Bullet Target Shape for NAIF type 2 DSK models. More...

#include <BulletDskShape.h>

Inheritance diagram for Isis::BulletDskShape:

Collaboration diagram for Isis::BulletDskShape:

Public Member Functions
	BulletDskShape ()
	Default empty constructor. More...

	BulletDskShape (const QString &dskfile)
	Construct a BulletDskShape from a DSK file. More...

virtual	~BulletDskShape ()
	Desctructor. More...

int	getNumTriangles () const
	Return the number of triangles in the shape. More...

int	getNumVertices () const
	Return the number of verticies in the shape. More...

virtual btVector3	getNormal (const int indexId, const int segment=0) const
	Return normal for a given triangle index. More...

virtual btMatrix3x3	getTriangle (const int index, const int segment=0) const
	Get the vertices of a triangle in the mesh. More...

QString	name () const
	Return name of the target shape. More...

void	writeBullet (const QString &btName) const
	Write a serialized version of the target shape to a Bullet file. More...

btCollisionObject *	body () const
	Return a pointer to the Bullet target object/shape. More...

btScalar	maximumDistance () const

Static Public Member Functions
static BulletTargetShape *	load (const QString &dem, const Pvl *conf=0)
	Load a DEM file into the target shape. More...

static BulletTargetShape *	loadPC (const QString &dem, const Pvl *conf=0)
	Load a point cloud type DEM in Bullet. More...

static BulletTargetShape *	loadDSK (const QString &dem, const Pvl *conf=0)
	Load a DSK in Bullet. More...

static BulletTargetShape *	loadCube (const QString &dem, const Pvl *conf=0)
	Load an ISIS cube type DEM in Bullet. More...

Protected Member Functions
void	setTargetBody (btCollisionObject *body)
	Set the Bullet shape object to this object instance More...

void	setMaximumDistance ()
	Calculate and save the maximum distance across the body. More...

Detailed Description

Bullet Target Shape for NAIF type 2 DSK models.

Author: 2017-03-17 Kris Becker

Constructor & Destructor Documentation

◆ BulletDskShape() [1/2]

Isis::BulletDskShape::BulletDskShape ( )

Default empty constructor.

◆ BulletDskShape() [2/2]

Isis::BulletDskShape::BulletDskShape ( const QString & dskfile )

Construct a BulletDskShape from a DSK file.

Parameters

dskfile The DSK file to load into a Bullet target shape.

References Isis::BulletTargetShape::setMaximumDistance().

◆ ~BulletDskShape()

Isis::BulletDskShape::~BulletDskShape ( )

virtual

Desctructor.

Member Function Documentation

◆ body()

btCollisionObject * Isis::BulletTargetShape::body ( ) const

inherited

Return a pointer to the Bullet target object/shape.

Returns: btCollisionObject A target to the Bullet collision object.

Referenced by Isis::BulletWorldManager::addTarget(), and Isis::BulletTargetShape::setTargetBody().

◆ getNormal()

btVector3 Isis::BulletDskShape::getNormal	(	const int	indexId,
		const int	segment = `0`
	)		const

virtual

Return normal for a given triangle index.

This method is particularly useful to return the normal of a triangle plate in a mesh-based target body.

Author: 2017-03-28 Kris Becker

Parameters

indexId The index of the triangle in the mesh.

Returns: btVector3 The local normal for the triangle.

References getTriangle().

◆ getNumTriangles()

int Isis::BulletDskShape::getNumTriangles ( ) const

Return the number of triangles in the shape.

Returns: int The number of triangles. If nothing has been loaded, then 0 is returned.

◆ getNumVertices()

int Isis::BulletDskShape::getNumVertices ( ) const

Return the number of verticies in the shape.

Returns: int The number of verticies. If nothing has been loaded, then 0 is returned.

◆ getTriangle()

btMatrix3x3 Isis::BulletDskShape::getTriangle	(	const int	index,
		const int	segment = `0`
	)		const

virtual

Get the vertices of a triangle in the mesh.

Parameters

index The index of the triangle in the mesh.

Returns: btMatrix3x3 Matrix with each row containing the coordinate of a vertex. The vertices are ordered counter-clockwise around the surface normal of the triangle.

Referenced by getNormal().

◆ load()

BulletTargetShape * Isis::BulletTargetShape::load	(	const QString &	dem,
		const Pvl *	conf = `0`
	)

staticinherited

Load a DEM file into the target shape.

Parameters

dem	The DEM file to load.
conf	PVL config for the DEM load. Currently unused.

Returns: BulletTargetShape A target shape containing the DEM

References Isis::FileName::extension(), Isis::BulletTargetShape::loadCube(), Isis::BulletTargetShape::loadDSK(), and Isis::BulletTargetShape::loadPC().

Referenced by Isis::BulletShapeModel::BulletShapeModel(), and Isis::ShapeModelFactory::create().

◆ loadCube()

BulletTargetShape * Isis::BulletTargetShape::loadCube	(	const QString &	dem,
		const Pvl *	conf = `0`
	)

staticinherited

Load an ISIS cube type DEM in Bullet.

Note: Currently not implemented

Parameters

dem	The DEM file to load.
conf	PVL config for the DEM load. Currently unused.

Returns: BulletTargetShape A target shape containing the DEM

Referenced by Isis::BulletTargetShape::load().

◆ loadDSK()

BulletTargetShape * Isis::BulletTargetShape::loadDSK	(	const QString &	dem,
		const Pvl *	conf = `0`
	)

staticinherited

Load a DSK in Bullet.

Parameters

dem	The DEM file to load.
conf	PVL config for the DEM load. Currently unused.

Returns: BulletTargetShape A target shape containing the DEM

Referenced by Isis::BulletTargetShape::load().

◆ loadPC()

BulletTargetShape * Isis::BulletTargetShape::loadPC	(	const QString &	dem,
		const Pvl *	conf = `0`
	)

staticinherited

Load a point cloud type DEM in Bullet.

Note: Currently not implemented

Parameters

dem	The DEM file to load.
conf	PVL config for the DEM load. Currently unused.

Returns: BulletTargetShape A target shape containing the DEM

Referenced by Isis::BulletTargetShape::load().

◆ maximumDistance()

btScalar Isis::BulletTargetShape::maximumDistance ( ) const

inherited

◆ name()

QString Isis::BulletTargetShape::name ( ) const

inherited

Return name of the target shape.

Returns: QString The target name

Referenced by Isis::BulletShapeModel::BulletShapeModel(), and Isis::BulletWorldManager::getTarget().

◆ setMaximumDistance()

void Isis::BulletTargetShape::setMaximumDistance ( )

protectedinherited

Calculate and save the maximum distance across the body.

This is calculated as the distance from the x, y, z minimum to x, y, z maximum.

Referenced by BulletDskShape(), Isis::BulletTargetShape::BulletTargetShape(), and Isis::BulletTargetShape::setTargetBody().

◆ setTargetBody()

void Isis::BulletTargetShape::setTargetBody ( btCollisionObject * body )

protectedinherited

Set the Bullet shape object to this object instance

References Isis::BulletTargetShape::body(), and Isis::BulletTargetShape::setMaximumDistance().

◆ writeBullet()

void Isis::BulletTargetShape::writeBullet ( const QString & btName ) const

inherited

Write a serialized version of the target shape to a Bullet file.

Parameters

btName The name of the file to write the target shape to.

Note: Currently not implemented

The documentation for this class was generated from the following files:

/Users/jmapel/ISIS3/isis/src/base/objs/BulletDskShape/BulletDskShape.h
/Users/jmapel/ISIS3/isis/src/base/objs/BulletDskShape/BulletDskShape.cpp
