Pepper noise Clean-up of Viking Orbiter Level 1 images
| Overview | Parameters | Example 1 |
Description
This program will perform the middle portion of the level 1 processing sequence on a Viking
Orbiter PDS image, the cleanup of pepper noise in the image.
CategoriesRelated Objects and DocumentsApplicationsHistory
|
| U.S. Department of the Interior | U.S. Geological Survey ISIS | Privacy & Disclaimers | Astrogeology Research Program To contact us, please post comments and questions on the USGS Astrogeology Discussion Board To report a bug, or suggest a feature go to: ISIS Github File Modified: 07/13/2023 15:39:45 |
Parameter GroupsFiles
Option
|
| U.S. Department of the Interior | U.S. Geological Survey ISIS | Privacy & Disclaimers | Astrogeology Research Program To contact us, please post comments and questions on the USGS Astrogeology Discussion Board To report a bug, or suggest a feature go to: ISIS Github File Modified: 07/13/2023 15:39:45 |
Files: FROM
Description
The cube to be cleaned. The cube will be ran through a series of filters to remove pepper noise.
| Type | cube |
|---|---|
| File Mode | input |
| Filter | *.cub |
Files: TO
Description
The resultant cube containing the cleaned data.
| Type | cube |
|---|---|
| File Mode | output |
| Filter | *.cub |
Option: REMOVE
Description
Option to remove or leave intermediate cube files made by the application
| Type | boolean |
|---|---|
| Default | TRUE |
Example 1Input Viking Image to have pepper noise removed Description
This example shows the viknopepper application in action. It removes all pepper noise.
Command Line
viknopepper from=../IN/temp.cub to=OUT/out.cub
Input a viking image to remove the pepper noise from and give it an output file name.
Input Image
Output Image
|
![Input Viking Image](javascript:popUpNewWindow ("assets/image/inputImage.jpg",584, 512))
![Output Viking Image after running the viknopepper application.](javascript:popUpNewWindow ("assets/image/outputImage.jpg",584, 512))
