#include <Blob.h>

Inheritance diagram for Isis::Blob:

Collaboration diagram for Isis::Blob:

Public Member Functions
	Blob (const QString &name, const QString &type)
	Constructs a Blob object using a name and type. More...

	Blob (const QString &name, const QString &type, const QString &file)
	Constructs a Blob object using a name, type, and reading Pvl values from a file. More...

	Blob (const Blob &other)
	This copies the blob object. More...

Blob &	operator= (const Blob &other)
	This makes the two blob objects exactly the same (copies the blob) More...

virtual	~Blob ()
	Destroys the Blob object. More...

QString	Type () const
	Accessor method that returns a string containing the Blob type. More...

QString	Name () const
	Accessor method that returns a string containing the Blob name. More...

int	Size () const
	Accessor method that returns the number of bytes in the blob data. More...

PvlObject &	Label ()
	Accessor method that returns a PvlObject containing the Blob label. More...

void	Read (const QString &file)
	This method reads Pvl values from a specified file. More...

void	Read (const QString &file, const Pvl &pvlLabels)
	This method reads the given a file and labels. More...

virtual void	Read (const Pvl &pvl, std::istream &is)
	This method reads the Blob data from an open input file stream. More...

void	Write (const QString &file)
	Write the blob data out to a file. More...

void	Write (Pvl &pvl, std::fstream &stm, const QString &detachedFileName="")
	Write the blob data out to a Pvl object. More...

Protected Member Functions
void	Find (const Pvl &pvl)
	This method searches the given Pvl for the Blob by the Blob's type and name. More...

virtual void	ReadInit ()
	This virtual method for classes that inherit Blob. More...

virtual void	ReadData (std::istream &is)
	Read binary data from an input stream into the Blob object. More...

virtual void	WriteInit ()
	This virtual method for classes that inherit Blob. More...

virtual void	WriteData (std::fstream &os)
	Writes blob data to a stream. More...

Protected Attributes
PvlObject	p_blobPvl
	Pvl Blob object. More...

QString	p_blobName
	Name of the Blob object. More...

char *	p_buffer
	Buffer blob data is stored in. More...

BigInt	p_startByte
	Byte blob data starts at in buffer. More...

int	p_nbytes
	Size of blob data (in bytes) More...

QString	p_type
	Type of data stored in the buffer. More...

QString	p_detached
	Used for reading detached blobs. More...

QString	p_labelFile
	The file containing the labels. More...

Detailed Description

Author: ????-??-?? Unknown

Constructor & Destructor Documentation

◆ Blob() [1/3]

Isis::Blob::Blob	(	const QString &	name,
		const QString &	type
	)

Constructs a Blob object using a name and type.

Parameters

name	The blob name
type	The blob type

◆ Blob() [2/3]

Isis::Blob::Blob	(	const QString &	name,
		const QString &	type,
		const QString &	file
	)

Constructs a Blob object using a name, type, and reading Pvl values from a file.

Parameters

name	The blob name
type	The blob type
file	The filename to read from.

References Isis::FileName::expanded().

◆ Blob() [3/3]

Isis::Blob::Blob ( const Blob & other )

This copies the blob object.

Parameters

other Blob to be copied

References p_blobName, p_blobPvl, p_buffer, p_detached, p_labelFile, p_nbytes, p_startByte, and p_type.

◆ ~Blob()

Isis::Blob::~Blob ( )

virtual

Destroys the Blob object.

Member Function Documentation

◆ Find()

void Isis::Blob::Find ( const Pvl & pvl )

protected

This method searches the given Pvl for the Blob by the Blob's type and name.

If found, the start byte, number of bytes are read from the Pvl. Also, if a keyword label pointer is found, the filename for the detached blob is stored and the pointer is removed from the blob pvl.

Parameters

pvl	The Pvl to be searched

References _FILEINFO_, Isis::PvlContainer::isNamed(), Isis::PvlObject::object(), Isis::PvlObject::objects(), and Isis::FileName::path().

◆ Label()

PvlObject & Isis::Blob::Label ( )

Accessor method that returns a PvlObject containing the Blob label.

Returns: PvlObject The label of the blob.

Referenced by Isis::SpiceRotation::CacheLabel(), Isis::SpicePosition::LoadCache(), and Isis::SpiceRotation::LoadCache().

◆ Name()

QString Isis::Blob::Name ( ) const

Accessor method that returns a string containing the Blob name.

Returns: string The name of the blob.

Referenced by Isis::Shape::isFootprintable(), Isis::Image::isFootprintable(), Isis::SpicePosition::LoadCache(), and Isis::Cube::write().

◆ operator=()

Blob & Isis::Blob::operator= ( const Blob & other )

This makes the two blob objects exactly the same (copies the blob)

Parameters

other Blob to be copied

Returns: Copied Blob

References p_blobName, p_blobPvl, p_buffer, p_detached, p_labelFile, p_nbytes, p_startByte, and p_type.

◆ Read() [1/3]

void Isis::Blob::Read ( const QString & file )

This method reads Pvl values from a specified file.

Parameters

file	The filename to read from.

Exceptions

iException::Io	- Unable to open file
iException::Pvl	- Invalid label format

References _FILEINFO_, and Isis::Pvl::read().

Referenced by Isis::History::History(), Isis::OriginalLabel::OriginalLabel(), Isis::OriginalXmlLabel::OriginalXmlLabel(), Isis::History::Read(), Isis::Cube::read(), and Isis::Table::Table().

◆ Read() [2/3]

void Isis::Blob::Read	(	const QString &	file,
		const Pvl &	pvlLabels
	)

This method reads the given a file and labels.

Parameters

file	The filename to read from.
pvlLabels	A Pvl containing the label information.

Exceptions

iException::Io - Unable to open file

References _FILEINFO_, and Isis::Message::FileOpen().

◆ Read() [3/3]

void Isis::Blob::Read	(	const Pvl &	pvl,
		std::istream &	istm
	)

virtual

This method reads the Blob data from an open input file stream.

Parameters

pvl	A Pvl containing the label information.
istm	The input file stream containing the blob data to be read.

Exceptions

iException::Io - Unable to open file

Reimplemented in Isis::History.

References _FILEINFO_, and Isis::Message::FileOpen().

◆ ReadData()

void Isis::Blob::ReadData ( std::istream & stream )

protectedvirtual

Read binary data from an input stream into the Blob object.

Parameters

stream The input stream to read from.

Exceptions

IException::Io - Error reading data from stream

Reimplemented in Isis::ImagePolygon, Isis::Table, and Isis::OriginalXmlLabel.

References _FILEINFO_.

Referenced by Isis::OriginalXmlLabel::ReadData().

◆ ReadInit()

void Isis::Blob::ReadInit ( )

protectedvirtual

This virtual method for classes that inherit Blob.

It is not defined in the Blob class.

Reimplemented in Isis::Table.

◆ Size()

int Isis::Blob::Size ( ) const

Accessor method that returns the number of bytes in the blob data.

Returns: int Number of bytes in the blob data.

◆ Type()

QString Isis::Blob::Type ( ) const

Accessor method that returns a string containing the Blob type.

Returns: string Type of blob.

Referenced by Isis::Shape::isFootprintable(), Isis::Image::isFootprintable(), and Isis::Cube::write().

◆ Write() [1/2]

void Isis::Blob::Write ( const QString & file )

Write the blob data out to a file.

Parameters

file	The filename to write to.

Exceptions

IException::Io	- Unable to open file
IException::Io	- Error preparing to write data to file
IException::Io	- Error creating file

References _FILEINFO_, Isis::PvlObject::addObject(), Isis::PvlObject::findObject(), Isis::toString(), and Isis::Pvl::write().

Referenced by Isis::Cube::write().

◆ Write() [2/2]

void Isis::Blob::Write	(	Pvl &	pvl,
		std::fstream &	stm,
		const QString &	detachedFileName = `""`
	)

Write the blob data out to a Pvl object.

Parameters

pvl	The pvl object to update
stm	stream to write data to
detachedFileName	If the stream is detached from the labels give the name of the file

References Isis::PvlObject::addObject(), Isis::PvlContainer::name(), Isis::PvlObject::object(), Isis::PvlObject::objects(), and Isis::toString().

◆ WriteData()

void Isis::Blob::WriteData ( std::fstream & stream )

protectedvirtual

Writes blob data to a stream.

Parameters

stream Output steam blob data will be written to

Exceptions

IException::Io - Error writing data to stream

Reimplemented in Isis::ImagePolygon, Isis::Table, and Isis::OriginalXmlLabel.

References _FILEINFO_.

◆ WriteInit()

void Isis::Blob::WriteInit ( )

protectedvirtual

This virtual method for classes that inherit Blob.

It is not defined in the Blob class.

Reimplemented in Isis::ImagePolygon, Isis::Table, Isis::History, Isis::OriginalLabel, and Isis::OriginalXmlLabel.

Member Data Documentation

◆ p_blobName

QString Isis::Blob::p_blobName

protected

Name of the Blob object.

Referenced by Blob(), Isis::Table::operator+=(), operator=(), Isis::Table::ReadData(), and Isis::ImagePolygon::ReadData().

◆ p_blobPvl

PvlObject Isis::Blob::p_blobPvl

protected

Pvl Blob object.

Referenced by Blob(), operator=(), Isis::OriginalXmlLabel::OriginalXmlLabel(), Isis::Table::ReadInit(), Isis::Table::Table(), Isis::OriginalXmlLabel::WriteInit(), and Isis::Table::WriteInit().

◆ p_buffer

char* Isis::Blob::p_buffer

protected

Buffer blob data is stored in.

Referenced by Blob(), Isis::GisBlob::GisBlob(), operator=(), Isis::OriginalXmlLabel::ReadData(), Isis::History::ReturnHist(), Isis::OriginalLabel::ReturnLabels(), Isis::GisBlob::setPolygon(), Isis::History::WriteInit(), and Isis::OriginalLabel::WriteInit().

◆ p_detached

QString Isis::Blob::p_detached

protected

Used for reading detached blobs.

Referenced by Blob(), and operator=().

◆ p_labelFile

QString Isis::Blob::p_labelFile

protected

The file containing the labels.

Referenced by Blob(), and operator=().

◆ p_nbytes

int Isis::Blob::p_nbytes

protected

Size of blob data (in bytes)

Referenced by Blob(), Isis::GisBlob::GisBlob(), operator=(), Isis::OriginalXmlLabel::ReadData(), Isis::ImagePolygon::ReadData(), Isis::History::ReturnHist(), Isis::OriginalLabel::ReturnLabels(), Isis::GisBlob::setPolygon(), Isis::ImagePolygon::WriteData(), Isis::OriginalXmlLabel::WriteInit(), Isis::History::WriteInit(), Isis::OriginalLabel::WriteInit(), Isis::Table::WriteInit(), and Isis::ImagePolygon::WriteInit().

◆ p_startByte

BigInt Isis::Blob::p_startByte

protected

Byte blob data starts at in buffer.

Referenced by Blob(), operator=(), Isis::Table::ReadData(), and Isis::ImagePolygon::ReadData().

◆ p_type

QString Isis::Blob::p_type

protected

Type of data stored in the buffer.

Referenced by Blob(), operator=(), and Isis::ImagePolygon::ReadData().

The documentation for this class was generated from the following files:

/usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/base/objs/Blob/Blob.h
/usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/base/objs/Blob/Blob.cpp
