Isis::FxBinder Class Reference

This is the parent class to the various function classes. More...

#include <InlineCalculator.h>

Inheritance diagram for Isis::FxBinder:

Collaboration diagram for Isis::FxBinder:

Public Member Functions
	FxBinder (const QString &name)
	Constructs a function binder given a name. More...
virtual	~FxBinder ()
	Destroys the FxBinder object. More...
QString	name () const
	The name assigned to this function binder. More...
void	execute ()
	Executes the function. More...
void	operator() ()
	Executes the function. More...
virtual void	dispatch ()=0
	This method defines how to execute this function. More...
virtual QVariant	args ()
	Accesses the arguments for this function. More...

Private Attributes
QString	m_name
	Name of function. More...

Detailed Description

This is the parent class to the various function classes.

Author

2012-07-15 Kris Becker

History:

2012-07-15 Kris Becker - Original version.

Definition at line 155 of file InlineCalculator.h.

Constructor & Destructor Documentation

Isis::FxBinder::FxBinder

(

const QString &

name

)

Constructs a function binder given a name.

Parameters

name	A string containing a name for this function.

Definition at line 690 of file InlineCalculator.cpp.

Isis::FxBinder::~FxBinder ( )

virtual

Destroys the FxBinder object.

Definition at line 697 of file InlineCalculator.cpp.

Member Function Documentation

QVariant Isis::FxBinder::args ( )

virtual

Accesses the arguments for this function.

For scalars and variables, the argument is also the function name.

Returns

QVariant The parameters of this function, as a QVariant.

Definition at line 735 of file InlineCalculator.cpp.

References m_name.

Referenced by Isis::ParameterFx::dispatch().

virtual void Isis::FxBinder::dispatch ( )

pure virtual

This method defines how to execute this function.

This class does not define an implementation for this pure virtual method.

Implemented in Isis::VoidFx, Isis::ParameterFx, and Isis::InlineVoidFx.

Referenced by execute(), and operator()().

void Isis::FxBinder::execute

(

)

Executes the function.

This method is a wrapper for the virtual dispatch method.

Definition at line 715 of file InlineCalculator.cpp.

References dispatch().

QString Isis::FxBinder::name

(

)

const

The name assigned to this function binder.

Returns

QString A string containing the name of this function.

Definition at line 706 of file InlineCalculator.cpp.

References m_name.

void Isis::FxBinder::operator()

(

)

Executes the function.

This method is a wrapper for the virtual dispatch method.

Definition at line 724 of file InlineCalculator.cpp.

References dispatch().

Member Data Documentation

QString Isis::FxBinder::m_name

private

Name of function.

Definition at line 172 of file InlineCalculator.h.

Referenced by args(), and name().

---

The documentation for this class was generated from the following files:

• src/base/objs/InlineCalculator/InlineCalculator.h
• src/base/objs/InlineCalculator/InlineCalculator.cpp
