View for displaying footprints of images in a QMos like way. More...

#include <Footprint2DView.h>

Inheritance diagram for Isis::Footprint2DView:

Collaboration diagram for Isis::Footprint2DView:

Public Slots
virtual void	addItem (ProjectItem *item)
	Adds an item to the view. More...

virtual void	addItems (QList< ProjectItem * > items)
	Adds several items to the view. More...

virtual void	removeItem (ProjectItem *item)
	Removes an item to the view. More...

virtual void	removeItems (QList< ProjectItem * > items)
	Removes several items from the view. More...

Signals
void	modifyControlPoint (ControlPoint *controlPoint)

void	deleteControlPoint (ControlPoint *controlPoint)

void	createControlPoint (double latitude, double longitude)

void	controlPointAdded (QString newPointId)

Public Member Functions
	Footprint2DView (Directory directory, QWidget parent=0)
	Constructor. More...

	~Footprint2DView ()
	Destructor. More...

MosaicSceneWidget *	mosaicSceneWidget ()

virtual QList< QAction * >	permToolBarActions ()
	Returns a list of actions for the permanent tool bar. More...

virtual QList< QAction * >	activeToolBarActions ()
	Returns a list of actions for the active tool bar. More...

virtual QList< QAction * >	toolPadActions ()
	Returns a list of actions for the tool pad. More...

QSize	sizeHint () const
	Returns the suggested size for the widget. More...

virtual void	setModel (ProjectItemModel *model)
	Sets the model used by the view. More...

virtual ProjectItemModel *	model ()
	Returns the model used by the view. More...

virtual void	dragEnterEvent (QDragEnterEvent *event)
	Accepts the drag enter event if the internal model can accept the mime data. More...

virtual void	dragMoveEvent (QDragMoveEvent *event)
	Accepts the drag event if the internal model can accept the mime data. More...

virtual void	dropEvent (QDropEvent *event)
	Drops the data into the internal model if it can accept the data. More...

virtual QList< QAction * >	contextMenuActions ()
	Returns a list of actions appropriate for a context menu. More...

virtual QList< QAction * >	fileMenuActions ()
	Returns a list of actions appropriate for a file menu. More...

virtual QList< QAction * >	projectMenuActions ()
	Returns a list of actions appropriate for a project menu. More...

virtual QList< QAction * >	editMenuActions ()
	Returns a list of actions appropriate for an edit menu. More...

virtual QList< QAction * >	viewMenuActions ()
	Returns a list of actions appropriate for a view menu. More...

virtual QList< QAction * >	settingsMenuActions ()
	Returns a list of actions appropriate for a settings menu. More...

virtual QList< QAction * >	helpMenuActions ()
	Returns a list of actions appropriate for a help menu. More...

virtual ProjectItem *	currentItem ()
	Returns the current item of the model. More...

virtual QList< ProjectItem * >	selectedItems ()
	Return the selected items of the model. More...

virtual ProjectItemModel *	internalModel ()
	Returns the internal model of the view. More...

virtual void	setInternalModel (ProjectItemModel *model)
	Sets the internal model of the view. More...

Protected Member Functions
bool	eventFilter (QObject watched, QEvent event)
	Event filter to filter out drag and drop events. More...

Private Slots
void	onItemAdded (ProjectItem *item)
	Slot to connect to the itemAdded signal from the model. More...

void	onItemRemoved (ProjectItem *item)
	Slot to connect to the itemRemoved signal from the model. More...

void	onQueueSelectionChanged ()
	Slot to connect to the queueSelectionChanged signal from a MosiacSceneWidget. More...

Private Attributes
MosaicSceneWidget *	m_sceneWidget
	The scene widget. More...

QMap< Image , ProjectItem >	m_imageItemMap
	Maps images to their items. More...

QToolBar *	m_permToolBar
	The permanent tool bar. More...

QToolBar *	m_activeToolBar
	The active tool bar. More...

ToolPad *	m_toolPad
	The tool pad. More...

QWidgetAction *	m_activeToolBarAction
	Stores the active tool bar. More...

Detailed Description

View for displaying footprints of images in a QMos like way.

Author: 2016-01-13 Jeffrey Covington

History:

2016-01-13 Jeffrey Covington - Original version.

2016-06-27 Ian Humphrey - Minor updates to documentation, checked coding standards. Fixes #4004.

2016-08-25 Adam Paquette - Updated documentation. Fixes #4299.

2016-09-14 Tracie Sucharski - Added signals for mouse clicks for modifying, deleting and creating control points. These are passed on to Directory slots.

2016-10-20 Tracie Sucharski - Added back the capability for choosing either a new view or using an existing view.

Definition at line 59 of file Footprint2DView.h.

Constructor & Destructor Documentation

Isis::Footprint2DView::Footprint2DView	(	Directory *	directory,
		QWidget *	parent = `0`
	)

Constructor.

Parameters

parent Pointer to parent QWidget

Definition at line 56 of file Footprint2DView.cpp.

References Isis::AbstractProjectItemView::internalModel(), m_activeToolBar, m_activeToolBarAction, m_permToolBar, m_sceneWidget, m_toolPad, onItemAdded(), onItemRemoved(), and onQueueSelectionChanged().

Isis::Footprint2DView::~Footprint2DView ( )

Destructor.

Definition at line 129 of file Footprint2DView.cpp.

References m_activeToolBar, m_permToolBar, and m_toolPad.

Member Function Documentation

QList< QAction * > Isis::Footprint2DView::activeToolBarActions ( )

virtual

Returns a list of actions for the active tool bar.

Returns: QList<QAction*> The actions

Reimplemented from Isis::AbstractProjectItemView.

Definition at line 286 of file Footprint2DView.cpp.

References m_activeToolBarAction.

void Isis::AbstractProjectItemView::addItem ( ProjectItem * item )

virtualslotinherited

Adds an item to the view.

The item must be part of the view's model. This method can be overriden in a subclass to filter out unneeded items.

Parameters

[in] item (ProjectItem *) The item to add.

Definition at line 273 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::CubeDnView::addItem(), and Isis::AbstractProjectItemView::addItems().

void Isis::AbstractProjectItemView::addItems ( QList< ProjectItem * > items )

virtualslotinherited

Adds several items to the view.

The items must be a part of the view's model.

Parameters

[in] items (QList<ProjectItem *>) The items to add.

Definition at line 287 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::addItem().

Referenced by Isis::CubeDnViewWorkOrder::syncRedo(), and Isis::Footprint2DViewWorkOrder::syncRedo().

QList< QAction * > Isis::AbstractProjectItemView::contextMenuActions ( )

virtualinherited

Returns a list of actions appropriate for a context menu.

Returns: QList<QAction *> The actions

Definition at line 181 of file AbstractProjectItemView.cpp.

ProjectItem * Isis::AbstractProjectItemView::currentItem ( )

virtualinherited

Returns the current item of the model.

Returns: ProjectItem * The item

Definition at line 251 of file AbstractProjectItemView.cpp.

References Isis::ProjectItemModel::currentItem(), and Isis::AbstractProjectItemView::model().

void Isis::AbstractProjectItemView::dragEnterEvent ( QDragEnterEvent * event )

virtualinherited

Accepts the drag enter event if the internal model can accept the mime data.

Parameters

[in] event (QDragEnterEvent *) The drag event

Definition at line 106 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::internalModel().

Referenced by eventFilter().

void Isis::AbstractProjectItemView::dragMoveEvent ( QDragMoveEvent * event )

virtualinherited

Accepts the drag event if the internal model can accept the mime data.

Parameters

[in] event (QDragMoveEvent *) The drag event

Definition at line 121 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::internalModel().

Referenced by eventFilter().

void Isis::AbstractProjectItemView::dropEvent ( QDropEvent * event )

virtualinherited

Drops the data into the internal model if it can accept the data.

Parameters

[in] event (QDropEvent *) The drop event

Definition at line 135 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::internalModel().

Referenced by eventFilter().

QList< QAction * > Isis::AbstractProjectItemView::editMenuActions ( )

virtualinherited

Returns a list of actions appropriate for an edit menu.

Returns: QList<QAction *> The actions

Reimplemented in Isis::CubeDnView.

Definition at line 211 of file AbstractProjectItemView.cpp.

bool Isis::Footprint2DView::eventFilter	(	QObject *	watched,
		QEvent *	event
	)

protected

Event filter to filter out drag and drop events.

Parameters

[in]	watched	(QObject *) The object being filtered
[in]	event	(QEvent *) The event

Returns: bool True if the event was intercepted

Definition at line 163 of file Footprint2DView.cpp.

References Isis::AbstractProjectItemView::dragEnterEvent(), Isis::AbstractProjectItemView::dragMoveEvent(), and Isis::AbstractProjectItemView::dropEvent().

QList< QAction * > Isis::AbstractProjectItemView::fileMenuActions ( )

virtualinherited

Returns a list of actions appropriate for a file menu.

Returns: QList<QAction *> The actions

Reimplemented in Isis::CubeDnView.

Definition at line 191 of file AbstractProjectItemView.cpp.

QList< QAction * > Isis::AbstractProjectItemView::helpMenuActions ( )

virtualinherited

Returns a list of actions appropriate for a help menu.

Returns: QList<QAction *> The actions

Reimplemented in Isis::CubeDnView.

Definition at line 241 of file AbstractProjectItemView.cpp.

ProjectItemModel * Isis::AbstractProjectItemView::internalModel ( )

virtualinherited

Returns the internal model of the view.

By default it is a proxy model.

Returns: ProjectItemModel * The internal model

Definition at line 95 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::m_internalModel.

Referenced by Isis::AbstractProjectItemView::addItem(), Isis::CubeDnView::CubeDnView(), Isis::AbstractProjectItemView::dragEnterEvent(), Isis::AbstractProjectItemView::dragMoveEvent(), Isis::AbstractProjectItemView::dropEvent(), Footprint2DView(), Isis::AbstractProjectItemView::model(), Isis::CubeDnView::onCubeViewportActivated(), Isis::CubeDnView::onCubeViewportDeleted(), Isis::CubeDnView::onCurrentChanged(), onQueueSelectionChanged(), Isis::ProjectItemTreeView::ProjectItemTreeView(), Isis::AbstractProjectItemView::removeItem(), Isis::ProjectItemTreeView::setInternalModel(), and Isis::AbstractProjectItemView::setModel().

ProjectItemModel * Isis::AbstractProjectItemView::model ( )

virtualinherited

Returns the model used by the view.

If the internal model is a proxy model, it returns the source model.

Returns: ProjectItemModel * The model.

Definition at line 70 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::AbstractProjectItemView::currentItem(), Isis::AbstractProjectItemView::selectedItems(), and Isis::AbstractProjectItemView::setInternalModel().

void Isis::Footprint2DView::onItemAdded ( ProjectItem * item )

privateslot

Slot to connect to the itemAdded signal from the model.

If the item is an image it adds it to the scene.

Parameters

[in] item (ProjectItem *) The item

Definition at line 187 of file Footprint2DView.cpp.

References Isis::ImageList::append(), Isis::Shape::cube(), Isis::ProjectItem::image(), Isis::ProjectItem::isImage(), Isis::ProjectItem::isShape(), m_imageItemMap, m_sceneWidget, and Isis::ProjectItem::shape().

Referenced by Footprint2DView().

void Isis::Footprint2DView::onItemRemoved ( ProjectItem * item )

privateslot

Slot to connect to the itemRemoved signal from the model.

If the item is an image it removes it from the scene.

Parameters

[in] item (ProjectItem *) The item to be removed

Definition at line 220 of file Footprint2DView.cpp.

References Isis::ImageList::append(), Isis::ProjectItem::image(), Isis::ProjectItem::isImage(), m_imageItemMap, and m_sceneWidget.

Referenced by Footprint2DView().

void Isis::Footprint2DView::onQueueSelectionChanged ( )

privateslot

Slot to connect to the queueSelectionChanged signal from a MosiacSceneWidget.

Updates the selection in the model.

Definition at line 247 of file Footprint2DView.cpp.

References Isis::AbstractProjectItemView::internalModel(), m_imageItemMap, m_sceneWidget, Isis::MosaicSceneWidget::selectedImages(), and Isis::ProjectItemModel::selectionModel().

Referenced by Footprint2DView().

QList< QAction * > Isis::Footprint2DView::permToolBarActions ( )

virtual

Returns a list of actions for the permanent tool bar.

Returns: QList<QAction*> The actions

Reimplemented from Isis::AbstractProjectItemView.

Definition at line 276 of file Footprint2DView.cpp.

References m_permToolBar.

QList< QAction * > Isis::AbstractProjectItemView::projectMenuActions ( )

virtualinherited

Returns a list of actions appropriate for a project menu.

Returns: QList<QAction *> The actions

Reimplemented in Isis::CubeDnView.

Definition at line 201 of file AbstractProjectItemView.cpp.

void Isis::AbstractProjectItemView::removeItem ( ProjectItem * item )

virtualslotinherited

Removes an item to the view.

The item must be part of the view's model. This method can be overriden in a subclass to filter out unneeded items.

Parameters

[in] item (ProjectItem *) The item to remove.

Definition at line 301 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::AbstractProjectItemView::removeItems().

void Isis::AbstractProjectItemView::removeItems ( QList< ProjectItem * > items )

virtualslotinherited

Removes several items from the view.

The items must be a part of the view's model.

Parameters

[in] items (QList<ProjectItem *>) The items to remove.

Definition at line 316 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::removeItem().

QList< ProjectItem * > Isis::AbstractProjectItemView::selectedItems ( )

virtualinherited

Return the selected items of the model.

Returns: QList<ProjectItem *> The items

Definition at line 261 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::model(), and Isis::ProjectItemModel::selectedItems().

void Isis::AbstractProjectItemView::setInternalModel ( ProjectItemModel * model )

virtualinherited

Sets the internal model of the view.

Parameters

[in] model (ProjectItemModel *) The new internal model

Reimplemented in Isis::ProjectItemTreeView.

Definition at line 84 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::m_internalModel, and Isis::AbstractProjectItemView::model().

Referenced by Isis::ProjectItemTreeView::setInternalModel().

void Isis::AbstractProjectItemView::setModel ( ProjectItemModel * model )

virtualinherited

Sets the model used by the view.

If the internal model is a proxy model, it sets the source model.

Parameters

[in] model (ProjectItemModel *) The new model

Definition at line 56 of file AbstractProjectItemView.cpp.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::Directory::addCubeDnView(), Isis::Directory::addFootprint2DView(), and Isis::Directory::addProjectItemTreeView().

QList< QAction * > Isis::AbstractProjectItemView::settingsMenuActions ( )

virtualinherited

Returns a list of actions appropriate for a settings menu.

Returns: QList<QAction *> The actions

Reimplemented in Isis::CubeDnView.

Definition at line 231 of file AbstractProjectItemView.cpp.

QSize Isis::Footprint2DView::sizeHint ( ) const

Returns the suggested size for the widget.

Returns: QSize The size

Definition at line 145 of file Footprint2DView.cpp.

QList< QAction * > Isis::Footprint2DView::toolPadActions ( )

virtual

Returns a list of actions for the tool pad.

Returns: QList<QAction*> The actions

Reimplemented from Isis::AbstractProjectItemView.

Definition at line 298 of file Footprint2DView.cpp.

References m_toolPad.

QList< QAction * > Isis::AbstractProjectItemView::viewMenuActions ( )

virtualinherited

Returns a list of actions appropriate for a view menu.

Returns: QList<QAction *> The actions

Reimplemented in Isis::CubeDnView.

Definition at line 221 of file AbstractProjectItemView.cpp.

Member Data Documentation

QToolBar* Isis::Footprint2DView::m_activeToolBar

private

The active tool bar.

Definition at line 94 of file Footprint2DView.h.

Referenced by Footprint2DView(), and ~Footprint2DView().

QWidgetAction* Isis::Footprint2DView::m_activeToolBarAction

private

Stores the active tool bar.

Definition at line 97 of file Footprint2DView.h.

Referenced by activeToolBarActions(), and Footprint2DView().

QMap<Image *, ProjectItem *> Isis::Footprint2DView::m_imageItemMap

private

Maps images to their items.

Definition at line 91 of file Footprint2DView.h.

Referenced by onItemAdded(), onItemRemoved(), and onQueueSelectionChanged().

QToolBar* Isis::Footprint2DView::m_permToolBar

private

The permanent tool bar.

Definition at line 93 of file Footprint2DView.h.

Referenced by Footprint2DView(), permToolBarActions(), and ~Footprint2DView().

MosaicSceneWidget* Isis::Footprint2DView::m_sceneWidget

private

The scene widget.

Definition at line 90 of file Footprint2DView.h.

Referenced by Footprint2DView(), onItemAdded(), onItemRemoved(), and onQueueSelectionChanged().

ToolPad* Isis::Footprint2DView::m_toolPad

private

The tool pad.

Definition at line 95 of file Footprint2DView.h.

Referenced by Footprint2DView(), toolPadActions(), and ~Footprint2DView().

The documentation for this class was generated from the following files:

src/qisis/objs/Footprint2DView/Footprint2DView.h
src/qisis/objs/Footprint2DView/Footprint2DView.cpp

Public Slots

Signals

Public Member Functions

Protected Member Functions

Private Slots

Private Attributes

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
