Isis::MosaicControlNetToolMovementConfigDialog Class Reference

Configure qmos Control Net Tool's movement arrows. More...

#include <MosaicControlNetToolMovementConfigDialog.h>

Inheritance diagram for Isis::MosaicControlNetToolMovementConfigDialog:

Collaboration diagram for Isis::MosaicControlNetToolMovementConfigDialog:

Public Slots
void	applySettings ()
	Apply the user's current settings to the tool. More...
void	readSettings ()
	Read the tool's current settings and set the widget states to match. More...
void	refreshWidgetStates ()
	Enables or disables widgets depending on the state of the tool. More...

Public Member Functions
	MosaicControlNetToolMovementConfigDialog (MosaicControlNetTool *tool, QWidget *parent)
	Create a config dialog that configures the given MosaicControlNetTool. More...
	~MosaicControlNetToolMovementConfigDialog ()
	Clean up allocated memory. More...

Detailed Description

Configure qmos Control Net Tool's movement arrows.

This allows a user to configure the qmos Control Net Tool's movement arrows. These are the arrows that go from the A Priori surface point to the Adjusted surface point.

Author

2012-12-31 Steven Lambright

Constructor & Destructor Documentation

MosaicControlNetToolMovementConfigDialog()

Isis::MosaicControlNetToolMovementConfigDialog::MosaicControlNetToolMovementConfigDialog	(	MosaicControlNetTool *	tool,
		QWidget *	parent
	)

Create a config dialog that configures the given MosaicControlNetTool.

Parameters

tool	The tool to read settings from and write settings to.
parent	The qt-parent relationship parent.

References applySettings(), Isis::MosaicControlNetTool::MeasureCount, Isis::MosaicControlNetTool::NoColor, readSettings(), refreshWidgetStates(), and Isis::MosaicControlNetTool::ResidualMagnitude.

~MosaicControlNetToolMovementConfigDialog()

Isis::MosaicControlNetToolMovementConfigDialog::~MosaicControlNetToolMovementConfigDialog

(

)

Clean up allocated memory.

Member Function Documentation

applySettings

void Isis::MosaicControlNetToolMovementConfigDialog::applySettings ( )

slot

Apply the user's current settings to the tool.

References Isis::MosaicControlNetTool::NoMovement, Isis::Null, readSettings(), Isis::toDouble(), and Isis::toInt().

Referenced by MosaicControlNetToolMovementConfigDialog().

readSettings

void Isis::MosaicControlNetToolMovementConfigDialog::readSettings ( )

slot

Read the tool's current settings and set the widget states to match.

References Isis::MosaicControlNetTool::NoMovement, Isis::Null, refreshWidgetStates(), and Isis::toString().

Referenced by applySettings(), and MosaicControlNetToolMovementConfigDialog().

refreshWidgetStates

void Isis::MosaicControlNetToolMovementConfigDialog::refreshWidgetStates ( )

slot

Enables or disables widgets depending on the state of the tool.

References Isis::MosaicControlNetTool::MeasureCount, Isis::MosaicControlNetTool::NoColor, Isis::MosaicControlNetTool::ResidualMagnitude, and Isis::toInt().

Referenced by MosaicControlNetToolMovementConfigDialog(), and readSettings().

---

The documentation for this class was generated from the following files:

• /usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/qisis/objs/MosaicSceneWidget/MosaicControlNetToolMovementConfigDialog.h
• /usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/qisis/objs/MosaicSceneWidget/MosaicControlNetToolMovementConfigDialog.cpp
