trimfilter
Apply a trim filter to a cube
This program convolves an NxM boxcar through a cube and trims (or NULLs)
pixels. A pixel at the center of the boxcar is trimmed in the output cube
if the number of valid pixels inside the boxcar is less than a user
specified minimum. Valid pixels are defined as those which are 1) not
special pixels and 2) inside the range of the LOW and HIGH parameters.
This is a very powerful trimming tool although much
thought must be put into the parameters in order to obtain the optimal
trimming results.
Categories
Related Applications to Previous Versions of ISIS
This program replaces the following application existing in previous versions of ISIS:- boxfilter
Related Objects and Documents
Applications
History
| Eric Eliason | 1988-05-20 | Original version |
| Jeff Anderson | 2002-08-01 | Ported to Isis 3.0 |
| K Teal Thompson | 2002-12-03 | Add example |
| K Teal Thompson | 2003-03-28 | Make images smaller. |
| Stuart Sides | 2003-04-04 | Fixed problem with isiscvs not checking in the thumb and image directories. |
| Kim Sides | 2003-05-13 | Added application test |
| Stuart Sides | 2003-05-16 | Modified schema location from astogeology... to isis.astrogeology..." |
| Stuart Sides | 2003-07-29 | Modified filename parameters to be cube parameters where necessary |
| Brendan George | 2006-03-20 | Added Minopt parameter |
