Isis::PFPixelMapper Class Reference

#include <ProjectionFactory.h>

Inheritance diagram for Isis::PFPixelMapper:

Collaboration diagram for Isis::PFPixelMapper:

Public Member Functions
	PFPixelMapper (double pixelResolution, double upperLeftX, double upperLeftY)
	Constructs a PFFixelMapper object with the given pixel resolution and location. More...
double	WorldX (const double projX) const
	Returns the world x position for the given x projection value. More...
double	WorldY (const double projY) const
	Returns the world y position for the given y projection value. More...
double	ProjectionX (const double sample) const
	Returns the x projection of the given sample. More...
double	ProjectionY (const double line) const
	Returns the y projection of the given line. More...
double	Resolution () const
	Returns the pixel resolution. More...

Private Attributes
double	p_pixelResolution
double	p_upperLeftX
double	p_upperLeftY

Detailed Description

Author

????-??-?? Unknown

Definition at line 131 of file ProjectionFactory.h.

Constructor & Destructor Documentation

Isis::PFPixelMapper::PFPixelMapper ( double  pixelResolution, double  upperLeftX, double  upperLeftY  )

inline

Constructs a PFFixelMapper object with the given pixel resolution and location.

Parameters

pixelResolution	The pixel resolution
upperLeftX	The x value for the upper left corner
upperLeftY	The y value for the upper left corner

Definition at line 140 of file ProjectionFactory.h.

Member Function Documentation

double Isis::PFPixelMapper::ProjectionX ( const double  sample ) const

inlinevirtual

Returns the x projection of the given sample.

Parameters

sample

The sample to get the x projection value for

Returns

double The x projection value

Implements Isis::WorldMapper.

Definition at line 172 of file ProjectionFactory.h.

double Isis::PFPixelMapper::ProjectionY ( const double  line ) const

inlinevirtual

Returns the y projection of the given line.

Parameters

line	The line to get the y projection value for

Returns

double The y projection value

Implements Isis::WorldMapper.

Definition at line 182 of file ProjectionFactory.h.

double Isis::PFPixelMapper::Resolution ( ) const

inlinevirtual

Returns the pixel resolution.

Reimplemented from Isis::WorldMapper.

Definition at line 187 of file ProjectionFactory.h.

double Isis::PFPixelMapper::WorldX ( const double  projX ) const

inlinevirtual

Returns the world x position for the given x projection value.

Parameters

projX

The x projection value to get the world x position for

Returns

double The world x position

Implements Isis::WorldMapper.

Definition at line 152 of file ProjectionFactory.h.

double Isis::PFPixelMapper::WorldY ( const double  projY ) const

inlinevirtual

Returns the world y position for the given y projection value.

Parameters

projY

The y projection value to get the world y position for

Returns

double The world y position

Implements Isis::WorldMapper.

Definition at line 162 of file ProjectionFactory.h.

---

The documentation for this class was generated from the following file:

• src/base/objs/ProjectionFactory/ProjectionFactory.h
