Isis::Spectel Class Reference

Stores information about a "Spectral pixel" or spectel. More...

#include <Spectel.h>

Inheritance diagram for Isis::Spectel:

Collaboration diagram for Isis::Spectel:

Public Member Functions
	Spectel ()
	Constructs an empty Spectel. More...
	Spectel (int sample, int line, int band, double DN, double center, double width)
	Constructs a Spectel using its l,s,b coordinates, its DN value, and its wavelength. More...
	Spectel (Pixel pixel, double center, double width)
	Constructs a Spectel, given a Pixel, center wavelength, and width. More...
	Spectel (const Spectel &spectel)
	Constructs a Spectel, given a Spectel. More...
virtual	~Spectel ()
	Default destructor. More...
Spectel &	operator= (const Spectel &other)
	Copy assignment operator. More...
double	centerWavelength () const
	Gets central wavelength of spectel. More...
double	filterWidth () const
	Gets wavelength width associated with spectel. More...
int	line () const
int	sample () const
int	band () const
double	DN () const
unsigned char	To8Bit ()
	Converts internal pixel value to an unsigned char pixel with special pixel translations. More...
short int	To16Bit ()
	Converts internal pixel value to a short int pixel with special pixel translations. More...
short unsigned int	To16Ubit ()
	Converts internal pixel value to a short int pixel with special pixel translations. More...
float	To32Bit ()
	Converts internal pixel value to float with special pixel translations. More...
double	ToDouble ()
	Converts stored pixel value to a double. More...
float	ToFloat ()
	Converts internal pixel value to float with pixel translations and care for overflows (underflows are assumed to cast to 0!) More...
std::string	ToString ()
	Returns the name of the pixel type as a string. More...
bool	IsSpecial ()
	Returns true if the input pixel is special. More...
bool	IsValid ()
	Returns true if the input pixel is valid. More...
bool	IsNull ()
	Returns true if the input pixel is null. More...
bool	IsHigh ()
	Returns true if the input pixel is one of the high saturation types. More...
bool	IsLow ()
	Returns true if the input pixel is one of the low saturation types. More...
bool	IsHrs ()
	Returns true if the input pixel is high representation saturation. More...
bool	IsHis ()
	Returns true if the input pixel is high instrument saturation. More...
bool	IsLis ()
	Returns true if the input pixel is low instrument saturation. More...
bool	IsLrs ()
	Returns true if the input pixel is low representation saturation. More...

Static Public Member Functions
static unsigned char	To8Bit (const double d)
	Converts double pixels to unsigned char pixels with special pixel translations. More...
static short int	To16Bit (const double d)
	Converts double pixels to short int pixels with special pixel translations. More...
static short unsigned int	To16UBit (const double d)
	Converts double pixels to short unsigned int pixels with special pixel translations. More...
static float	To32Bit (const double d)
	Converts double pixels to float pixels with special pixel translations. More...
static double	ToDouble (const unsigned char t)
	Converts unsigned char pixels to double pixels with special pixel translations. More...
static double	ToDouble (const short int t)
	Converts short int pixels to double pixels with special pixel translations. More...
static double	ToDouble (const short unsigned int t)
	Converts short unsigned int pixels to double pixels with special pixel translations. More...
static double	ToDouble (const float t)
	Converts float pixels to double pixels with special pixel translations. More...
static float	ToFloat (const unsigned char d)
	Converts unsigned char to float with pixel translations and care for overflows (underflows are assumed to cast to 0!) More...
static float	ToFloat (const short int d)
	Converts short int to float with pixel translations and care for overflows (underflows are assumed to cast to 0!) More...
static float	ToFloat (const short unsigned int d)
	Converts short unsigned int to float with pixel translations and care for overflows (underflows are assumed to cast to 0!) More...
static float	ToFloat (const double d)
	Converts double to float with pixel translations and care for overflows (underflows are assumed to cast to 0!) More...
static std::string	ToString (double d)
	Takes a double pixel value and returns the name of the pixel type as a string. More...
static bool	IsSpecial (const double d)
	Returns true if the input pixel is special. More...
static bool	IsSpecial (const float f)
	Returns true if the input pixel is special. More...
static bool	IsValid (const double d)
	Returns true if the input pixel is valid. More...
static bool	IsNull (const double d)
	Returns true if the input pixel is null. More...
static bool	IsHigh (const double d)
	Returns true if the input pixel is one of the high saturation types. More...
static bool	IsLow (const double d)
	Returns true if the input pixel is one of the low saturation types. More...
static bool	IsHrs (const double d)
	Returns true if the input pixel is high representation saturation. More...
static bool	IsHis (const double d)
	Returns true if the input pixel is high instrument saturation. More...
static bool	IsLis (const double d)
	Returns true if the input pixel is low instrument saturation. More...
static bool	IsLrs (const double d)
	Returns true if the input pixel is low representation saturation. More...

Detailed Description

Stores information about a "Spectral pixel" or spectel.

Author

2015-05-11 Kristin Berry (5/11/2015)

Constructor & Destructor Documentation

Spectel() [1/4]

Isis::Spectel::Spectel

(

)

Constructs an empty Spectel.

Author

2015-06-11 Stuart Sides

References Isis::Null.

Spectel() [2/4]

Isis::Spectel::Spectel	(	int	sample,
		int	line,
		int	band,
		double	DN,
		double	center,
		double	width
	)

Constructs a Spectel using its l,s,b coordinates, its DN value, and its wavelength.

Author

2015-05-08 Kristin Berry (5/8/2015)

Parameters

line	spectel line coordinate
sample	spectel sample coordinate
band	spectel band coordinate
DN	spectel value
center	center wavelength of spectel
width	wavelength width of spectel

Spectel() [3/4]

Isis::Spectel::Spectel	(	Pixel	pixel,
		double	center,
		double	width
	)

Constructs a Spectel, given a Pixel, center wavelength, and width.

Author

2015-08-09 Kristin Berry

Parameters

pixel	Pixel used to create the Spectel
center	Center wavelength of the Spectel
width	Width of the Spectel

Spectel() [4/4]

Isis::Spectel::Spectel

(

const Spectel &

spectel

)

Constructs a Spectel, given a Spectel.

Author

2015-08-06 Kristin Berry

Parameters

spectel

Spectel to copy

References centerWavelength(), and filterWidth().

~Spectel()

Isis::Spectel::~Spectel ( )

virtual

Default destructor.

Member Function Documentation

band()

int Isis::Pixel::band ( ) const

inherited

Returns

int The band coordinate of the Pixel

Referenced by Isis::Pixel::operator=(), and Isis::Pixel::Pixel().

centerWavelength()

double Isis::Spectel::centerWavelength

(

)

const

Gets central wavelength of spectel.

Author

kberry (5/11/2015)

Returns

double center wavelength of spectel

Referenced by Isis::SpectralDefinition2D::findSpectel(), Isis::SpectralDefinition1D::findSpectel(), operator=(), Spectel(), and Isis::SpectralDefinition2D::toString().

DN()

double Isis::Pixel::DN ( ) const

inherited

Returns

double The DN value of the Pixel

Referenced by Isis::Pixel::operator=(), and Isis::Pixel::Pixel().

filterWidth()

double Isis::Spectel::filterWidth

(

)

const

Gets wavelength width associated with spectel.

Author

kberry (5/11/2015)

Returns

double wavelength width of spectel

Referenced by operator=(), Spectel(), and Isis::SpectralDefinition2D::toString().

IsHigh() [1/2]

static bool Isis::Pixel::IsHigh ( const double  d )

inlinestaticinherited

Returns true if the input pixel is one of the high saturation types.

Parameters

d	Pixel value to test

Returns

bool

References Isis::HIGH_INSTR_SAT8, and Isis::HIGH_REPR_SAT8.

IsHigh() [2/2]

bool Isis::Pixel::IsHigh ( )

inlineinherited

Returns true if the input pixel is one of the high saturation types.

Returns

bool

IsHis() [1/2]

static bool Isis::Pixel::IsHis ( const double  d )

inlinestaticinherited

Returns true if the input pixel is high instrument saturation.

Parameters

d	Pixel value to test

Returns

bool

References Isis::HIGH_INSTR_SAT8.

IsHis() [2/2]

bool Isis::Pixel::IsHis ( )

inlineinherited

Returns true if the input pixel is high instrument saturation.

Returns

bool

IsHrs() [1/2]

static bool Isis::Pixel::IsHrs ( const double  d )

inlinestaticinherited

Returns true if the input pixel is high representation saturation.

Parameters

d	Pixel value to test

Returns

bool

References Isis::HIGH_REPR_SAT8.

IsHrs() [2/2]

bool Isis::Pixel::IsHrs ( )

inlineinherited

Returns true if the input pixel is high representation saturation.

Returns

bool

IsLis() [1/2]

static bool Isis::Pixel::IsLis ( const double  d )

inlinestaticinherited

Returns true if the input pixel is low instrument saturation.

Parameters

d	Pixel value to test

Returns

bool

References Isis::LOW_INSTR_SAT8.

IsLis() [2/2]

bool Isis::Pixel::IsLis ( )

inlineinherited

Returns true if the input pixel is low instrument saturation.

Returns

bool

IsLow() [1/2]

static bool Isis::Pixel::IsLow ( const double  d )

inlinestaticinherited

Returns true if the input pixel is one of the low saturation types.

Parameters

d	Pixel value to test

Returns

bool

References Isis::LOW_INSTR_SAT8, and Isis::LOW_REPR_SAT8.

IsLow() [2/2]

bool Isis::Pixel::IsLow ( )

inlineinherited

Returns true if the input pixel is one of the low saturation types.

Returns

bool

IsLrs() [1/2]

static bool Isis::Pixel::IsLrs ( const double  d )

inlinestaticinherited

Returns true if the input pixel is low representation saturation.

Parameters

d	Pixel value to test

Returns

bool

References Isis::LOW_REPR_SAT8.

IsLrs() [2/2]

bool Isis::Pixel::IsLrs ( )

inlineinherited

Returns true if the input pixel is low representation saturation.

Returns

bool

IsNull() [1/2]

static bool Isis::Pixel::IsNull ( const double  d )

inlinestaticinherited

Returns true if the input pixel is null.

Parameters

d	Pixel value to test

Returns

bool

References Isis::NULL8.

IsNull() [2/2]

bool Isis::Pixel::IsNull ( )

inlineinherited

Returns true if the input pixel is null.

Returns

bool

IsSpecial() [1/3]

static bool Isis::Pixel::IsSpecial ( const double  d )

inlinestaticinherited

Returns true if the input pixel is special.

Not special implies it is valid to use in computations.

Parameters

d	Pixel value to test

Returns

bool

References Isis::VALID_MIN8.

IsSpecial() [2/3]

bool Isis::Pixel::IsSpecial ( )

inlineinherited

Returns true if the input pixel is special.

Not special implies it is valid to use in computations.

Returns

bool

IsSpecial() [3/3]

static bool Isis::Pixel::IsSpecial ( const float  f )

inlinestaticinherited

Returns true if the input pixel is special.

Not special implies it is valid to use in computations. This method applies to a 4-byte floating point rather than an 8-byte double.

Parameters

f	Pixel value to test

Returns

bool

References Isis::VALID_MIN4.

IsValid() [1/2]

static bool Isis::Pixel::IsValid ( const double  d )

inlinestaticinherited

Returns true if the input pixel is valid.

Valid implies the pixel is neither hrs, lrs, his, lis, nor null.

Parameters

d	Pixel value to test

Returns

bool

References Isis::VALID_MIN8.

IsValid() [2/2]

bool Isis::Pixel::IsValid ( )

inlineinherited

Returns true if the input pixel is valid.

Valid implies the pixel is neither hrs, lrs, his, lis, nor null.

Returns

bool

line()

int Isis::Pixel::line ( ) const

inherited

Returns

int The line coordinate of the Pixel

Referenced by Isis::Pixel::operator=(), and Isis::Pixel::Pixel().

operator=()

Spectel & Isis::Spectel::operator=

(

const Spectel &

other

)

Copy assignment operator.

References centerWavelength(), filterWidth(), and Isis::Pixel::operator=().

sample()

int Isis::Pixel::sample ( ) const

inherited

Returns

int The sample coordinate of the Pixel

Referenced by Isis::SpectralDefinition2D::findSpectel(), Isis::Pixel::operator=(), and Isis::Pixel::Pixel().

To16Bit() [1/2]

short int Isis::Pixel::To16Bit ( const double  d )

staticinherited

Converts double pixels to short int pixels with special pixel translations.

Parameters

d	Double pixel value to be converted to a double

Returns

short int The short int pixel value

References Isis::HIGH_INSTR_SAT2, Isis::HIGH_INSTR_SAT8, Isis::HIGH_REPR_SAT2, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT2, Isis::LOW_INSTR_SAT8, Isis::LOW_REPR_SAT2, Isis::LOW_REPR_SAT8, Isis::NULL2, Isis::NULL8, Isis::VALID_MAX2, Isis::VALID_MIN2, and Isis::VALID_MIN8.

To16Bit() [2/2]

short int Isis::Pixel::To16Bit ( )

inherited

Converts internal pixel value to a short int pixel with special pixel translations.

Returns

short int The short int pixel value

To16UBit()

short unsigned int Isis::Pixel::To16UBit ( const double  d )

staticinherited

Converts double pixels to short unsigned int pixels with special pixel translations.

Parameters

d	Double pixel value to be converted to a double

Returns

short unsigned int The short int pixel value

References Isis::HIGH_INSTR_SAT8, Isis::HIGH_INSTR_SATU2, Isis::HIGH_REPR_SAT8, Isis::HIGH_REPR_SATU2, Isis::LOW_INSTR_SAT8, Isis::LOW_INSTR_SATU2, Isis::LOW_REPR_SAT8, Isis::LOW_REPR_SATU2, Isis::NULL8, Isis::NULLU2, Isis::VALID_MAX2, Isis::VALID_MIN2, and Isis::VALID_MIN8.

To16Ubit()

short unsigned int Isis::Pixel::To16Ubit ( )

inherited

Converts internal pixel value to a short int pixel with special pixel translations.

Returns

short unsigned int The short int pixel value

To32Bit() [1/2]

float Isis::Pixel::To32Bit ( const double  d )

staticinherited

Converts double pixels to float pixels with special pixel translations.

Parameters

d	Double pixel value to be converted to a double

Returns

float The float pixel value

References Isis::HIGH_INSTR_SAT4, Isis::HIGH_INSTR_SAT8, Isis::HIGH_REPR_SAT4, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT4, Isis::LOW_INSTR_SAT8, Isis::LOW_REPR_SAT4, Isis::LOW_REPR_SAT8, Isis::NULL4, Isis::NULL8, Isis::VALID_MAX8, and Isis::VALID_MIN8.

To32Bit() [2/2]

float Isis::Pixel::To32Bit ( )

inherited

Converts internal pixel value to float with special pixel translations.

Returns

float The float pixel value

To8Bit() [1/2]

unsigned char Isis::Pixel::To8Bit ( const double  d )

staticinherited

Converts double pixels to unsigned char pixels with special pixel translations.

Parameters

d	Double pixel value to be converted to a double

Returns

unsigned char The unsigned char pixel value

References Isis::HIGH_INSTR_SAT1, Isis::HIGH_INSTR_SAT8, Isis::HIGH_REPR_SAT1, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT1, Isis::LOW_INSTR_SAT8, Isis::LOW_REPR_SAT1, Isis::LOW_REPR_SAT8, Isis::NULL1, Isis::NULL8, Isis::VALID_MAX1, Isis::VALID_MIN1, and Isis::VALID_MIN8.

To8Bit() [2/2]

unsigned char Isis::Pixel::To8Bit ( )

inherited

Converts internal pixel value to an unsigned char pixel with special pixel translations.

Returns

unsigned char The unsigned char pixel value

ToDouble() [1/5]

double Isis::Pixel::ToDouble ( const unsigned char  d )

staticinherited

Converts unsigned char pixels to double pixels with special pixel translations.

Parameters

d	Unsigned char pixel value to be converted to a double

Returns

double The double pixel value

References Isis::HIGH_INSTR_SAT1, Isis::HIGH_INSTR_SAT8, Isis::HIGH_REPR_SAT1, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT1, Isis::LOW_INSTR_SAT8, Isis::LOW_REPR_SAT1, Isis::LOW_REPR_SAT8, Isis::NULL1, Isis::NULL8, Isis::VALID_MAX1, and Isis::VALID_MIN1.

ToDouble() [2/5]

double Isis::Pixel::ToDouble ( const short int  d )

staticinherited

Converts short int pixels to double pixels with special pixel translations.

Parameters

d	Short int pixel value to be converted to a double

Returns

double The double pixel value

References Isis::HIGH_INSTR_SAT2, Isis::HIGH_INSTR_SAT8, Isis::HIGH_REPR_SAT2, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT2, Isis::LOW_INSTR_SAT8, Isis::LOW_REPR_SAT2, Isis::LOW_REPR_SAT8, Isis::NULL2, Isis::NULL8, and Isis::VALID_MIN2.

ToDouble() [3/5]

double Isis::Pixel::ToDouble ( const short unsigned int  d )

staticinherited

Converts short unsigned int pixels to double pixels with special pixel translations.

Parameters

d	Short unsigned int pixel value to be converted to a double

Returns

double The double pixel value

References Isis::HIGH_INSTR_SAT8, Isis::HIGH_INSTR_SATU2, Isis::HIGH_REPR_SAT8, Isis::HIGH_REPR_SATU2, Isis::LOW_INSTR_SAT8, Isis::LOW_INSTR_SATU2, Isis::LOW_REPR_SAT8, Isis::LOW_REPR_SATU2, Isis::NULL8, Isis::NULLU2, and Isis::VALID_MINU2.

ToDouble() [4/5]

double Isis::Pixel::ToDouble ( const float  d )

staticinherited

Converts float pixels to double pixels with special pixel translations.

Parameters

d	Float pixel value to be converted to a double

Returns

double The double pixel value

References Isis::HIGH_INSTR_SAT4, Isis::HIGH_INSTR_SAT8, Isis::HIGH_REPR_SAT4, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT4, Isis::LOW_INSTR_SAT8, Isis::LOW_REPR_SAT4, Isis::LOW_REPR_SAT8, Isis::NULL4, Isis::NULL8, Isis::VALID_MAX4, and Isis::VALID_MIN4.

ToDouble() [5/5]

double Isis::Pixel::ToDouble ( )

inherited

Converts stored pixel value to a double.

Returns

double The double pixel value

ToFloat() [1/5]

float Isis::Pixel::ToFloat ( const unsigned char  t )

staticinherited

Converts unsigned char to float with pixel translations and care for overflows (underflows are assumed to cast to 0!)

Parameters

t	Unsigned char pixel value to be converted to a float

Returns

float The float pixel value

References Isis::HIGH_INSTR_SAT1, Isis::HIGH_INSTR_SAT4, Isis::HIGH_REPR_SAT1, Isis::HIGH_REPR_SAT4, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT1, Isis::LOW_INSTR_SAT4, Isis::LOW_REPR_SAT1, Isis::LOW_REPR_SAT4, Isis::NULL1, Isis::NULL4, Isis::VALID_MAX1, and Isis::VALID_MIN1.

ToFloat() [2/5]

float Isis::Pixel::ToFloat ( const short int  t )

staticinherited

Converts short int to float with pixel translations and care for overflows (underflows are assumed to cast to 0!)

Parameters

t	Short int pixel value to be converted to a float

Returns

float The float pixel value

References Isis::HIGH_INSTR_SAT2, Isis::HIGH_INSTR_SAT4, Isis::HIGH_REPR_SAT2, Isis::HIGH_REPR_SAT4, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT2, Isis::LOW_INSTR_SAT4, Isis::LOW_REPR_SAT2, Isis::LOW_REPR_SAT4, Isis::NULL2, Isis::NULL4, Isis::VALID_MAX2, and Isis::VALID_MIN2.

ToFloat() [3/5]

float Isis::Pixel::ToFloat ( const short unsigned int  t )

staticinherited

Converts short unsigned int to float with pixel translations and care for overflows (underflows are assumed to cast to 0!)

Parameters

t	Short unsigned int pixel value to be converted to a float

Returns

float The float pixel value

References Isis::HIGH_INSTR_SAT4, Isis::HIGH_INSTR_SATU2, Isis::HIGH_REPR_SAT4, Isis::HIGH_REPR_SAT8, Isis::HIGH_REPR_SATU2, Isis::LOW_INSTR_SAT4, Isis::LOW_INSTR_SATU2, Isis::LOW_REPR_SAT4, Isis::LOW_REPR_SATU2, Isis::NULL4, Isis::NULLU2, Isis::VALID_MAXU2, and Isis::VALID_MINU2.

ToFloat() [4/5]

float Isis::Pixel::ToFloat ( const double  t )

staticinherited

Converts double to float with pixel translations and care for overflows (underflows are assumed to cast to 0!)

Parameters

t	Double pixel value to be converted to a float

Returns

float The float pixel value

References Isis::HIGH_INSTR_SAT4, Isis::HIGH_INSTR_SAT8, Isis::HIGH_REPR_SAT4, Isis::HIGH_REPR_SAT8, Isis::LOW_INSTR_SAT4, Isis::LOW_INSTR_SAT8, Isis::LOW_REPR_SAT4, Isis::LOW_REPR_SAT8, Isis::NULL4, Isis::NULL8, Isis::VALID_MAX8, and Isis::VALID_MIN8.

ToFloat() [5/5]

float Isis::Pixel::ToFloat ( )

inherited

Converts internal pixel value to float with pixel translations and care for overflows (underflows are assumed to cast to 0!)

Returns

float The float pixel value

ToString() [1/2]

string Isis::Pixel::ToString ( double  d )

staticinherited

Takes a double pixel value and returns the name of the pixel type as a string.

Parameters

d	Pixel value

Returns

string The name of the pixel type

References Isis::IsSpecial().

ToString() [2/2]

string Isis::Pixel::ToString ( )

inherited

Returns the name of the pixel type as a string.

Returns

string The name of the pixel type

References Isis::ToString().

---

The documentation for this class was generated from the following files:

• /usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/base/objs/Spectel/Spectel.h
• /usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/base/objs/Spectel/Spectel.cpp
