixelType. |
ui | A user interface used to get the attributes needed for SetOutputCube. |
Isis::iException::Message |
References _FILEINFO_, Isis::Process::InputCubes, Isis::IException::Programmer, and Isis::Process::SetOutputCubeStretch().
Referenced by Isis::Process::SetOutputCubeStretch().
|
inlinevirtualinherited |
In the base class, this method will invoked a user-specified function exactly one time.
In derived classes such as ProcessByLine, the StartProcess will invoke a user-specified function for every line in a cube.
funct() | Name of your processing function |
|
virtual |
This method invokes the process on a line by line basis.
funct | (Isis::Buffer &in, Isis::Buffer &out, Isis::QuickFilter &filter) Name of your processing function |
Isis::IException::Programmer |
References _FILEINFO_, Isis::QuickFilter::AddLine(), Isis::Progress::CheckStatus(), Isis::QuickFilter::HalfHeight(), Isis::Process::InputCubes, Isis::Process::OutputCubes, Isis::Process::p_progress, Isis::IException::Programmer, Isis::QuickFilter::RemoveLine(), Isis::QuickFilter::Reset(), Isis::Progress::SetMaximumSteps(), Isis::QuickFilter::SetMinimumPixels(), Isis::QuickFilter::SetMinMax(), and Isis::IException::User.
Referenced by ProcessCube().
|
inherited |
Writes out the History blob to the cube.
References Isis::History::AddEntry(), Isis::iApp, Isis::Process::InputCubes, Isis::PvlObject::object(), Isis::Process::p_propagateHistory, Isis::Cube::readHistory(), and Isis::Cube::write().
Referenced by Isis::Process::SetOutputCube(), and Isis::ProcessMapMosaic::StartProcess().
|
protectedinherited |
A vector of pointers to opened Cube objects.
The pointers are established in the SetInputCube/SetInputWorkCube methods.
Referenced by Isis::Process::AddInputCube(), Isis::Process::CalculateStatistics(), Isis::Process::CheckRequirements(), Isis::Process::ClearInputCubes(), Isis::ProcessExportPds4::CreateImageLabel(), Isis::ProcessExport::CreateWorldFile(), Isis::ProcessExportPds4::displaySettings(), Isis::ProcessExportPds::ExportTable(), Isis::ProcessExportPds4::fileAreaObservational(), Isis::ProcessExportPds::FixedJP2ImageRoot(), Isis::ProcessExport::GetBuffersBIL(), Isis::ProcessExport::GetBuffersBIP(), Isis::ProcessExport::GetBuffersBSQ(), Isis::ProcessExportPds4::identificationArea(), Isis::ProcessExportPds::LineBytes(), Isis::ProcessExportPds::OutputLabel(), Isis::ProcessByBrick::ProcessCube(), Isis::ProcessExport::ProcessCubes(), Isis::ProcessByBrick::ProcessCubes(), Isis::ProcessRubberSheet::processPatchTransform(), Isis::ProcessByLine::SetBricks(), Isis::ProcessByBrick::SetInputBrickSize(), Isis::ProcessByBrick::SetInputBrickSize(), Isis::ProcessMosaic::SetInputCube(), Isis::ProcessMosaic::SetInputCube(), Isis::ProcessExport::SetInputRange(), Isis::ProcessExport::SetInputRange(), Isis::ProcessExport::SetInputRange(), Isis::ProcessByBrick::SetOutputCube(), Isis::Process::SetOutputCube(), Isis::Process::SetOutputCube(), Isis::Process::SetOutputCubeStretch(), Isis::ProcessGroundPolygons::SetStatCubes(), Isis::ProcessExportPds4::StandardAllMapping(), Isis::ProcessExportPds::StandardAllMapping(), Isis::ProcessExportPds4::standardBandBin(), Isis::ProcessExportPds::StandardImageImage(), Isis::ProcessExportPds4::standardInstrument(), Isis::ProcessExportPds::StandardJP2Image(), Isis::ProcessMosaic::StartProcess(), Isis::ProcessMapMosaic::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessExport::StartProcess(), Isis::ProcessRubberSheet::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessExport::StartProcess(), Isis::ProcessByBoxcar::StartProcess(), StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessExportPds::StreamJP2ImageRoot(), Isis::ProcessByBrick::VerifyCubes(), and Isis::Process::WriteHistory().
|
protectedinherited |
A list of cubes owned by this instant.
These cubes will be deleted on finalization. Process will not take ownership of cubes allocated outside of Process. It is the caller's responsibility to delete such cubes.
Referenced by Isis::Process::AddInputCube(), Isis::Process::AddOutputCube(), Isis::Process::ClearCubes(), Isis::Process::ClearInputCubes(), Isis::Process::ClearOutputCubes(), Isis::Process::Process(), and Isis::Process::~Process().
|
protectedinherited |
A vector of pointers to allocated Cube objects.
The pointers are established in the SetOutputCube method.
Referenced by Isis::Process::AddOutputCube(), Isis::Process::ClearOutputCubes(), Isis::ProcessImportPds::Finalize(), Isis::ProcessImport::ProcessBil(), Isis::ProcessImport::ProcessBip(), Isis::ProcessImport::ProcessBsq(), Isis::ProcessByBrick::ProcessCube(), Isis::ProcessByBrick::ProcessCubes(), Isis::ProcessImport::ProcessJp2(), Isis::ProcessRubberSheet::processPatchTransform(), Isis::Process::PropagateLabels(), Isis::Process::PropagateTables(), Isis::ProcessMapMosaic::RingsSetOutputCube(), Isis::ProcessByLine::SetBricks(), Isis::ProcessByBrick::SetOutputBrickSize(), Isis::ProcessByBrick::SetOutputBrickSize(), Isis::ProcessMapMosaic::SetOutputCube(), Isis::ProcessMosaic::SetOutputCube(), Isis::ProcessPolygons::SetStatCubes(), Isis::ProcessGroundPolygons::SetStatCubes(), Isis::ProcessGroundPolygons::SetStatCubes(), Isis::ProcessImportPds::StartProcess(), Isis::ProcessMosaic::StartProcess(), Isis::ProcessMapMosaic::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessRubberSheet::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessByBoxcar::StartProcess(), StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessImportPds::TranslatePdsProjection(), and Isis::ProcessByBrick::VerifyCubes().
|
protectedinherited |
Holds the calculated statistics for each band separately of every input cubei after the CalculateStatistics method is called.
Referenced by Isis::Process::BandStatistics(), and Isis::Process::CalculateStatistics().
|
protectedinherited |
Holds the calculated statistics for every band together of every input cubei after the CalculateStatistics method is called.
Referenced by Isis::Process::CalculateStatistics(), and Isis::Process::CubeStatistics().
|
protectedinherited |
Pointer to a Progress object.
Referenced by Isis::Process::Process(), Isis::ProcessImport::ProcessBil(), Isis::ProcessImport::ProcessBip(), Isis::ProcessImport::ProcessBsq(), Isis::ProcessExport::ProcessCubes(), Isis::ProcessExport::ProcessExport(), Isis::ProcessImport::ProcessImport(), Isis::ProcessImport::ProcessJp2(), Isis::ProcessRubberSheet::processPatchTransform(), Isis::Process::Progress(), Isis::ProcessMosaic::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessExport::StartProcess(), Isis::ProcessRubberSheet::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessByBrick::StartProcess(), Isis::ProcessExport::StartProcess(), Isis::ProcessByBoxcar::StartProcess(), StartProcess(), Isis::ProcessByBrick::StartProcess(), and Isis::Process::~Process().
|
protectedinherited |
Flag indicating if history is to be propagated to output cubes.
Referenced by Isis::Process::Process(), Isis::Process::PropagateHistory(), Isis::ProcessMapMosaic::StartProcess(), and Isis::Process::WriteHistory().
|
protectedinherited |
Flag indicating if labels are be propagated to output cubes.
Referenced by Isis::Process::Process(), Isis::Process::PropagateLabels(), and Isis::Process::SetOutputCube().
|
protectedinherited |
Flag indicating if original lable is to be propagated to output cubes.
Referenced by Isis::Process::Process(), Isis::Process::PropagateOriginalLabel(), and Isis::Process::SetOutputCube().
|
protectedinherited |
Flag indicating if blobs are be propagated to output cubes.
Referenced by Isis::Process::Process(), Isis::Process::PropagatePolygons(), and Isis::Process::SetOutputCube().
|
protectedinherited |
Flag indicating if tables are be propagated to output cubes.
Referenced by Isis::Process::Process(), Isis::Process::PropagateTables(), and Isis::Process::SetOutputCube().
