Isis::ParameterFx Class Reference

This class is used to bind function names with corresponding Calculator functions that take a parameter. More...

#include <InlineCalculator.h>

Inheritance diagram for Isis::ParameterFx:

Collaboration diagram for Isis::ParameterFx:

Public Types
typedef void(InlineCalculator::*	calcOp )(const QVariant &arg)
	Defines an InlineCalculator function that takes arguments. More...

Public Member Functions
	ParameterFx (const QString &name, calcOp function, InlineCalculator *calculator)
	Constructs a Parameter function from the given name (containing the appropriate parameters), InlineCalculator operator, and InlineCalculator. More...
virtual	~ParameterFx ()
	Destroys the ParameterFx object. More...
void	dispatch ()
	Calls the function corresponding to this object using its stored InlineCalculator, InlineCalculator operator, and arguments. More...
QString	name () const
	The name assigned to this function binder. More...
void	execute ()
	Executes the function. More...
void	operator() ()
	Executes the function. More...
virtual QVariant	args ()
	Accesses the arguments for this function. More...

Private Attributes
calcOp	m_func
	The InlineCalculator operator that takes parameters. More...
InlineCalculator *	m_calc
	The InlineCalculator used to evaluate this function. More...

Detailed Description

This class is used to bind function names with corresponding Calculator functions that take a parameter.

Author

2012-07-15 Kris Becker

History:

2012-07-15 Kris Becker - Original version.

Definition at line 208 of file InlineCalculator.h.

Member Typedef Documentation

typedef void(InlineCalculator::* Isis::ParameterFx::calcOp)(const QVariant &arg)

Defines an InlineCalculator function that takes arguments.

Definition at line 211 of file InlineCalculator.h.

Constructor & Destructor Documentation

Isis::ParameterFx::ParameterFx	(	const QString &	name,
		calcOp	function,
		InlineCalculator *	calculator
	)

Constructs a Parameter function from the given name (containing the appropriate parameters), InlineCalculator operator, and InlineCalculator.

Parameters

name	A string containing a name for this function. Note: The name given should include the parameters to be passed into this function.
function	An InlineCalculator operator that takes parameters.
calculator	The InlineCalculator used to evaluate this function.

Definition at line 782 of file InlineCalculator.cpp.

Isis::ParameterFx::~ParameterFx ( )

virtual

Destroys the ParameterFx object.

Definition at line 792 of file InlineCalculator.cpp.

Member Function Documentation

QVariant Isis::FxBinder::args ( )

virtualinherited

Accesses the arguments for this function.

For scalars and variables, the argument is also the function name.

Returns

QVariant The parameters of this function, as a QVariant.

Definition at line 735 of file InlineCalculator.cpp.

References Isis::FxBinder::m_name.

Referenced by dispatch().

void Isis::ParameterFx::dispatch ( )

virtual

Calls the function corresponding to this object using its stored InlineCalculator, InlineCalculator operator, and arguments.

Implements Isis::FxBinder.

Definition at line 801 of file InlineCalculator.cpp.

References Isis::FxBinder::args(), CALL_MEMBER_FN, m_calc, and m_func.

void Isis::FxBinder::execute ( )

inherited

Executes the function.

This method is a wrapper for the virtual dispatch method.

Definition at line 715 of file InlineCalculator.cpp.

References Isis::FxBinder::dispatch().

QString Isis::FxBinder::name ( ) const

inherited

The name assigned to this function binder.

Returns

QString A string containing the name of this function.

Definition at line 706 of file InlineCalculator.cpp.

References Isis::FxBinder::m_name.

void Isis::FxBinder::operator() ( )

inherited

Executes the function.

This method is a wrapper for the virtual dispatch method.

Definition at line 724 of file InlineCalculator.cpp.

References Isis::FxBinder::dispatch().

Member Data Documentation

InlineCalculator* Isis::ParameterFx::m_calc

private

The InlineCalculator used to evaluate this function.

Definition at line 220 of file InlineCalculator.h.

Referenced by dispatch().

calcOp Isis::ParameterFx::m_func

private

The InlineCalculator operator that takes parameters.

Definition at line 219 of file InlineCalculator.h.

Referenced by dispatch().

---

The documentation for this class was generated from the following files:

• src/base/objs/InlineCalculator/InlineCalculator.h
• src/base/objs/InlineCalculator/InlineCalculator.cpp
