Isis::CameraSkyMap Class Reference

Convert between undistorted focal plane and ra/dec coordinates. More...

#include <CameraSkyMap.h>

Inheritance diagram for Isis::CameraSkyMap:
Inheritance graph
Collaboration diagram for Isis::CameraSkyMap:
Collaboration graph

Public Member Functions

 CameraSkyMap (Camera *parent)
 Constructor a map between focal plane x/y and right acension/declination. More...

virtual ~CameraSkyMap ()
 Destructor. More...

virtual bool SetFocalPlane (const double ux, const double uy, const double uz)
 Compute ra/dec from focal plane coordinate. More...

virtual bool SetSky (const double ra, const double dec)
 Compute undistorted focal plane coordinate from ra/dec. More...

double FocalPlaneX () const
 Return undistorted focal plane x. More...

double FocalPlaneY () const
 Return undistorted focal plane y. More...


Protected Attributes

Camera * p_camera

double p_focalPlaneX

double p_focalPlaneY


Detailed Description

Convert between undistorted focal plane and ra/dec coordinates.

This base class is used to convert between undistorted focal plane coordinates (x/y) in millimeters and sky (ra/dec). This class handles the case of framing cameras.

See Also
Camera
Author
2005-02-08 Jeff Anderson
History:

2005-02-08 Jeff Anderson Original version

2008-07-14 Steven Lambright Added NaifStatus calls

Definition at line 47 of file CameraSkyMap.h.

Constructor & Destructor Documentation

Isis::CameraSkyMap::CameraSkyMap ( Camera *  parent)

Constructor a map between focal plane x/y and right acension/declination.

Parameters
parentparent camera which will use this map

Definition at line 33 of file CameraSkyMap.cpp.

References Isis::Camera::SetSkyMap().

virtual Isis::CameraSkyMap::~CameraSkyMap ( )
inlinevirtual

Destructor.

Definition at line 52 of file CameraSkyMap.h.

Member Function Documentation

double Isis::CameraSkyMap::FocalPlaneX ( ) const
inline

Return undistorted focal plane x.

Definition at line 60 of file CameraSkyMap.h.

Referenced by Isis::Camera::SetRightAscensionDeclination().

double Isis::CameraSkyMap::FocalPlaneY ( ) const
inline

Return undistorted focal plane y.

Definition at line 65 of file CameraSkyMap.h.

Referenced by Isis::Camera::SetRightAscensionDeclination().

bool Isis::CameraSkyMap::SetFocalPlane ( const double  ux,
const double  uy,
const double  uz
)
virtual

Compute ra/dec from focal plane coordinate.

This method will compute the right ascension and declination given an undistorted focal plane coordinate. Note that the ra/dec values can be obtained from the parent camera class passed into the constructor.

Parameters
uxdistorted focal plane x in millimeters
uydistorted focal plane y in millimeters
uzdistorted focal plane z in millimeters
Returns
conversion was successful

Reimplemented in Isis::VimsSkyMap, and Isis::RadarSkyMap.

Definition at line 50 of file CameraSkyMap.cpp.

References Isis::NaifStatus::CheckErrors(), and Isis::Sensor::SetLookDirection().

bool Isis::CameraSkyMap::SetSky ( const double  ra,
const double  dec
)
virtual

Compute undistorted focal plane coordinate from ra/dec.

Parameters
raThe right ascension angle
decThe declination
Returns
conversion was successful
Todo:

what happens if we are looking behind the focal plane?????

what happens if we are looking parallel to the focal plane??

can lookC[2] == zero imply parallel

can this all be solved by restricting the physical size of the focal plane?

Reimplemented in Isis::VimsSkyMap, Isis::LineScanCameraSkyMap, and Isis::RadarSkyMap.

Definition at line 81 of file CameraSkyMap.cpp.

References Isis::Camera::FocalLength().

Referenced by Isis::Camera::SetRightAscensionDeclination().

The documentation for this class was generated from the following files:
