Child class for XmlStackedHandler which is used to process XML in a stack-oriented way. More...

Inheritance diagram for Isis::Image::XmlHandler:

Collaboration diagram for Isis::Image::XmlHandler:

Public Member Functions
	XmlHandler (Image *image, FileName imageFolder)
	Create an XML Handler (reader) that can populate the Image class data. More...

virtual bool	startElement (const QString &namespaceURI, const QString &localName, const QString &qName, const QXmlAttributes &atts)
	The XML reader invokes this method at the start of every element in the XML document. More...

virtual bool	characters (const QString &ch)
	This implementation of a virtual function calls QXmlDefaultHandler::characters(QString &ch) which in turn calls QXmlContentHandler::characters(QString &ch) which is called when the XML processor has parsed a chunk of character data. More...

virtual bool	endElement (const QString &namespaceURI, const QString &localName, const QString &qName)
	The XML reader invokes this method at the end of every element in the XML document. More...

virtual void	setReader (XmlStackedHandlerReader *)

void	switchToNewHandler (XmlStackedHandler *nextHandler)

Protected Member Functions
XmlStackedHandlerReader *	reader ()

const XmlStackedHandlerReader *	reader () const

bool	fatalError (const QXmlParseException &exception)

Private Member Functions
	Q_DISABLE_COPY (XmlHandler)

Private Attributes
Image *	m_image
	Pointer to the Image. More...

FileName	m_imageFolder
	The Name/path of the image. More...

QString	m_characters
	Character data storage found in the content of XML elements. More...

Detailed Description

Child class for XmlStackedHandler which is used to process XML in a stack-oriented way.

It's been modified to process an Image object object.

Author: 2012-??-?? Steven Lambright

History:: 2016-06-23 Tyler Wilson - Added documention to the member functions. Fixes #3950.

Definition at line 151 of file Image.h.

Constructor & Destructor Documentation

Isis::Image::XmlHandler::XmlHandler	(	Image *	image,
		FileName	imageFolder
	)

Create an XML Handler (reader) that can populate the Image class data.

See Also: Image::save() for the expected format.

Parameters

image	The image we're going to be initializing
imageFolder	The folder that contains the Cube

Definition at line 763 of file Image.cpp.

References m_image, and m_imageFolder.

Member Function Documentation

bool Isis::Image::XmlHandler::characters ( const QString & ch )

virtual

This implementation of a virtual function calls QXmlDefaultHandler::characters(QString &ch) which in turn calls QXmlContentHandler::characters(QString &ch) which is called when the XML processor has parsed a chunk of character data.

See Also: XmlStackedHandler, QXmlDefaultHandler,QXmlContentHandler

Parameters

ch	The character data.

Returns: bool Returns True if there were no problems with the character processing. It returns False if there was a problem, and the XML reader stops.

Definition at line 877 of file Image.cpp.

bool Isis::Image::XmlHandler::endElement	(	const QString &	namespaceURI,
		const QString &	localName,
		const QString &	qName
	)

virtual

The XML reader invokes this method at the end of every element in the XML document.

This expects <image> and <footprint> elements.

Parameters

namespaceURI	The Uniform Resource Identifier of the namespace (eg. "xmlns")
localName	The local name string (eg. "xhtml")
qName	The XML qualified string (eg. "xmlns:xhtml"). This can be empty if QNames are not available.

Returns: bool If this function returns True, then a signal is sent to the reader indicating the end of the element. If this function returns False, something bad happened and processing stops.

Reimplemented from Isis::XmlStackedHandler.

Definition at line 895 of file Image.cpp.

References Isis::PolygonTools::MakeMultiPolygon().

bool Isis::Image::XmlHandler::startElement	(	const QString &	namespaceURI,
		const QString &	localName,
		const QString &	qName,
		const QXmlAttributes &	atts
	)

virtual

The XML reader invokes this method at the start of every element in the XML document.

This expects <image> and <displayProperties> elements. A quick example using this function: startElement("xsl","stylesheet","xsl:stylesheet",attributes)

Parameters

namespaceURI	The Uniform Resource Identifier of the element's namespace
localName	The local name string
qName	The XML qualified string (or empty, if QNames are not available).
atts	The XML attributes attached to each element

Returns: bool Returns True signalling to the reader the start of a valid XML element. If False is returned, something bad happened.

Reimplemented from Isis::XmlStackedHandler.

Definition at line 783 of file Image.cpp.

References Isis::Image::fileName(), Isis::Distance::Meters, and Isis::Angle::Radians.

Member Data Documentation

QString Isis::Image::XmlHandler::m_characters

private

Character data storage found in the content of XML elements.

Definition at line 166 of file Image.h.

Image* Isis::Image::XmlHandler::m_image

private

Pointer to the Image.

Definition at line 164 of file Image.h.

Referenced by XmlHandler().

FileName Isis::Image::XmlHandler::m_imageFolder

private

The Name/path of the image.

Definition at line 165 of file Image.h.

Referenced by XmlHandler().

The documentation for this class was generated from the following files:

src/qisis/objs/Image/Image.h
src/qisis/objs/Image/Image.cpp
