View for displaying footprints of images in a QMos like way. More...

#include <Footprint2DView.h>

Inheritance diagram for Isis::Footprint2DView:

Collaboration diagram for Isis::Footprint2DView:

Public Slots
void	enableControlNetTool (bool value)
	A slot function that is called when directory emits a siganl that an active control network is set. More...

virtual void	addItem (ProjectItem *item)
	Adds an item to the view. More...

virtual void	addItems (QList< ProjectItem *> items)
	Adds several items to the view. More...

virtual void	removeItem (ProjectItem *item)
	Removes an item to the view. More...

virtual void	removeItems (QList< ProjectItem *> items)
	Removes several items from the view. More...

virtual void	disableActions ()
	Disables toolbars and toolpad actions. More...

Signals
void	modifyControlPoint (ControlPoint *controlPoint)

void	deleteControlPoint (ControlPoint *controlPoint)

void	createControlPoint (double latitude, double longitude)

void	redrawMeasures ()

void	controlPointAdded (QString newPointId)

void	windowChangeEvent (bool event)

Public Member Functions
	Footprint2DView (Directory directory, QWidget parent=0)
	Constructor. More...

	~Footprint2DView ()
	Destructor. More...

MosaicSceneWidget *	mosaicSceneWidget ()
	Accessor for the MosaicSceneWidget. More...

ImageFileListWidget *	fileListWidget ()
	Accessor for the FileListWidget. More...

void	load (XmlStackedHandlerReader *xmlReader)
	Loads the Footprint2DView from an XML file. More...

void	save (QXmlStreamWriter &stream, Project *project, FileName newProjectRoot) const
	Save the footprint view widgets (ImageFileListWidget and MosaicSceneWidget to an XML file. More...

virtual QSize	sizeHint () const
	Returns the suggested size. More...

virtual void	setModel (ProjectItemModel *model)
	Sets the model used by the view. More...

virtual ProjectItemModel *	model ()
	Returns the model used by the view. More...

virtual void	dragEnterEvent (QDragEnterEvent *event)
	Accepts the drag enter event if the internal model can accept the mime data. More...

virtual void	dragMoveEvent (QDragMoveEvent *event)
	Accepts the drag event if the internal model can accept the mime data. More...

virtual void	dropEvent (QDropEvent *event)
	Drops the data into the internal model if it can accept the data. More...

virtual void	moveEvent (QMoveEvent *event)

virtual void	resizeEvent (QResizeEvent *event)

virtual void	enterEvent (QEvent *event)
	Enables actions when cursor enters the view. More...

virtual void	leaveEvent (QEvent *event)
	Disables actions when cursor leaves the view. More...

virtual QList< QAction * >	contextMenuActions ()
	Returns a list of actions appropriate for a context menu. More...

virtual ProjectItem *	currentItem ()
	Returns the current item of the model. More...

virtual QList< ProjectItem * >	selectedItems ()
	Return the selected items of the model. More...

virtual ProjectItemModel *	internalModel ()
	Returns the internal model of the view. More...

virtual void	setInternalModel (ProjectItemModel *model)
	Sets the internal model of the view. More...

Protected Member Functions
bool	eventFilter (QObject watched, QEvent event)
	Event filter to filter out drag and drop events. More...

Detailed Description

View for displaying footprints of images in a QMos like way.

Author: 2016-01-13 Jeffrey Covington

Constructor & Destructor Documentation

◆ Footprint2DView()

Isis::Footprint2DView::Footprint2DView	(	Directory *	directory,
		QWidget *	parent = `0`
	)

Constructor.

Parameters

parent (QMainWindow *) Pointer to parent QMainWindow

References Isis::MosaicSceneWidget::addTo(), Isis::MosaicSceneWidget::addToPermanent(), createControlPoint(), deleteControlPoint(), Isis::AbstractProjectItemView::disableActions(), Isis::MosaicSceneWidget::getScene(), Isis::MosaicSceneWidget::getView(), Isis::AbstractProjectItemView::internalModel(), modifyControlPoint(), and redrawMeasures().

◆ ~Footprint2DView()

Isis::Footprint2DView::~Footprint2DView ( )

Destructor.

Member Function Documentation

◆ addItem

void Isis::AbstractProjectItemView::addItem ( ProjectItem * item )

virtualslotinherited

Adds an item to the view.

The item must be part of the view's model. This method can be overridden in a subclass to filter out unneeded items.

Parameters

[in] item (ProjectItem *) The item to add.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::CubeDnView::addItem().

◆ addItems

void Isis::AbstractProjectItemView::addItems ( QList< ProjectItem *> items )

virtualslotinherited

Adds several items to the view.

The items must be a part of the view's model. This method can be overridden in a subclass to filter out unneeded items.

Parameters

[in] items (QList<ProjectItem *>) The items to add.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::CubeDnViewWorkOrder::execute(), and Isis::Footprint2DViewWorkOrder::execute().

◆ contextMenuActions()

QList< QAction * > Isis::AbstractProjectItemView::contextMenuActions ( )

virtualinherited

Returns a list of actions appropriate for a context menu.

Returns: QList<QAction *> The actions

◆ controlPointAdded

void Isis::Footprint2DView::controlPointAdded ( QString newPointId )

signal

◆ createControlPoint

void Isis::Footprint2DView::createControlPoint	(	double	latitude,
		double	longitude
	)

signal

Referenced by Footprint2DView().

◆ currentItem()

ProjectItem * Isis::AbstractProjectItemView::currentItem ( )

virtualinherited

Returns the current item of the model.

Returns: ProjectItem * The item

References Isis::ProjectItemModel::currentItem(), and Isis::AbstractProjectItemView::model().

◆ deleteControlPoint

void Isis::Footprint2DView::deleteControlPoint ( ControlPoint * controlPoint )

signal

Referenced by Footprint2DView().

◆ disableActions

void Isis::AbstractProjectItemView::disableActions ( )

virtualslotinherited

Disables toolbars and toolpad actions.

Referenced by Isis::CnetEditorView::CnetEditorView(), Footprint2DView(), and Isis::AbstractProjectItemView::leaveEvent().

◆ dragEnterEvent()

void Isis::AbstractProjectItemView::dragEnterEvent ( QDragEnterEvent * event )

virtualinherited

Accepts the drag enter event if the internal model can accept the mime data.

Parameters

[in] event (QDragEnterEvent *) The drag event

References Isis::AbstractProjectItemView::internalModel().

Referenced by eventFilter().

◆ dragMoveEvent()

void Isis::AbstractProjectItemView::dragMoveEvent ( QDragMoveEvent * event )

virtualinherited

Accepts the drag event if the internal model can accept the mime data.

Parameters

[in] event (QDragMoveEvent *) The drag event

References Isis::AbstractProjectItemView::internalModel().

Referenced by eventFilter().

◆ dropEvent()

void Isis::AbstractProjectItemView::dropEvent ( QDropEvent * event )

virtualinherited

Drops the data into the internal model if it can accept the data.

Parameters

[in] event (QDropEvent *) The drop event

References Isis::AbstractProjectItemView::internalModel().

Referenced by eventFilter().

◆ enableControlNetTool

void Isis::Footprint2DView::enableControlNetTool ( bool value )

slot

A slot function that is called when directory emits a siganl that an active control network is set.

It enables the control network editor tool in the toolpad.

Parameters

value The boolean that holds if a control network has been set.

References Isis::MosaicControlNetTool::loadNetwork().

◆ enterEvent()

void Isis::AbstractProjectItemView::enterEvent ( QEvent * event )

virtualinherited

Enables actions when cursor enters the view.

Parameters

event The enter event

References Isis::AbstractProjectItemView::enableActions().

◆ eventFilter()

bool Isis::Footprint2DView::eventFilter	(	QObject *	watched,
		QEvent *	event
	)

protected

Event filter to filter out drag and drop events.

Parameters

[in]	watched	(QObject *) The object being filtered
[in]	event	(QEvent *) The event

Returns: bool True if the event was intercepted

References Isis::AbstractProjectItemView::dragEnterEvent(), Isis::AbstractProjectItemView::dragMoveEvent(), and Isis::AbstractProjectItemView::dropEvent().

◆ fileListWidget()

ImageFileListWidget * Isis::Footprint2DView::fileListWidget ( )

Accessor for the FileListWidget.

◆ internalModel()

ProjectItemModel * Isis::AbstractProjectItemView::internalModel ( )

virtualinherited

Returns the internal model of the view.

By default it is a proxy model.

Returns: ProjectItemModel * The internal model

◆ leaveEvent()

void Isis::AbstractProjectItemView::leaveEvent ( QEvent * event )

virtualinherited

Disables actions when cursor leaves the view.

Parameters

event The leave event

References Isis::AbstractProjectItemView::disableActions().

◆ load()

void Isis::Footprint2DView::load ( XmlStackedHandlerReader * xmlReader )

Loads the Footprint2DView from an XML file.

Parameters

xmlReader The reader that takes in and parses the XML file.

References Isis::XmlStackedHandlerReader::pushContentHandler().

◆ model()

ProjectItemModel * Isis::AbstractProjectItemView::model ( )

virtualinherited

Returns the model used by the view.

If the internal model is a proxy model, it returns the source model.

Returns: ProjectItemModel * The model.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::AbstractProjectItemView::currentItem(), Isis::AbstractProjectItemView::selectedItems(), Isis::ProjectItemTreeView::setInternalModel(), Isis::AbstractProjectItemView::setInternalModel(), and Isis::AbstractProjectItemView::setModel().

◆ modifyControlPoint

void Isis::Footprint2DView::modifyControlPoint ( ControlPoint * controlPoint )

signal

Referenced by Footprint2DView().

◆ mosaicSceneWidget()

MosaicSceneWidget * Isis::Footprint2DView::mosaicSceneWidget ( )

Accessor for the MosaicSceneWidget.

Referenced by Isis::Directory::addFootprint2DView().

◆ moveEvent()

void Isis::AbstractProjectItemView::moveEvent ( QMoveEvent * event )

virtualinherited

References Isis::AbstractProjectItemView::windowChangeEvent().

◆ redrawMeasures

void Isis::Footprint2DView::redrawMeasures ( )

signal

Referenced by Footprint2DView().

◆ removeItem

void Isis::AbstractProjectItemView::removeItem ( ProjectItem * item )

virtualslotinherited

Removes an item to the view.

The item must be part of the view's model. This method can be overriden in a subclass to filter out unneeded items.

Parameters

[in] item (ProjectItem *) The item to remove.

References Isis::AbstractProjectItemView::internalModel().

Referenced by Isis::AbstractProjectItemView::removeItems().

◆ removeItems

void Isis::AbstractProjectItemView::removeItems ( QList< ProjectItem *> items )

virtualslotinherited

Removes several items from the view.

The items must be a part of the view's model.

Parameters

[in] items (QList<ProjectItem *>) The items to remove.

References Isis::AbstractProjectItemView::removeItem().

◆ resizeEvent()

void Isis::AbstractProjectItemView::resizeEvent ( QResizeEvent * event )

virtualinherited

References Isis::AbstractProjectItemView::windowChangeEvent().

◆ save()

void Isis::Footprint2DView::save	(	QXmlStreamWriter &	stream,
		Project *	project,
		FileName	newProjectRoot
	)		const

Save the footprint view widgets (ImageFileListWidget and MosaicSceneWidget to an XML file.

Parameters

stream	The XML stream writer
newProjectRoot	The FileName of the project this Directory is attached to.

References Isis::ImageFileListWidget::save(), and Isis::MosaicSceneWidget::save().

Referenced by Isis::Directory::save().

◆ selectedItems()

QList< ProjectItem * > Isis::AbstractProjectItemView::selectedItems ( )

virtualinherited

Return the selected items of the model.

Returns: QList<ProjectItem *> The items

References Isis::AbstractProjectItemView::model(), and Isis::ProjectItemModel::selectedItems().

◆ setInternalModel()

void Isis::AbstractProjectItemView::setInternalModel ( ProjectItemModel * model )

virtualinherited

Sets the internal model of the view.

Parameters

[in] model (ProjectItemModel *) The new internal model

Reimplemented in Isis::ProjectItemTreeView.

References Isis::AbstractProjectItemView::model().

Referenced by Isis::ProjectItemTreeView::setInternalModel().

◆ setModel()

void Isis::AbstractProjectItemView::setModel ( ProjectItemModel * model )

virtualinherited

Sets the model used by the view.

If the internal model is a proxy model, it sets the source model.

Parameters

[in] model (ProjectItemModel *) The new model

References Isis::AbstractProjectItemView::internalModel(), and Isis::AbstractProjectItemView::model().

Referenced by Isis::Directory::addCubeDnView(), Isis::Directory::addFootprint2DView(), and Isis::Directory::addProjectItemTreeView().

◆ sizeHint()

QSize Isis::AbstractProjectItemView::sizeHint ( ) const

virtualinherited

Returns the suggested size.

Returns: QSize The size hint

Reimplemented in Isis::ProjectItemTreeView, and Isis::ControlHealthMonitorView.

◆ windowChangeEvent

void Isis::AbstractProjectItemView::windowChangeEvent ( bool event )

signalinherited

Referenced by Isis::AbstractProjectItemView::moveEvent(), and Isis::AbstractProjectItemView::resizeEvent().

The documentation for this class was generated from the following files:

/usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/qisis/objs/Footprint2DView/Footprint2DView.h
/usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/qisis/objs/Footprint2DView/Footprint2DView.cpp

Public Slots

Signals

Public Member Functions

Protected Member Functions

Detailed Description

Constructor & Destructor Documentation

◆ Footprint2DView()

◆ ~Footprint2DView()

Member Function Documentation

◆ addItem

◆ addItems

◆ contextMenuActions()

◆ controlPointAdded

◆ createControlPoint

◆ currentItem()

◆ deleteControlPoint

◆ disableActions

◆ dragEnterEvent()

◆ dragMoveEvent()

◆ dropEvent()

◆ enableControlNetTool

◆ enterEvent()

◆ eventFilter()

◆ fileListWidget()

◆ internalModel()

◆ leaveEvent()

◆ load()

◆ model()

◆ modifyControlPoint

◆ mosaicSceneWidget()

◆ moveEvent()

◆ redrawMeasures

◆ removeItem

◆ removeItems

◆ resizeEvent()

◆ save()

◆ selectedItems()

◆ setInternalModel()

◆ setModel()

◆ sizeHint()

◆ windowChangeEvent
