Isis Developer Reference
Public Types | Public Member Functions | Protected Member Functions | Static Protected Member Functions | List of all members
Isis::AbstractImageItem Class Referenceabstract

Base class for an image item in the tree. More...

#include <AbstractImageItem.h>

Inheritance diagram for Isis::AbstractImageItem:
Inheritance graph
Collaboration diagram for Isis::AbstractImageItem:
Collaboration graph

Public Types

enum  InternalPointerType { None , Point , Measure , ImageAndNet }


Public Member Functions

 AbstractImageItem (QString imageSerial, ControlNet *net, int avgCharWidth, AbstractTreeItem *parent=0)

virtual ~AbstractImageItem ()

QVariant getData () const

QVariant getData (QString columnTitle) const

void setData (QString const &columnTitle, QString const &newData)

bool isDataEditable (QString columnTitle) const

void deleteSource ()

InternalPointerType getPointerType () const

void * getPointer () const

bool hasImage (QString imageSerial) const

AbstractTreeItem * parent () const

void setParent (AbstractTreeItem *newParent)

int row () const

virtual void addChild (AbstractTreeItem *child)=0

virtual QList< AbstractTreeItem * > getChildren () const =0

virtual AbstractTreeItem * childAt (int row) const =0

virtual int childCount () const =0

virtual AbstractTreeItem * getFirstVisibleChild () const =0

virtual AbstractTreeItem * getLastVisibleChild () const =0

virtual int indexOf (AbstractTreeItem *child) const =0

virtual void setFirstVisibleChild (AbstractTreeItem *child)=0

virtual void setLastVisibleChild (AbstractTreeItem *child)=0

virtual QString getFormattedData () const

virtual QString getFormattedData (QString columnTitle) const

virtual bool hasMeasure (ControlMeasure *) const

virtual bool hasPoint (ControlPoint *) const

virtual AbstractTreeItem * getNextVisiblePeer () const

virtual void setNextVisiblePeer (AbstractTreeItem *next)

virtual void setExpanded (bool newState)

virtual bool isExpanded () const

virtual void setSelected (bool newState)

virtual void setSelectable (bool newSelectable)

virtual bool isSelected () const

virtual bool isSelectable () const

virtual void setVisible (bool newState)

virtual bool isVisible () const

virtual int getDataWidth () const

virtual int getDepth () const

virtual void setLastVisibleFilteredItem (AbstractTreeItem *item)

virtual const AbstractTreeItem * getLastVisibleFilteredItem () const


Protected Member Functions

virtual void sourceDeleted ()
 This method is required to be implemented by the parent AbstractTreeItem class, but for this it's a NOP. More...

virtual void calcDataWidth (int avgCharWidth)


Static Protected Member Functions

static double catchNull (QString)

static QString catchNull (QVariant)


Detailed Description

Base class for an image item in the tree.

This class represents an image item in the tree. This is generally visualized as a serial number.

Author
????-??-?? Eric Hyer

Member Enumeration Documentation

◆ InternalPointerType

enum Isis::AbstractTreeItem::InternalPointerType
inherited
Enumerator
None
Point
Measure
ImageAndNet

Constructor & Destructor Documentation

◆ AbstractImageItem()

Isis::AbstractImageItem::AbstractImageItem ( QString  imageSerial,
ControlNet *  net,
int  avgCharWidth,
AbstractTreeItem *  parent = 0
)

References Isis::AbstractTreeItem::calcDataWidth().

◆ ~AbstractImageItem()

Isis::AbstractImageItem::~AbstractImageItem ( )
virtual

Member Function Documentation

◆ addChild()

virtual void Isis::AbstractTreeItem::addChild ( AbstractTreeItem *  child)
pure virtualinherited

Implemented in Isis::AbstractLeafItem, Isis::AbstractParentItem, Isis::ConnectionParentItem, and Isis::PointParentItem.

◆ calcDataWidth()

void Isis::AbstractTreeItem::calcDataWidth ( int  avgCharWidth)
protectedvirtualinherited

References _FILEINFO_, Isis::AbstractTreeItem::getFormattedData(), and Isis::IException::Programmer.

Referenced by AbstractImageItem(), Isis::AbstractMeasureItem::AbstractMeasureItem(), Isis::AbstractPointItem::AbstractPointItem(), and Isis::BusyLeafItem::BusyLeafItem().

◆ catchNull() [1/2]

double Isis::AbstractTreeItem::catchNull ( QString  str)
staticprotectedinherited

References Isis::Null.

Referenced by Isis::AbstractTreeItem::getFormattedData(), Isis::AbstractMeasureItem::setData(), and Isis::AbstractPointItem::setData().

◆ catchNull() [2/2]

QString Isis::AbstractTreeItem::catchNull ( QVariant  data)
staticprotectedinherited

References Isis::Double, and Isis::Null.

◆ childAt()

virtual AbstractTreeItem * Isis::AbstractTreeItem::childAt ( int  row) const
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

Referenced by Isis::AbstractTreeItem::hasImage(), Isis::AbstractTreeItem::hasMeasure(), and Isis::AbstractTreeItem::hasPoint().

◆ childCount()

virtual int Isis::AbstractTreeItem::childCount ( ) const
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

Referenced by Isis::AbstractTreeItem::hasImage(), Isis::AbstractTreeItem::hasMeasure(), and Isis::AbstractTreeItem::hasPoint().

◆ deleteSource()

void Isis::AbstractImageItem::deleteSource ( )
virtual

Implements Isis::AbstractTreeItem.

◆ getChildren()

virtual QList< AbstractTreeItem * > Isis::AbstractTreeItem::getChildren ( ) const
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

Referenced by Isis::TableViewContent::mouseMoveEvent(), Isis::TableViewContent::mousePressEvent(), and Isis::TreeViewContent::mousePressEvent().

◆ getData() [1/2]

QVariant Isis::AbstractImageItem::getData ( ) const
virtual

Implements Isis::AbstractTreeItem.

◆ getData() [2/2]

QVariant Isis::AbstractImageItem::getData ( QString  columnTitle) const
virtual

Implements Isis::AbstractTreeItem.

◆ getDataWidth()

int Isis::AbstractTreeItem::getDataWidth ( ) const
virtualinherited

References _FILEINFO_, and Isis::IException::Programmer.

Referenced by Isis::AbstractTreeModel::getVisibleSize().

◆ getDepth()

int Isis::AbstractTreeItem::getDepth ( ) const
virtualinherited

References Isis::AbstractTreeItem::parent().

Referenced by Isis::AbstractTreeModel::getVisibleSize().

◆ getFirstVisibleChild()

virtual AbstractTreeItem * Isis::AbstractTreeItem::getFirstVisibleChild ( ) const
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

Referenced by Isis::TreeViewContent::mouseMoveEvent(), and Isis::TreeViewContent::mousePressEvent().

◆ getFormattedData() [1/2]

QString Isis::AbstractTreeItem::getFormattedData ( ) const
virtualinherited

References Isis::AbstractTreeItem::catchNull(), and Isis::AbstractTreeItem::getData().

Referenced by Isis::AbstractTreeItem::calcDataWidth(), Isis::AbstractMeasureItem::deleteSource(), Isis::AbstractPointItem::deleteSource(), Isis::MeasureTableModel::getMeasureWarningMessage(), Isis::PointTableModel::getPointWarningMessage(), Isis::MeasureTableDelegate::readData(), and Isis::PointTableDelegate::readData().

◆ getFormattedData() [2/2]

QString Isis::AbstractTreeItem::getFormattedData ( QString  columnTitle) const
virtualinherited

References Isis::AbstractTreeItem::catchNull(), and Isis::AbstractTreeItem::getData().

◆ getLastVisibleChild()

virtual AbstractTreeItem * Isis::AbstractTreeItem::getLastVisibleChild ( ) const
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

Referenced by Isis::AbstractTreeModel::getItems().

◆ getLastVisibleFilteredItem()

const AbstractTreeItem * Isis::AbstractTreeItem::getLastVisibleFilteredItem ( ) const
virtualinherited

Reimplemented in Isis::RootItem.

◆ getNextVisiblePeer()

AbstractTreeItem * Isis::AbstractTreeItem::getNextVisiblePeer ( ) const
virtualinherited

Referenced by Isis::AbstractTreeModel::getVisibleTopLevelItemCount().

◆ getPointer()

void * Isis::AbstractImageItem::getPointer ( ) const
virtual

Implements Isis::AbstractTreeItem.

◆ getPointerType()

AbstractTreeItem::InternalPointerType Isis::AbstractImageItem::getPointerType ( ) const
virtual

Implements Isis::AbstractTreeItem.

References Isis::AbstractTreeItem::ImageAndNet.

◆ hasImage()

bool Isis::AbstractImageItem::hasImage ( QString  imageSerial) const
virtual

Reimplemented from Isis::AbstractTreeItem.

References Isis::AbstractTreeItem::hasImage().

◆ hasMeasure()

bool Isis::AbstractTreeItem::hasMeasure ( ControlMeasure *  measure) const
virtualinherited

Reimplemented in Isis::AbstractMeasureItem.

References Isis::AbstractTreeItem::childAt(), Isis::AbstractTreeItem::childCount(), and Isis::AbstractTreeItem::hasMeasure().

Referenced by Isis::AbstractTreeItem::hasMeasure().

◆ hasPoint()

bool Isis::AbstractTreeItem::hasPoint ( ControlPoint *  point) const
virtualinherited

Reimplemented in Isis::AbstractPointItem.

References Isis::AbstractTreeItem::childAt(), Isis::AbstractTreeItem::childCount(), and Isis::AbstractTreeItem::hasPoint().

Referenced by Isis::AbstractTreeItem::hasPoint().

◆ indexOf()

virtual int Isis::AbstractTreeItem::indexOf ( AbstractTreeItem *  child) const
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

Referenced by Isis::AbstractTreeItem::row().

◆ isDataEditable()

bool Isis::AbstractImageItem::isDataEditable ( QString  columnTitle) const
virtual

Implements Isis::AbstractTreeItem.

◆ isExpanded()

bool Isis::AbstractTreeItem::isExpanded ( ) const
virtualinherited

Referenced by Isis::TreeViewContent::mouseDoubleClickEvent(), and Isis::TreeViewContent::mouseReleaseEvent().

◆ isSelectable()

bool Isis::AbstractTreeItem::isSelectable ( ) const
virtualinherited

Reimplemented in Isis::BusyLeafItem.

Referenced by Isis::TreeViewContent::mouseMoveEvent(), and Isis::TreeViewContent::mousePressEvent().

◆ isSelected()

bool Isis::AbstractTreeItem::isSelected ( ) const
virtualinherited

Referenced by Isis::AbstractTreeModel::getSelectedItems(), Isis::TableViewContent::mousePressEvent(), and Isis::TreeViewContent::mousePressEvent().

◆ isVisible()

bool Isis::AbstractTreeItem::isVisible ( ) const
virtualinherited

◆ parent()

AbstractTreeItem * Isis::AbstractTreeItem::parent ( ) const
inherited

Referenced by Isis::AbstractTreeItem::getDepth(), Isis::AbstractTreeModel::getItems(), Isis::PointTableModel::handleTreeSelectionChanged(), and Isis::TableViewContent::mousePressEvent().

◆ row()

int Isis::AbstractTreeItem::row ( ) const
inherited

References Isis::AbstractTreeItem::indexOf().

Referenced by Isis::AbstractParentItem::childAt().

◆ setData()

void Isis::AbstractImageItem::setData ( QString const &  columnTitle,
QString const &  newData
)
virtual

Implements Isis::AbstractTreeItem.

◆ setExpanded()

void Isis::AbstractTreeItem::setExpanded ( bool  newState)
virtualinherited

Referenced by Isis::TreeViewContent::mouseDoubleClickEvent(), Isis::TreeViewContent::mouseReleaseEvent(), and Isis::RootItem::RootItem().

◆ setFirstVisibleChild()

virtual void Isis::AbstractTreeItem::setFirstVisibleChild ( AbstractTreeItem *  child)
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

◆ setLastVisibleChild()

virtual void Isis::AbstractTreeItem::setLastVisibleChild ( AbstractTreeItem *  child)
pure virtualinherited

Implemented in Isis::AbstractLeafItem, and Isis::AbstractParentItem.

◆ setLastVisibleFilteredItem()

void Isis::AbstractTreeItem::setLastVisibleFilteredItem ( AbstractTreeItem *  item)
virtualinherited

Reimplemented in Isis::RootItem.

References _FILEINFO_, and Isis::IException::Programmer.

◆ setNextVisiblePeer()

void Isis::AbstractTreeItem::setNextVisiblePeer ( AbstractTreeItem *  next)
virtualinherited

◆ setParent()

void Isis::AbstractTreeItem::setParent ( AbstractTreeItem *  newParent)
inherited

Referenced by Isis::AbstractParentItem::addChild().

◆ setSelectable()

void Isis::AbstractTreeItem::setSelectable ( bool  newSelectable)
virtualinherited

◆ setSelected()

void Isis::AbstractTreeItem::setSelected ( bool  newState)
virtualinherited

Referenced by Isis::TableViewContent::mouseMoveEvent(), Isis::TableViewContent::mousePressEvent(), and Isis::TreeViewContent::mousePressEvent().

◆ setVisible()

void Isis::AbstractTreeItem::setVisible ( bool  newState)
virtualinherited

◆ sourceDeleted()

void Isis::AbstractImageItem::sourceDeleted ( )
protectedvirtual

This method is required to be implemented by the parent AbstractTreeItem class, but for this it's a NOP.

Implements Isis::AbstractTreeItem.

The documentation for this class was generated from the following files:
