Isis::Parabola Class Reference

Parabola basis function. More...

#include <Parabola.h>

Inheritance diagram for Isis::Parabola:

Collaboration diagram for Isis::Parabola:

Public Member Functions
	Parabola (const QString &bname="Parabola")
	Create a Parabola object. More...
	~Parabola ()
	Destroys the Parabola object. More...
void	Expand (const std::vector< double > &vars)
	This is the the overriding virtual function that provides the expansion into the parabolic equation. More...
void	SetCoefficients (const std::vector< double > &coefs)
	Set the coefficients for the equation. More...
double	Evaluate (const std::vector< double > &vars)
	Compute the equation using the input variables. More...
double	Evaluate (const double &var)
	Compute the equation using the input variable. More...
int	Coefficients () const
	Returns the number of coefficients for the equation. More...
int	Variables () const
	Returns the number of variables in the equation. More...
QString	Name () const
	Returns the name of the equation. More...
double	Term (int c) const
	Returns the cth term. More...
double	Coefficient (int i) const
	Returns the ith coefficient. More...

Protected Attributes
QString	p_name
	The name of the equation. Call it by using Name() More...
int	p_numVars
	The number of variables in the equation. Call it by using Variables() More...
int	p_numCoefs
	The number of coefficients in the equation. More...
std::vector< double >	p_coefs
	A vector of the coefficients in the equation. More...
std::vector< double >	p_terms
	A vector of the terms in the equation. More...

Detailed Description

Parabola basis function.

This is a derived class from the BasisFunction class which creates a parabola (second degree equation in 1 variable). The parabolic function has the following form:

Author

2005-06-09 Kris Becker

History:

2006-04-15 Debbie A. Cook - Imported from ISIS2 to Isis 3

Definition at line 50 of file Parabola.h.

Constructor & Destructor Documentation

Isis::Parabola::Parabola ( const QString &  bname = "Parabola" )

inline

Create a Parabola object.

Definition at line 56 of file Parabola.h.

Isis::Parabola::~Parabola ( )

inline

Destroys the Parabola object.

Definition at line 60 of file Parabola.h.

Member Function Documentation

double Isis::BasisFunction::Coefficient ( int  i ) const

inlineinherited

Returns the ith coefficient.

Parameters

i	The index for the desired coefficient.

Returns

The ith coefficient

Definition at line 123 of file BasisFunction.h.

References Isis::BasisFunction::p_coefs.

Referenced by Isis::PolynomialUnivariate::DerivativeVar(), Isis::SpicePosition::LoadHermiteCache(), Isis::SurfaceModel::MinMax(), Isis::SpicePosition::SetPolynomial(), Isis::SpiceRotation::SetPolynomial(), and Isis::Affine::Solve().

int Isis::BasisFunction::Coefficients ( ) const

inlineinherited

Returns the number of coefficients for the equation.

Returns

The number of coefficients.

Definition at line 80 of file BasisFunction.h.

References Isis::BasisFunction::p_numCoefs.

Referenced by Isis::PolynomialUnivariate::DerivativeCoef(), Isis::PolynomialUnivariate::DerivativeVar(), Isis::SpicePosition::SetPolynomial(), Isis::SpiceRotation::SetPolynomial(), Isis::LeastSquares::SolveQRD(), and Isis::LeastSquares::SolveSVD().

double Isis::BasisFunction::Evaluate ( const std::vector< double > &  vars )

inherited

Compute the equation using the input variables.

Parameters

vars	A vector of double values to use for the equation. After setting the coefficients, this can be invoked many times to compute output values given input values.

Returns

The output value.

Definition at line 80 of file BasisFunction.cpp.

References _FILEINFO_, Isis::BasisFunction::Expand(), Isis::BasisFunction::p_coefs, Isis::BasisFunction::p_numCoefs, Isis::BasisFunction::p_numVars, Isis::BasisFunction::p_terms, Isis::IException::Programmer, and Isis::toString().

Referenced by Isis::BasisFunction::Evaluate(), Isis::LeastSquares::Evaluate(), Isis::SpiceRotation::EvaluatePolyFunction(), Isis::SpicePosition::LoadHermiteCache(), Isis::SpicePosition::SetEphemerisTimePolyFunction(), Isis::SpiceRotation::setEphemerisTimePolyFunction(), Isis::LeastSquares::SolveQRD(), and Isis::LeastSquares::SolveSVD().

double Isis::BasisFunction::Evaluate ( const double &  var )

inherited

Compute the equation using the input variable.

Parameters

var	A single double value to use for the equation.

Returns

The output double value resulting from the equation.

Definition at line 117 of file BasisFunction.cpp.

References Isis::BasisFunction::Evaluate().

void Isis::Parabola::Expand ( const std::vector< double > &  vars )

virtual

This is the the overriding virtual function that provides the expansion into the parabolic equation.

See BasisFunction for more information.

Parameters

vars	A vector of double values to use for the expansion.

Reimplemented from Isis::BasisFunction.

Definition at line 39 of file Parabola.cpp.

References Isis::BasisFunction::p_terms, and Isis::BasisFunction::Variables().

QString Isis::BasisFunction::Name ( ) const

inlineinherited

Returns the name of the equation.

Returns

The name of the equation.

Definition at line 96 of file BasisFunction.h.

References Isis::BasisFunction::p_name.

Referenced by Isis::LeastSquares::AddKnown().

void Isis::BasisFunction::SetCoefficients ( const std::vector< double > &  coefs )

inherited

Set the coefficients for the equation.

Parameters

coefs

A vector of coefficients for the equation.

Definition at line 58 of file BasisFunction.cpp.

References _FILEINFO_, Isis::BasisFunction::p_coefs, Isis::BasisFunction::p_numCoefs, Isis::IException::Programmer, and Isis::toString().

Referenced by Isis::SpiceRotation::DCJdt(), Isis::SpiceRotation::EvaluatePolyFunction(), Isis::SpicePosition::LoadHermiteCache(), Isis::SpicePosition::SetEphemerisTimePolyFunction(), Isis::SpiceRotation::setEphemerisTimePolyFunction(), Isis::SpicePosition::SetPolynomial(), Isis::SpiceRotation::SetPolynomial(), Isis::LeastSquares::SolveQRD(), Isis::LeastSquares::SolveSparse(), and Isis::LeastSquares::SolveSVD().

double Isis::BasisFunction::Term ( int  c ) const

inlineinherited

Returns the cth term.

This is only valid after a Evalute/Expand has been invoked. It represents the expansion of the variables into the ith term. For example,

would return x*y for the 3rd term (zero-based)

Parameters

c	The index for the desired coefficient.

Returns

The cth term.

Definition at line 113 of file BasisFunction.h.

References Isis::BasisFunction::p_terms.

Referenced by Isis::LeastSquares::FillSparseA(), Isis::LeastSquares::SolveQRD(), and Isis::LeastSquares::SolveSVD().

int Isis::BasisFunction::Variables ( ) const

inlineinherited

Returns the number of variables in the equation.

Returns

The number of variables.

Definition at line 88 of file BasisFunction.h.

References Isis::BasisFunction::p_numVars.

Referenced by Isis::LeastSquares::AddKnown(), and Expand().

Member Data Documentation

std::vector<double> Isis::BasisFunction::p_coefs

protectedinherited

A vector of the coefficients in the equation.

Call it by using Coefficient()

Definition at line 139 of file BasisFunction.h.

Referenced by Isis::BasisFunction::Coefficient(), Isis::BasisFunction::Evaluate(), and Isis::BasisFunction::SetCoefficients().

QString Isis::BasisFunction::p_name

protectedinherited

The name of the equation. Call it by using Name()

Definition at line 125 of file BasisFunction.h.

Referenced by Isis::BasisFunction::BasisFunction(), and Isis::BasisFunction::Name().

int Isis::BasisFunction::p_numCoefs

protectedinherited

The number of coefficients in the equation.

Call it by using Coefficients()

Definition at line 135 of file BasisFunction.h.

Referenced by Isis::BasisFunction::BasisFunction(), Isis::BasisFunction::Coefficients(), Isis::BasisFunction::Evaluate(), and Isis::BasisFunction::SetCoefficients().

int Isis::BasisFunction::p_numVars

protectedinherited

The number of variables in the equation. Call it by using Variables()

Definition at line 131 of file BasisFunction.h.

Referenced by Isis::BasisFunction::BasisFunction(), Isis::BasisFunction::Evaluate(), and Isis::BasisFunction::Variables().

std::vector<double> Isis::BasisFunction::p_terms

protectedinherited

A vector of the terms in the equation.

Call it by using Term()

Definition at line 143 of file BasisFunction.h.

Referenced by Isis::BasisFunction::Evaluate(), Isis::PolynomialUnivariate::Expand(), Isis::PolynomialBivariate::Expand(), Expand(), Isis::BasisFunction::Expand(), and Isis::BasisFunction::Term().

---

The documentation for this class was generated from the following files:

• src/base/objs/Parabola/Parabola.h
• src/base/objs/Parabola/Parabola.cpp
