This class is used to modify and manage solve settings for 1 to many BundleObservations. More...

#include <BundleObservationSolveSettings.h>

Collaboration diagram for Isis::BundleObservationSolveSettings:

Classes
class	XmlHandler

Public Types
enum	InstrumentPointingSolveOption { NoPointingFactors = 0, AnglesOnly = 1, AnglesVelocity = 2, AnglesVelocityAcceleration = 3, AllPointingCoefficients = 4 }
	Options for how to solve for instrument pointing. More...

enum	InstrumentPositionSolveOption { NoPositionFactors = 0, PositionOnly = 1, PositionVelocity = 2, PositionVelocityAcceleration = 3, AllPositionCoefficients = 4 }
	Options for how to solve for instrument position. More...

Public Member Functions
	BundleObservationSolveSettings ()
	Constructor with default parameter initializations. More...

	BundleObservationSolveSettings (Project project, XmlStackedHandlerReader xmlReader)
	Construct this BundleObservationSolveSettings object from XML. More...

	BundleObservationSolveSettings (FileName xmlFile, Project project, XmlStackedHandlerReader xmlReader)

	BundleObservationSolveSettings (const BundleObservationSolveSettings &src)
	Constructs a BundleObservationSolveSettings from another one. More...

	~BundleObservationSolveSettings ()
	Destructor. More...

BundleObservationSolveSettings &	operator= (const BundleObservationSolveSettings &src)
	Assigns the state of another BundleObservationSolveSettings to this one. More...

void	initialize ()
	Initializes the default state of this BundleObservationSolveSettings. More...

PvlObject	pvlObject (QString name="") const
	Serializes this BundleObservationSolveSettings into a PvlObject. More...

void	setInstrumentId (QString instrumentId)
	Sets the instrument id for this observation. More...

QString	instrumentId () const
	Accesses the instrument id for this observation. More...

void	addObservationNumber (QString observationNumber)
	Associates an observation number with these solve settings. More...

QSet< QString >	observationNumbers () const
	Returns a list of observation numbers associated with these solve settings. More...

void	setInstrumentPointingSettings (InstrumentPointingSolveOption option, bool solveTwist, int ckDegree=2, int ckSolveDegree=2, bool solvePolynomialOverExisting=false, double anglesAprioriSigma=-1.0, double angularVelocityAprioriSigma=-1.0, double angularAccelerationAprioriSigma=-1.0)
	Sets the instrument pointing settings. More...

InstrumentPointingSolveOption	instrumentPointingSolveOption () const
	Accesses the instrument pointing solve option. More...

bool	solveTwist () const
	Accesses the flag for solving for twist. More...

int	ckDegree () const
	Accesses the degree of polynomial fit to original camera angles (ckDegree). More...

int	ckSolveDegree () const
	Accesses the degree of the camera angles polynomial being fit to in the bundle adjustment (ckSolveDegree). More...

int	numberCameraAngleCoefficientsSolved () const
	Accesses the number of camera angle coefficients in the solution. More...

bool	solvePolyOverPointing () const
	Whether or not the solve polynomial will be fit over the existing pointing polynomial. More...

QList< double >	aprioriPointingSigmas () const
	Accesses the a priori pointing sigmas. More...

SpiceRotation::Source	pointingInterpolationType () const
	Accesses the SpiceRotation interpolation type for the instrument pointing. More...

void	setInstrumentPositionSettings (InstrumentPositionSolveOption option, int spkDegree=2, int spkSolveDegree=2, bool positionOverHermite=false, double positionAprioriSigma=-1.0, double velocityAprioriSigma=-1.0, double accelerationAprioriSigma=-1.0)
	Sets the instrument pointing settings. More...

InstrumentPositionSolveOption	instrumentPositionSolveOption () const
	Accesses the instrument position solve option. More...

int	spkDegree () const
	Accesses the degree of the polynomial fit to the original camera position (spkDegree). More...

int	spkSolveDegree () const
	Accesses the degree of thecamera position polynomial being fit to in the bundle adjustment (spkSolveDegree). More...

int	numberCameraPositionCoefficientsSolved () const
	Accesses the number of camera position coefficients in the solution. More...

bool	solvePositionOverHermite () const
	Whether or not the polynomial for solving will be fit over an existing Hermite spline. More...

QList< double >	aprioriPositionSigmas () const
	Accesses the a priori position sigmas. More...

SpicePosition::Source	positionInterpolationType () const
	Accesses the SpicePosition interpolation type for the spacecraft position. More...

void	save (QXmlStreamWriter &stream, const Project *project) const
	Saves this BundleObservationSolveSettings to an xml stream. More...

QDataStream &	write (QDataStream &stream) const
	Writes this BundleObservationSolveSettings to a stream. More...

QDataStream &	read (QDataStream &stream)
	Reads in the state of a BundleObservationSolveSettings from a stream. More...

Static Public Member Functions
static InstrumentPointingSolveOption	stringToInstrumentPointingSolveOption (QString option)
	Translates a QString InstrumentPointingSolveOption to its enumerated value. More...

static QString	instrumentPointingSolveOptionToString (InstrumentPointingSolveOption option)
	Tranlsates an enumerated InstrumentPointingSolveOption value to its string representation. More...

static InstrumentPositionSolveOption	stringToInstrumentPositionSolveOption (QString option)
	Translates a QString InstrumentPositionSolveOption to its enumerated value. More...

static QString	instrumentPositionSolveOptionToString (InstrumentPositionSolveOption option)
	Translates an enumerated InstrumentPositionSolveOption to its string representation. More...

Private Attributes
QUuid *	m_id
	A unique ID for this object (useful for others to reference this object when saving to disk). More...

QString	m_instrumentId
	The spacecraft instrument id for this observation. More...

QSet< QString >	m_observationNumbers
	Associated observation numbers for these settings. More...

InstrumentPointingSolveOption	m_instrumentPointingSolveOption
	Option for how to solve for instrument pointing. More...

int	m_numberCamAngleCoefSolved
	The number of camera angle coefficients in solution. More...

int	m_ckDegree
	Degree of the polynomial fit to the original camera angles. More...

int	m_ckSolveDegree
	Degree of the camera angles polynomial being fit to in the bundle adjustment. More...

bool	m_solveTwist
	Solve for "twist" angle. More...

bool	m_solvePointingPolynomialOverExisting
	The polynomial will be fit over the existing pointing polynomial. More...

QList< double >	m_anglesAprioriSigma
	The image position a priori sigmas.The size of the list is equal to the number of coefficients in the solution. More...

SpiceRotation::Source	m_pointingInterpolationType
	SpiceRotation interpolation type. More...

InstrumentPositionSolveOption	m_instrumentPositionSolveOption
	Option for how to solve for instrument position. More...

int	m_numberCamPosCoefSolved
	The number of camera position coefficients in the solution. More...

int	m_spkDegree
	Degree of the polynomial fit to the original camera position. More...

int	m_spkSolveDegree
	Degree of the camera position polynomial being fit to in the bundle adjustment. More...

bool	m_solvePositionOverHermiteSpline
	The polynomial will be fit over an existing Hermite spline. More...

QList< double >	m_positionAprioriSigma
	The instrument pointing a priori sigmas. More...

SpicePosition::Source	m_positionInterpolationType
	SpicePosition interpolation types. More...

Detailed Description

This class is used to modify and manage solve settings for 1 to many BundleObservations.

These settings indicate how any associated observations should be solved.

Author: 2014-07-09 Ken Edmundson

History:

2014-07-09 Ken Edmundson - Original version.

2014-07-23 Jeannie Backer - Replace QVectors with QLists. Moved copy constructor above destructor. Moved operator= implementation to cpp file. Added methods to set/get instrument Id. Created setInstrumentPointingSettings() and setInstrumentPositionSettings() methods to check for variable dependencies before setting. Reordered so that all position methods were together and all pointing methods were together. Updated documentation. Added QDataStream >> and << operators and read/write methods. Added unitTest for BundleUtilities BundleObservationSolveSettings class.

2014-07-25 Jeannie Backer - For enums < 4, set solve degrees one less than enum value.

2014-12-02 Jeannie Backer - Undo last modification. While it makes sense, it was causing jigsaw to fail. Brought test coverage of this class to 99.403% scope.

2016-08-03 Jesse Mapel - Added BundleObservationSolveSettingsQsp definition. Fixes #4150.

2016-08-03 Ian Humphrey - Updated documentation and reviewed coding standards. Fixes #4078.

2016-08-18 Jesse Mapel - Changed to no longer inherit from QObject. Fixes #4192.

2016-10-13 Ian Humphrey - Added m_observationNumbers, addObservationNumber(), and observationNumbers() members to associate multiple observation types with these settings. Removed the setFromPvl() method. When re- implemented, it should be put in jigsaw. References #4293.

Todo:

Figure out why solve degree and num coefficients does not match solve option.

Determine whether xml stuff needs a Project pointer.

Determine which XmlStackedHandlerReader constructor is preferred.

Definition at line 84 of file BundleObservationSolveSettings.h.

Member Enumeration Documentation

enum Isis::BundleObservationSolveSettings::InstrumentPointingSolveOption

Options for how to solve for instrument pointing.

Enumerator
NoPointingFactors	Solve for none of the pointing factors.
AnglesOnly	Solve for pointing angles: right ascension, declination and, optionally, twist.
AnglesVelocity	Solve for pointing angles and their angular velocities.
AnglesVelocityAcceleration	Solve for pointing angles, their velocities and their accelerations.
AllPointingCoefficients	Solve for all coefficients in the polynomials fit to the pointing angles.

Definition at line 108 of file BundleObservationSolveSettings.h.

enum Isis::BundleObservationSolveSettings::InstrumentPositionSolveOption

Options for how to solve for instrument position.

Enumerator
NoPositionFactors	Solve for none of the position factors.
PositionOnly	Solve for instrument positions only.
PositionVelocity	Solve for instrument positions and velocities.
PositionVelocityAcceleration	Solve for instrument positions, velocities, and accelerations.
AllPositionCoefficients	Solve for all coefficients in the polynomials fit to the instrument positions.

Definition at line 141 of file BundleObservationSolveSettings.h.

Constructor & Destructor Documentation

Isis::BundleObservationSolveSettings::BundleObservationSolveSettings ( )

Constructor with default parameter initializations.

Definition at line 34 of file BundleObservationSolveSettings.cpp.

References initialize().

Isis::BundleObservationSolveSettings::BundleObservationSolveSettings	(	Project *	project,
		XmlStackedHandlerReader *	xmlReader
	)

Construct this BundleObservationSolveSettings object from XML.

Parameters

bundleSettingsFolder	Where this settings XML resides - /work/.../projectRoot/images/import1
xmlReader	An XML reader that's up to an <bundleSettings> tag.

Definition at line 46 of file BundleObservationSolveSettings.cpp.

References initialize().

Isis::BundleObservationSolveSettings::BundleObservationSolveSettings ( const BundleObservationSolveSettings & other )

Constructs a BundleObservationSolveSettings from another one.

Parameters

other The BundleObservationSolveSettings to copy

Definition at line 113 of file BundleObservationSolveSettings.cpp.

References m_anglesAprioriSigma, m_ckDegree, m_ckSolveDegree, m_id, m_instrumentId, m_instrumentPointingSolveOption, m_instrumentPositionSolveOption, m_numberCamAngleCoefSolved, m_numberCamPosCoefSolved, m_observationNumbers, m_pointingInterpolationType, m_positionAprioriSigma, m_positionInterpolationType, m_solvePointingPolynomialOverExisting, m_solvePositionOverHermiteSpline, m_solveTwist, m_spkDegree, and m_spkSolveDegree.

Isis::BundleObservationSolveSettings::~BundleObservationSolveSettings ( )

Destructor.

Definition at line 143 of file BundleObservationSolveSettings.cpp.

References m_id.

Member Function Documentation

void Isis::BundleObservationSolveSettings::addObservationNumber ( QString observationNumber )

Associates an observation number with these solve settings.

These solve settings are to be applied to any associated observations.

Parameters

observationNumber QString observation number to associate with these settings.

Definition at line 262 of file BundleObservationSolveSettings.cpp.

References m_observationNumbers.

QList< double > Isis::BundleObservationSolveSettings::aprioriPointingSigmas ( ) const

Accesses the a priori pointing sigmas.

Returns: QList<double> Returns a QList of the a priori pointing sigmas

Definition at line 512 of file BundleObservationSolveSettings.cpp.

References m_anglesAprioriSigma.

Referenced by Isis::BundleSolutionInfo::outputHeader(), and pvlObject().

QList< double > Isis::BundleObservationSolveSettings::aprioriPositionSigmas ( ) const

Accesses the a priori position sigmas.

Returns: QList<double> Returns a QList of the a priori position sigmas

Definition at line 746 of file BundleObservationSolveSettings.cpp.

References m_positionAprioriSigma.

Referenced by Isis::BundleSolutionInfo::outputHeader(), and pvlObject().

int Isis::BundleObservationSolveSettings::ckDegree ( ) const

Accesses the degree of polynomial fit to original camera angles (ckDegree).

Returns: int Returns the degree of the polynomial fit to the original camera angles

Definition at line 470 of file BundleObservationSolveSettings.cpp.

References m_ckDegree.

Referenced by Isis::BundleSolutionInfo::outputHeader(), pvlObject(), read(), setInstrumentPointingSettings(), and Isis::BundleObservationSolveSettings::XmlHandler::startElement().

int Isis::BundleObservationSolveSettings::ckSolveDegree ( ) const

Accesses the degree of the camera angles polynomial being fit to in the bundle adjustment (ckSolveDegree).

Returns: int Returns the degree of the camera angles polynomial in the bundle adjustment

Definition at line 481 of file BundleObservationSolveSettings.cpp.

References m_ckSolveDegree.

Referenced by Isis::BundleSolutionInfo::outputHeader(), pvlObject(), read(), setInstrumentPointingSettings(), and Isis::BundleObservationSolveSettings::XmlHandler::startElement().

void Isis::BundleObservationSolveSettings::initialize ( )

Initializes the default state of this BundleObservationSolveSettings.

Definition at line 198 of file BundleObservationSolveSettings.cpp.

References AnglesOnly, m_id, m_instrumentId, NoPositionFactors, setInstrumentPointingSettings(), and setInstrumentPositionSettings().

Referenced by BundleObservationSolveSettings().

QString Isis::BundleObservationSolveSettings::instrumentId ( ) const

Accesses the instrument id for this observation.

Returns: QString Returns the instrument id for this observation

Definition at line 250 of file BundleObservationSolveSettings.cpp.

References m_instrumentId.

Referenced by pvlObject(), save(), and setInstrumentId().

BundleObservationSolveSettings::InstrumentPointingSolveOption Isis::BundleObservationSolveSettings::instrumentPointingSolveOption ( ) const

Accesses the instrument pointing solve option.

Returns: BundleObservationSolveSettings::InstrumentPointingSolveOption Returns the instrument pointing solve option

Definition at line 450 of file BundleObservationSolveSettings.cpp.

References m_instrumentPointingSolveOption.

Referenced by pvlObject().

QString Isis::BundleObservationSolveSettings::instrumentPointingSolveOptionToString ( InstrumentPointingSolveOption option )

static

Tranlsates an enumerated InstrumentPointingSolveOption value to its string representation.

Parameters

option Enumerated InstrumentPointingSolveOption value

Exceptions

IException::Programmer "Unknown pointing solve option enum."

Returns: QString Returns the QString representation of the passed InstrumentPointingSolveOption

Definition at line 342 of file BundleObservationSolveSettings.cpp.

References _FILEINFO_, AllPointingCoefficients, AnglesOnly, AnglesVelocity, AnglesVelocityAcceleration, NoPointingFactors, Isis::IException::Programmer, and Isis::toString().

Referenced by pvlObject(), and save().

BundleObservationSolveSettings::InstrumentPositionSolveOption Isis::BundleObservationSolveSettings::instrumentPositionSolveOption ( ) const

Accesses the instrument position solve option.

Returns: BundleObservationSolveSettings::InstrumentPositionSolveOption Returns the instrument position solve option

Definition at line 694 of file BundleObservationSolveSettings.cpp.

References m_instrumentPositionSolveOption.

Referenced by pvlObject().

QString Isis::BundleObservationSolveSettings::instrumentPositionSolveOptionToString ( InstrumentPositionSolveOption option )

static

Translates an enumerated InstrumentPositionSolveOption to its string representation.

Parameters

option Enumerated InstrumentPositionSolveOption value

Exceptions

IException::Programmer "Unknown position solve option enum."

Returns: QString Returns the QString representation of the passed InstrumentPointingSolveOption

Definition at line 592 of file BundleObservationSolveSettings.cpp.

References _FILEINFO_, AllPositionCoefficients, NoPositionFactors, PositionOnly, PositionVelocity, PositionVelocityAcceleration, Isis::IException::Programmer, and Isis::toString().

Referenced by pvlObject(), and save().

int Isis::BundleObservationSolveSettings::numberCameraAngleCoefficientsSolved ( ) const

Accesses the number of camera angle coefficients in the solution.

Returns: int Returns the number of camera angle coefficients in the solution

Definition at line 491 of file BundleObservationSolveSettings.cpp.

References m_numberCamAngleCoefSolved.

Referenced by Isis::BundleSolutionInfo::outputHeader(), Isis::BundleSolutionInfo::outputImagesCSVHeader(), and pvlObject().

int Isis::BundleObservationSolveSettings::numberCameraPositionCoefficientsSolved ( ) const

Accesses the number of camera position coefficients in the solution.

Returns: int Returns the number of camera position coefficients.

Definition at line 725 of file BundleObservationSolveSettings.cpp.

References m_numberCamPosCoefSolved.

Referenced by Isis::BundleSolutionInfo::outputHeader(), Isis::BundleSolutionInfo::outputImagesCSVHeader(), and pvlObject().

QSet< QString > Isis::BundleObservationSolveSettings::observationNumbers ( ) const

Returns a list of observation numbers associated with these solve settings.

Returns: QSet<QString> Returns a QSet containing the associated observation numbers.

Definition at line 272 of file BundleObservationSolveSettings.cpp.

References m_observationNumbers.

BundleObservationSolveSettings & Isis::BundleObservationSolveSettings::operator= ( const BundleObservationSolveSettings & other )

Assigns the state of another BundleObservationSolveSettings to this one.

Parameters

other The other BundleObservationSolveSettings to assign state from

Todo:: Check this (assignment operator)

Definition at line 160 of file BundleObservationSolveSettings.cpp.

References m_anglesAprioriSigma, m_ckDegree, m_ckSolveDegree, m_id, m_instrumentId, m_instrumentPointingSolveOption, m_instrumentPositionSolveOption, m_numberCamAngleCoefSolved, m_numberCamPosCoefSolved, m_observationNumbers, m_pointingInterpolationType, m_positionAprioriSigma, m_positionInterpolationType, m_solvePointingPolynomialOverExisting, m_solvePositionOverHermiteSpline, m_solveTwist, m_spkDegree, and m_spkSolveDegree.

SpiceRotation::Source Isis::BundleObservationSolveSettings::pointingInterpolationType ( ) const

Accesses the SpiceRotation interpolation type for the instrument pointing.

Returns: SpiceRotation::Source Returns the SpiceRotation interpolation type for pointing

Definition at line 522 of file BundleObservationSolveSettings.cpp.

References m_pointingInterpolationType.

Referenced by pvlObject().

SpicePosition::Source Isis::BundleObservationSolveSettings::positionInterpolationType ( ) const

Accesses the SpicePosition interpolation type for the spacecraft position.

Returns: SpicePosition::Source Returns the SpicePositon interpolation type for position

Definition at line 756 of file BundleObservationSolveSettings.cpp.

References m_positionInterpolationType.

Referenced by pvlObject().

PvlObject Isis::BundleObservationSolveSettings::pvlObject ( QString name = "" ) const

Serializes this BundleObservationSolveSettings into a PvlObject.

Parameters

name	Name of the pvl to create

Returns: PvlObject Returns the serialized settings as a PvlObject

Definition at line 773 of file BundleObservationSolveSettings.cpp.

References Isis::PvlKeyword::addValue(), aprioriPointingSigmas(), aprioriPositionSigmas(), ckDegree(), ckSolveDegree(), instrumentId(), instrumentPointingSolveOption(), instrumentPointingSolveOptionToString(), instrumentPositionSolveOption(), instrumentPositionSolveOptionToString(), Isis::IsSpecial(), m_anglesAprioriSigma, m_positionAprioriSigma, NoPointingFactors, NoPositionFactors, numberCameraAngleCoefficientsSolved(), numberCameraPositionCoefficientsSolved(), pointingInterpolationType(), positionInterpolationType(), solvePolyOverPointing(), solvePositionOverHermite(), solveTwist(), spkDegree(), spkSolveDegree(), and Isis::toString().

Referenced by Isis::BundleSettings::pvlObject().

QDataStream & Isis::BundleObservationSolveSettings::read ( QDataStream & stream )

Reads in the state of a BundleObservationSolveSettings from a stream.

Parameters

stream QDataStream to read state from

Definition at line 1162 of file BundleObservationSolveSettings.cpp.

References ckDegree(), ckSolveDegree(), m_anglesAprioriSigma, m_ckDegree, m_ckSolveDegree, m_id, m_instrumentId, m_instrumentPointingSolveOption, m_instrumentPositionSolveOption, m_numberCamAngleCoefSolved, m_numberCamPosCoefSolved, m_pointingInterpolationType, m_positionAprioriSigma, m_positionInterpolationType, m_solvePointingPolynomialOverExisting, m_solvePositionOverHermiteSpline, m_solveTwist, m_spkDegree, m_spkSolveDegree, spkDegree(), and spkSolveDegree().

Referenced by Isis::operator>>().

void Isis::BundleObservationSolveSettings::save	(	QXmlStreamWriter &	stream,
		const Project *	project
	)		const

Saves this BundleObservationSolveSettings to an xml stream.

Parameters

stream	A QXmlStreamWriter to write to
project	Pointer to the current project

Todo:: Does xml stuff need project???

Definition at line 866 of file BundleObservationSolveSettings.cpp.

References instrumentId(), instrumentPointingSolveOptionToString(), instrumentPositionSolveOptionToString(), Isis::IsSpecial(), m_anglesAprioriSigma, m_ckDegree, m_ckSolveDegree, m_id, m_instrumentPointingSolveOption, m_instrumentPositionSolveOption, m_numberCamAngleCoefSolved, m_numberCamPosCoefSolved, m_pointingInterpolationType, m_positionAprioriSigma, m_positionInterpolationType, m_solvePointingPolynomialOverExisting, m_solvePositionOverHermiteSpline, m_solveTwist, m_spkDegree, m_spkSolveDegree, and Isis::toString().

void Isis::BundleObservationSolveSettings::setInstrumentId ( QString instrumentId )

Sets the instrument id for this observation.

Parameters

instrumentId QString instrument id

Definition at line 240 of file BundleObservationSolveSettings.cpp.

References instrumentId(), and m_instrumentId.

void Isis::BundleObservationSolveSettings::setInstrumentPointingSettings	(	InstrumentPointingSolveOption	option,
		bool	solveTwist,
		int	ckDegree = `2`,
		int	ckSolveDegree = `2`,
		bool	solvePolynomialOverExisting = `false`,
		double	anglesAprioriSigma = `-1.0`,
		double	angularVelocityAprioriSigma = `-1.0`,
		double	angularAccelerationAprioriSigma = `-1.0`
	)

Sets the instrument pointing settings.

Parameters

option	Option for how to solve for instrument pointing
solveTwist	Whether or not to solve for twist
ckDegree
ckSolveDegree
solvePolynomialOverExisting	Indicates whether the polynomial will be fit over an existing pointing polynomial
anglesAprioriSigma	A priori angle values
angularVelocityAprioriSigma	A priori angular velocity
angularAccelerationAprioriSigma	A priori angular acceleration

Definition at line 368 of file BundleObservationSolveSettings.cpp.

References AllPointingCoefficients, ckDegree(), ckSolveDegree(), m_anglesAprioriSigma, m_ckDegree, m_ckSolveDegree, m_instrumentPointingSolveOption, m_numberCamAngleCoefSolved, m_pointingInterpolationType, m_solvePointingPolynomialOverExisting, m_solveTwist, Isis::Null, Isis::SpiceRotation::PolyFunction, Isis::SpiceRotation::PolyFunctionOverSpice, and solveTwist().

Referenced by initialize().

void Isis::BundleObservationSolveSettings::setInstrumentPositionSettings	(	InstrumentPositionSolveOption	option,
		int	spkDegree = `2`,
		int	spkSolveDegree = `2`,
		bool	positionOverHermite = `false`,
		double	positionAprioriSigma = `-1.0`,
		double	velocityAprioriSigma = `-1.0`,
		double	accelerationAprioriSigma = `-1.0`
	)

Sets the instrument pointing settings.

Parameters

option	Option for how to solve the instrument position
spkDegree
spkSolveDegree
positionOverHermite	Whether or not the polynomial will be fit over an existing Hermite spline
positionAprioriSigma	A priori position sigma
velocityAprioriSigma	A priori velocity sigma
accelerationAprioriSigma	A priori acceleration sigma

Definition at line 617 of file BundleObservationSolveSettings.cpp.

References AllPositionCoefficients, m_instrumentPositionSolveOption, m_numberCamPosCoefSolved, m_positionAprioriSigma, m_positionInterpolationType, m_solvePositionOverHermiteSpline, m_spkDegree, m_spkSolveDegree, Isis::Null, Isis::SpicePosition::PolyFunction, Isis::SpicePosition::PolyFunctionOverHermiteConstant, spkDegree(), and spkSolveDegree().

Referenced by initialize().

bool Isis::BundleObservationSolveSettings::solvePolyOverPointing ( ) const

Whether or not the solve polynomial will be fit over the existing pointing polynomial.

Returns: bool Indicates whether the polynomial will be fit over the existing pointing polynomial

Definition at line 502 of file BundleObservationSolveSettings.cpp.

References m_solvePointingPolynomialOverExisting.

Referenced by Isis::BundleSolutionInfo::outputHeader(), and pvlObject().

bool Isis::BundleObservationSolveSettings::solvePositionOverHermite ( ) const

Whether or not the polynomial for solving will be fit over an existing Hermite spline.

Returns: bool Returns whether or not to fit the solve polynomial over an existing Hermite spline

Definition at line 736 of file BundleObservationSolveSettings.cpp.

References m_solvePositionOverHermiteSpline.

Referenced by Isis::BundleSolutionInfo::outputHeader(), and pvlObject().

bool Isis::BundleObservationSolveSettings::solveTwist ( ) const

Accesses the flag for solving for twist.

Returns: bool Returns whether or not to solve for twist

Definition at line 460 of file BundleObservationSolveSettings.cpp.

References m_solveTwist.

Referenced by Isis::BundleSolutionInfo::outputHeader(), pvlObject(), setInstrumentPointingSettings(), and Isis::BundleObservationSolveSettings::XmlHandler::startElement().

int Isis::BundleObservationSolveSettings::spkDegree ( ) const

Accesses the degree of the polynomial fit to the original camera position (spkDegree).

Returns: int Returns the degree of the original camera position polynomial.

Definition at line 704 of file BundleObservationSolveSettings.cpp.

References m_spkDegree.

Referenced by Isis::BundleSolutionInfo::outputHeader(), pvlObject(), read(), setInstrumentPositionSettings(), and Isis::BundleObservationSolveSettings::XmlHandler::startElement().

int Isis::BundleObservationSolveSettings::spkSolveDegree ( ) const

Accesses the degree of thecamera position polynomial being fit to in the bundle adjustment (spkSolveDegree).

Returns: int Returns the degree of the camera position polynomial in the bundle adjustment.

Definition at line 715 of file BundleObservationSolveSettings.cpp.

References m_spkSolveDegree.

Referenced by Isis::BundleSolutionInfo::outputHeader(), pvlObject(), read(), setInstrumentPositionSettings(), and Isis::BundleObservationSolveSettings::XmlHandler::startElement().

BundleObservationSolveSettings::InstrumentPointingSolveOption Isis::BundleObservationSolveSettings::stringToInstrumentPointingSolveOption ( QString option )

static

Translates a QString InstrumentPointingSolveOption to its enumerated value.

Parameters

option QString representation of the instrument pointing solve option

Exceptions

IException::Unknown "Unknown bundle instrument point solve option."

Returns: BundleObservationSolveSettings::InstrumentPointingSolveOption Returns the enumerated value of the instrument pointing solve option

Definition at line 293 of file BundleObservationSolveSettings.cpp.

References _FILEINFO_, AllPointingCoefficients, AnglesOnly, AnglesVelocity, AnglesVelocityAcceleration, NoPointingFactors, and Isis::IException::Unknown.

Referenced by Isis::BundleObservationSolveSettings::XmlHandler::startElement().

BundleObservationSolveSettings::InstrumentPositionSolveOption Isis::BundleObservationSolveSettings::stringToInstrumentPositionSolveOption ( QString option )

static

Translates a QString InstrumentPositionSolveOption to its enumerated value.

Parameters

option QString representation of an instrument position solve option

Exceptions

IExeption::Unknown "Unknown bundle instrument position solve option."

Returns: BundleObservationSolveSettings::InstrumentPositionSolveOption Returns the enumerated value of the instrument position solve option

Definition at line 543 of file BundleObservationSolveSettings.cpp.

References _FILEINFO_, AllPositionCoefficients, NoPositionFactors, PositionOnly, PositionVelocity, PositionVelocityAcceleration, and Isis::IException::Unknown.

Referenced by Isis::BundleObservationSolveSettings::XmlHandler::startElement().

QDataStream & Isis::BundleObservationSolveSettings::write ( QDataStream & stream ) const

Writes this BundleObservationSolveSettings to a stream.

Parameters

stream QDataStream to write state to

Definition at line 1132 of file BundleObservationSolveSettings.cpp.

References m_anglesAprioriSigma, m_ckDegree, m_ckSolveDegree, m_id, m_instrumentId, m_instrumentPointingSolveOption, m_instrumentPositionSolveOption, m_numberCamAngleCoefSolved, m_numberCamPosCoefSolved, m_pointingInterpolationType, m_positionAprioriSigma, m_positionInterpolationType, m_solvePointingPolynomialOverExisting, m_solvePositionOverHermiteSpline, m_solveTwist, m_spkDegree, and m_spkSolveDegree.

Referenced by Isis::operator<<().

Member Data Documentation

QList<double> Isis::BundleObservationSolveSettings::m_anglesAprioriSigma

private

The image position a priori sigmas.The size of the list is equal to the number of coefficients in the solution.

An Isis::Null value implies no weighting will be applied.

Definition at line 222 of file BundleObservationSolveSettings.h.

Referenced by aprioriPointingSigmas(), BundleObservationSolveSettings(), operator=(), pvlObject(), read(), save(), setInstrumentPointingSettings(), and write().

int Isis::BundleObservationSolveSettings::m_ckDegree

private

Degree of the polynomial fit to the original camera angles.

Definition at line 215 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), ckDegree(), operator=(), read(), save(), setInstrumentPointingSettings(), and write().

int Isis::BundleObservationSolveSettings::m_ckSolveDegree

private

Degree of the camera angles polynomial being fit to in the bundle adjustment.

Definition at line 217 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), ckSolveDegree(), operator=(), read(), save(), setInstrumentPointingSettings(), and write().

QUuid* Isis::BundleObservationSolveSettings::m_id

private

A unique ID for this object (useful for others to reference this object when saving to disk).

Definition at line 206 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), initialize(), operator=(), read(), save(), write(), and ~BundleObservationSolveSettings().

QString Isis::BundleObservationSolveSettings::m_instrumentId

private

The spacecraft instrument id for this observation.

Definition at line 207 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), initialize(), instrumentId(), operator=(), read(), setInstrumentId(), and write().

InstrumentPointingSolveOption Isis::BundleObservationSolveSettings::m_instrumentPointingSolveOption

private

Option for how to solve for instrument pointing.

Definition at line 212 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), instrumentPointingSolveOption(), operator=(), read(), save(), setInstrumentPointingSettings(), and write().

InstrumentPositionSolveOption Isis::BundleObservationSolveSettings::m_instrumentPositionSolveOption

private

Option for how to solve for instrument position.

Definition at line 238 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), instrumentPositionSolveOption(), operator=(), read(), save(), setInstrumentPositionSettings(), and write().

int Isis::BundleObservationSolveSettings::m_numberCamAngleCoefSolved

private

The number of camera angle coefficients in solution.

Definition at line 213 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), numberCameraAngleCoefficientsSolved(), operator=(), read(), save(), setInstrumentPointingSettings(), and write().

int Isis::BundleObservationSolveSettings::m_numberCamPosCoefSolved

private

The number of camera position coefficients in the solution.

Definition at line 239 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), numberCameraPositionCoefficientsSolved(), operator=(), read(), save(), setInstrumentPositionSettings(), and write().

QSet<QString> Isis::BundleObservationSolveSettings::m_observationNumbers

private

Associated observation numbers for these settings.

Definition at line 208 of file BundleObservationSolveSettings.h.

Referenced by addObservationNumber(), BundleObservationSolveSettings(), observationNumbers(), and operator=().

SpiceRotation::Source Isis::BundleObservationSolveSettings::m_pointingInterpolationType

private

SpiceRotation interpolation type.

Defined in SpiceRotation.cpp, these types are: 1) Spice: directly from kernels, 2) Nadir: Nadir pointing, 3) Memcache: from cached table, 4) PolyFunction: from nth degree polynomial, 5) PolyFunctionOverSpice: kernels plus nth degree polynomial.

Definition at line 227 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), operator=(), pointingInterpolationType(), read(), save(), setInstrumentPointingSettings(), and write().

QList<double> Isis::BundleObservationSolveSettings::m_positionAprioriSigma

private

The instrument pointing a priori sigmas.

The size of the list is equal to the number of coefficients in the solution. An Isis:Null value implies no weighting will be applied.

Definition at line 247 of file BundleObservationSolveSettings.h.

Referenced by aprioriPositionSigmas(), BundleObservationSolveSettings(), operator=(), pvlObject(), read(), save(), setInstrumentPositionSettings(), and write().

SpicePosition::Source Isis::BundleObservationSolveSettings::m_positionInterpolationType

private

SpicePosition interpolation types.

Defined in SpicePosition.cpp, these types are: 1) Spice: read directly from kernels, 2) Memcache: read from cached table, 3) HermiteCache: read from splined table, 4) PolyFunction: calced from nth degree polynomial, 5) PolyFunctionOverHermiteConstant: read from splined table and adding nth degree polynomial.

Definition at line 252 of file BundleObservationSolveSettings.h.

Referenced by BundleObservationSolveSettings(), operator=(), positionInterpolationType(), read(), save(), setInstrumentPositionSettings(), and write().
