ISIS Documentation

eisstitch

Combine Clipper EIS files into a single ISIS cube

This program takes a series of Clipper EIS cubes and combines them into a single unified cube with a unified ephemeris time table as well as a unified camera.

The program requires that the list of cubes provided be Clipper EIS cubes and that the cubes are in chronological order.

Categories

History

Adam Paquette2024-08-12 Original version.

Parameters

Files

The name of a file containing a list of Clipper EIS images in chronological order to be stitched together.
Type filename
File Mode input
Filter *

The output cube file that will contain the EIS stitched image in ISIS format.
Type cube
File Mode output
Filter *.cub

Example 1

Demonstrats how to use eisstitch

This example demonstrates the basic workings of eisstitch and how to properly format the input information for stitching.

Command Line

This is the command line used to create the stitched output cube. The FROMLIST needs to be a newline delimited list of EIS Clipper cubes to stitch together.
eisstitch fromlist=eis_cubes.lis to=eis_stitched_cube.cub

Input Images

First capture to be stitched

First chronological capture from an EIS image set

First capture to be stitched

This is the first image in a series of images taken by the EIS Clipper WAC/NAC camera.

Second capture to be stitched

Second chronological capture from an EIS image set

Second capture to be stitched

This is the second image in a series of images taken by the EIS Clipper WAC/NAC camera.

Third capture to be stitched

Third chronological capture from an EIS image set

Third capture to be stitched

This is the third image in a series of images taken by the EIS Clipper WAC/NAC camera.

Data File

Links open in a new window.
FROMLIST Input list file of cubes, where each line is the full path or relative path for each cube to stitch

Output Image

Output of eisstitch

Output image for eisstitch

Output of eisstitch

Parameter Name: TO

The sitched output from the three images above
