| void | resetKnownGlobal () |
| |
| QSize | sizeHint () const |
| | Make viewports show up as 512 by 512.
|
| |
| void | setScale (double scale) |
| | Change the scale of the cube to the given parameter value.
|
| |
| void | setScale (double scale, double sample, double line) |
| | Change the scale of the cube after moving samp/line to the center.
|
| |
| void | setScale (double scale, int x, int y) |
| | Change the scale of the cube after moving x,y to the center.
|
| |
| void | center (int x, int y) |
| | Bring the cube pixel under viewport x/y to the center.
|
| |
| void | center (double sample, double line) |
| | Bring the cube sample/line the center.
|
| |
| virtual void | viewRGB (int redBand, int greenBand, int blueBand) |
| | View cube as color.
|
| |
| virtual void | viewGray (int band) |
| | View cube as gray.
|
| |
| void | stretchGray (const QString &string) |
| | Apply stretch pairs to gray band.
|
| |
| void | stretchGray (const Stretch &stretch) |
| | Sets the stretch for gray mode.
|
| |
| void | stretchRed (const QString &string) |
| | Apply stretch pairs to red bands.
|
| |
| void | stretchRed (const Stretch &stretch) |
| | Sets the stretch for red in rgb mode.
|
| |
| void | stretchGreen (const QString &string) |
| | Apply stretch pairs to green bands.
|
| |
| void | stretchGreen (const Stretch &stretch) |
| | Sets the stretch for green in rgb mode.
|
| |
| void | stretchBlue (const QString &string) |
| | Apply stretch pairs to blue bands.
|
| |
| void | stretchBlue (const Stretch &stretch) |
| | Sets the stretch for blue in rgb mode.
|
| |
| void | stretchKnownGlobal () |
| | List<Tool *> p This stretches to the global stretch.
|
| |
| void | cubeChanged (bool changed) |
| | This method is called when the cube has changed or changes have been finalized.
|
| |
| void | scrollBy (int dx, int dy) |
| | Move the scrollbars by dx/dy screen pixels.
|
| |
| void | changeCursor (QCursor cursor) |
| | Allows users to change the cursor type on the viewport.
|
| |
| void | onProgressTimer () |
| | This updates the progress bar visually.
|
| |
| void | enableProgress () |
| | This restarts the progress bar.
|
| |
|
|
void | synchronize (IndependentCubeViewport *) |
| |
|
void | trackingChanged (double sample, double line, double lat, double lon, double dn, IndependentCubeViewport *) |
| |
|
void | trackingChanged (double samp, double line, double dn, IndependentCubeViewport *) |
| |
|
void | cantTrack (QString, IndependentCubeViewport *) |
| |
| void | viewportUpdated () |
| | Emitted when viewport updated.
|
| |
| void | viewportClosed (CubeViewport *) |
| | Emitted when viewport is closed.
|
| |
| void | mouseEnter () |
| | Emitted when the mouse enters the viewport.
|
| |
| void | mouseMove (QPoint) |
| | Emitted when the mouse moves.
|
| |
| void | mouseMove (QPoint, Qt::MouseButton) |
| | Emitted when the mouse moves.
|
| |
| void | mouseLeave () |
| | Emitted when the mouse leaves the viewport.
|
| |
| void | mouseButtonPress (QPoint, Qt::MouseButton) |
| | Emitted when mouse button pressed.
|
| |
| void | mouseButtonRelease (QPoint, Qt::MouseButton) |
| | Emitted when mouse button released.
|
| |
| void | mouseDoubleClick (QPoint) |
| | Emitted when double click happens.
|
| |
| void | windowTitleChanged () |
| | Emitted when window title changes.
|
| |
| void | scaleChanged () |
| | Emitted when zoom factor changed just before the repaint event.
|
| |
| void | saveChanges (CubeViewport *) |
| | Emitted when changes should be saved.
|
| |
| void | discardChanges (CubeViewport *) |
| | Emitted when changes should be discarded.
|
| |
| void | screenPixelsChanged () |
| | Emitted when cube pixels that should be on the screen change.
|
| |
| void | progressChanged (int) |
| | Emitted with current progress (0 to 100) when working.
|
| |
| void | progressComplete () |
| | Emitted when the current progress is complete (100)
|
| |
| void | doneWithData (int, const Isis::Brick *) |
| | Emitted when a brick is no longer needed, should only be sent to cube data thread.
|
| |
|
| | IndependentCubeViewport (Cube *cube, CubeDataThread *cdt=0, QWidget *parent=0) |
| |
| bool | eventFilter (QObject *o, QEvent *e) |
| | Event filter to watch for mouse events on viewport.
|
| |
| void | paintEvent (QPaintEvent *e) |
| | Repaint the viewport.
|
| |
| void | restretch (ViewportBuffer *) |
| | This is called by internal viewport buffers when a stretch action should be performed.
|
| |
| virtual void | showEvent (QShowEvent *e) |
| |
| void | setCube (Cube *cube) |
| | This method sets the viewports cube.
|
| |
| int | cubeSamples () const |
| | Return the number of samples in the cube.
|
| |
| int | cubeLines () const |
| | Return the number of lines in the cube.
|
| |
| int | cubeBands () const |
| | Return the number of bands in the cube.
|
| |
| bool | isColor () const |
| |
| bool | isGray () const |
| |
| int | grayBand () const |
| |
| int | redBand () const |
| |
| int | greenBand () const |
| |
| int | blueBand () const |
| |
| double | scale () const |
| |
| bool | cubeShown () const |
| |
| int | comboCount () const |
| |
| int | comboIndex () const |
| |
| void | cubeContentsChanged (QRect rect) |
| | Calle dhwen the contents of the cube changes.
|
| |
| double | fitScale () const |
| | Determine the scale that causes the full cube to fit in the viewport.
|
| |
| double | fitScaleWidth () const |
| | Determine the scale of cube in the width to fit in the viewport.
|
| |
| double | fitScaleHeight () const |
| | Determine the scale of cube in heighth to fit in the viewport.
|
| |
| void | viewportToCube (int x, int y, double &sample, double &line) const |
| | Turns a viewport into a cube.
|
| |
| void | cubeToViewport (double sample, double line, int &x, int &y) const |
| | Turns a cube into a viewport.
|
| |
| void | contentsToCube (int x, int y, double &sample, double &line) const |
| | Turns contents to a cube.
|
| |
| void | cubeToContents (double sample, double line, int &x, int &y) const |
| | Turns a cube into contents.
|
| |
| double | redPixel (int sample, int line) |
| | Gets the red pixel.
|
| |
| double | greenPixel (int sample, int line) |
| | Gets the green pixel.
|
| |
| double | bluePixel (int sample, int line) |
| | Gets the blue pixel.
|
| |
| double | grayPixel (int sample, int line) |
| | Gets the gray pixel.
|
| |
| CubeStretch | grayStretch () const |
| | Return the gray band stretch.
|
| |
| CubeStretch | redStretch () const |
| | Return the red band stretch.
|
| |
| CubeStretch | greenStretch () const |
| | Return the green band stretch.
|
| |
| CubeStretch | blueStretch () const |
| | Return the blue band stretch.
|
| |
| Cube * | cube () const |
| |
| Projection * | projection () const |
| |
| Camera * | camera () const |
| |
| UniversalGroundMap * | universalGroundMap () const |
| |
| Cube * | trackingCube () const |
| |
| void | moveCursor (int x, int y) |
| | Move the cursor by x,y if possible.
|
| |
| bool | cursorInside () const |
| | Is cursor inside viewport.
|
| |
| QPoint | cursorPosition () const |
| | Return the cursor position in the viewport.
|
| |
| void | setCursorPosition (int x, int y) |
| | Set the cursor position to x/y in the viewport.
|
| |
| void | setCaption () |
| | Change the caption on the viewport title bar.
|
| |
| void | setBackground (QColor color) |
| | Sets the background color.
|
| |
| void | setComboCount (int count) |
| | Sets the band bin combo box count.
|
| |
| void | setComboIndex (int index) |
| | Sets the band bin combo box index.
|
| |
| QPixmap | pixmap () |
| | Returns the pixmap.
|
| |
| ViewportBuffer * | grayBuffer () |
| | Returns the gray viewport buffer (Will be NULL if in RGB mode.)
|
| |
| ViewportBuffer * | redBuffer () |
| | Returns the red viewport buffer (Will be NULL if in Gray mode.)
|
| |
| ViewportBuffer * | greenBuffer () |
| | Returns the green viewport buffer (Will be NULL if in Gray mode.)
|
| |
| ViewportBuffer * | blueBuffer () |
| | Returns the blue viewport buffer (Will be NULL if in Gray mode.)
|
| |
| void | bufferUpdated (QRect rect) |
| | This method is called by ViewportBuffer upon successful completion of all operations and gives the appropriate rect to be repainted.
|
| |
| void | paintPixmap () |
| | Paint the whole pixmap.
|
| |
| void | forgetStretches () |
| | Resets all remembered stretches.
|
| |
| void | setAllBandStretches (Stretch stretch) |
| | Sets a stretch for all bands.
|
| |
| CubeDataThread * | cubeDataThread () |
| |
| int | cubeID () |
| |
| void | getAllWhatsThisInfo (Pvl &pWhatsThisPvl) |
| | Get All WhatsThis info - viewport, cube, area in PVL format.
|
| |
| void | getBandFilterName (PvlKeyword &pFilterNameKey) |
| | Get Band Filter name from the Isis cube label.
|
| |
| void | getCubeArea (double &pdStartSample, double &pdEndSample, double &pdStartLine, double &pdEndLine) |
| | Get Cube area corresponding to the viewport's dimension.
|
| |
| bool | confirmClose () |
| | This method should be called during a close event that would cause this viewport to close.
|
| |
| void | setTrackingCube () |
| | Finds the Tracking group from p_cube and stores the tracking cube name so that we can grab it in AdvancedTrackTool and get mosaic information.
|
| |
General purpose Cube display widget.
- Author
- ????-??-?? Eric Hyer
- See also
- CubeViewport
- History
- 2013-02-20 Debbie A. Cook - Changed to use new projection types. References #775.
Definition at line 45 of file IndependentCubeViewport.h.
| void Isis::CubeViewport::setScale |
( |
double | scale | ) |
|
|
slotinherited |
Change the scale of the cube to the given parameter value.
This method will reset the scale value if the value passed in is too large or too small.
- Parameters
-
| scale | Value by which to scale the image. |
- History
- 2010-07-12 Jeannie Walldren - Changed scale maximum value from hard-coded 16 to the max of the viewport width and height. Added scale minimum value of 1/min(samps,lines).
Definition at line 587 of file CubeViewport.cpp.
References contentsToCube(), cubeLines(), cubeSamples(), cubeToContents(), p_blueBuffer, p_grayBuffer, p_greenBuffer, p_redBuffer, p_scale, p_updatingBuffers, paintPixmap(), paintPixmapRects(), scale(), scaleChanged(), screenPixelsChanged(), setCaption(), and updateScrollBars().
Referenced by Isis::FindTool::centerLinkedViewports(), keyPressEvent(), setScale(), setScale(), Isis::ZoomTool::setScale(), Isis::ZoomTool::setScale(), Isis::ZoomTool::setScale(), and showEvent().
