Isis 3.0 Programmer Reference
Home
Public Types | Public Slots | Signals | Public Member Functions | Private Slots | Private Member Functions | Private Attributes | Static Private Attributes | List of all members
Isis::CnetEditorWidget Class Reference

This widget provides full editing, filtering and viewing capabilities for the raw data in a control network. More...

#include <CnetEditorWidget.h>

Inheritance diagram for Isis::CnetEditorWidget:
Inheritance graph
Collaboration diagram for Isis::CnetEditorWidget:
Collaboration graph

Public Types

enum  View { PointView, ImageView, ConnectionView }


Public Slots

void configSorting ()

void setTablesFrozen (bool)


Signals

void cnetModified ()


Public Member Functions

 CnetEditorWidget (ControlNet *, QString)

void readSettings ()

void writeSettings ()

QWidget * pointTreeView ()

QWidget * serialTreeView ()

QWidget * connectionTreeView ()

QWidget * pointFilterWidget ()

QWidget * serialFilterWidget ()

QWidget * connectionFilterWidget ()

CnetViz::AbstractTableModel * measureTableModel ()

CnetViz::AbstractTableModel * pointTableModel ()

QMap< QAction *, QList< QString > > menuActions ()

QMap< QString, QList< QAction * > > toolBarActions ()

ControlNet * filteredNetwork () const

bool measureTableSortingEnabled () const

int measureTableSortLimit () const

bool pointTableSortingEnabled () const

int pointTableSortLimit () const

void setMeasureTableSortingEnabled (bool enabled)

void setMeasureTableSortLimit (int limit)

void setPointTableSortingEnabled (bool enabled)

void setPointTableSortLimit (int limit)


Private Slots

void rebuildModels ()

void rebuildModels (QList< CnetViz::AbstractTreeItem * > itemsToDelete)

void pointColToggled ()

void measureColToggled ()

void handlePointTableFilterCountsChanged (int visibleRows, int totalRows)

void handleMeasureTableFilterCountsChanged (int visibleRows, int totalRows)


Private Member Functions

void nullify ()

QBoxLayout * createMainLayout ()

void createActions ()

void createPointTreeView ()

void createSerialTreeView ()

void createConnectionTreeView ()

void createFilterArea ()

void createPointTableView ()

void createMeasureTableView ()

void upgradeVersion ()

void handleTableFilterCountsChanged (int visibleRows, int totalRows, QGroupBox *box, QString initialText)


Private Attributes

bool m_updatingSelection

ControlNet * m_controlNet

QString * m_workingVersion

CnetViz::TreeView * m_pointTreeView

CnetViz::TreeView * m_imageTreeView

CnetViz::TreeView * m_connectionTreeView

CnetViz::TableView * m_pointTableView

CnetViz::TableView * m_measureTableView

QGroupBox * m_pointTableBox

QGroupBox * m_measureTableBox

QScrollArea * m_filterArea

QWidget * m_pointFilterWidget

QWidget * m_serialFilterWidget

QWidget * m_connectionFilterWidget

CnetViz::PointMeasureTreeModel * m_pointModel

CnetViz::ImagePointTreeModel * m_imageModel

CnetViz::ImageImageTreeModel * m_connectionModel

CnetViz::PointTableModel * m_pointTableModel

CnetViz::MeasureTableModel * m_measureTableModel

QSplitter * m_mainSplitter

QMap< QAction *, QList
< QString > > * 		m_menuActions

QMap< QString, QList< QAction * > > * m_toolBarActions

QString * m_settingsPath


Static Private Attributes

static const QString VERSION = "0.1"


Detailed Description

This widget provides full editing, filtering and viewing capabilities for the raw data in a control network.

The raw data is, for example, chooser name or cube serial number. The display is all textual. Please use the widget accessors to appropriately place the various ancillary sections of the editor.

Author
????-??-?? Eric Hyer
History:
2015-10-07 Ian Humphrey - Icons updated and no longer embedded (in order to not violate licensing terms). Fixes #1041.

Definition at line 46 of file CnetEditorWidget.h.

The documentation for this class was generated from the following files:
