Isis 3 Developer Reference
|
|
Isis 3 Developer Reference
|
A colored, grouped cube list. More...
#include <ImageFileListWidget.h>
Public Slots | |
| void | addImages (ImageList *images) |
| This method adds the new images to the tree. More... | |
| void | removeImages (ImageList *images) |
| Removes an imagelist from the FileListWidget. More... | |
| void | clear () |
| void | filterFileList () |
Public Member Functions | |
| ImageFileListWidget (Directory *directory=0, QWidget *parent=0) | |
| Constructor. More... | |
| virtual | ~ImageFileListWidget () |
| Destructor. More... | |
| QProgressBar * | getProgress () |
| This method returns the progress bar. More... | |
| void | fromPvl (PvlObject &pvl) |
| This method loads the state of this class from the pvl. More... | |
| PvlObject | toPvl () const |
| This method writes the state of this class to a pvl. More... | |
| void | load (XmlStackedHandlerReader *xmlReader) |
| This method pushes a new XmlHandler into the parser stack. More... | |
| void | save (QXmlStreamWriter &stream, Project *project, FileName newProjectRoot) const |
| This method saves the FootprintColumns in the project and the settings associated with every column. More... | |
| QList< QAction * > | actions () |
| This method calls ImageTreeWidget::actions() which sets up a QAction that sets a default for the file list columns and returns a QList of QPointers that point to the QAction. More... | |
| QList< QAction * > | getViewActions () |
| This method calls ImageTreeWidget::getViewActions() which returns a list of FootprintColumns. More... | |
| QList< QAction * > | getExportActions () |
| This method creates a new QAction which is connected and when triggered will save the cube list. More... | |
Static Public Member Functions | |
| static QWidget * | getLongHelp (QWidget *fileListContainer=NULL) |
| This method creates a QWidget that displays a long help message explaining the tool. More... | |
Protected Member Functions | |
| void | contextMenuEvent (QContextMenuEvent *event) |
| This method takes an event and gets all of the FootprintColumns, adds them to the menu, then it pops up the menu at the location of event. More... | |
A colored, grouped cube list.
Constructor.
This method sets up the QWidget to show the ImageTreeWidget that is created using directory.
| directory | The directory where you want the ImageTreeWidget to be made |
| parent | The QWidget parent |
References clear(), and filterFileList().
Referenced by getLongHelp().
|
virtual |
Destructor.
This method calls ImageTreeWidget::actions() which sets up a QAction that sets a default for the file list columns and returns a QList of QPointers that point to the QAction.
References Isis::ImageTreeWidget::actions().
Referenced by contextMenuEvent().
|
slot |
This method adds the new images to the tree.
| images | ImageList containing all of the images that need to be added to the tree. |
References Isis::ImageTreeWidget::createGroup(), Isis::ImageTreeWidget::createImageListNameItem(), Isis::ImageTreeWidget::ImagePosition::group(), Isis::ImageTreeWidget::groupInList(), Isis::ImageTreeWidget::ImageGroupType, Isis::ImageTreeWidget::ImageListNameType, Isis::ImageTreeWidget::imagesInView(), Isis::ImageTreeWidget::ImagePosition::index(), Isis::ImageTreeWidget::ImagePosition::isValid(), Isis::ImageList::name(), Isis::ImageTreeWidget::prepCube(), and Isis::ImageTreeWidget::refit().
Referenced by Isis::ImageFileListViewWorkOrder::execute().
|
slot |
Referenced by ImageFileListWidget().
|
protected |
This method takes an event and gets all of the FootprintColumns, adds them to the menu, then it pops up the menu at the location of event.
| event | A QContextMenuEvent that is used to find the position of the mouse. |
References actions(), and Isis::ImageTreeWidget::getViewActions().
|
slot |
References Isis::Image::fileName(), and Isis::ImageTreeWidgetItem::image().
Referenced by ImageFileListWidget().
| void Isis::ImageFileListWidget::fromPvl | ( | PvlObject & | pvl | ) |
This method loads the state of this class from the pvl.
| pvl | The pvl that we are reading the state from. |
| IException::Io | "Unable to read image file's list widget settings from Pvl" |
References _FILEINFO_, Isis::ImageTreeWidget::addGroup(), Isis::ImageTreeWidgetItem::BlankColumn, Isis::IString::Convert(), Isis::ImageTreeWidgetItem::FootprintColumn, Isis::PvlObject::hasKeyword(), Isis::IException::Io, Isis::PvlContainer::name(), Isis::PvlObject::object(), Isis::PvlObject::objects(), Isis::toBool(), Isis::IString::ToQt(), Isis::ImageTreeWidgetItem::treeColumnToString(), and Isis::ImageTreeWidget::updateViewActs().
This method creates a QWidget that displays a long help message explaining the tool.
References ImageFileListWidget().
| QProgressBar * Isis::ImageFileListWidget::getProgress | ( | ) |
This method returns the progress bar.
This method calls ImageTreeWidget::getViewActions() which returns a list of FootprintColumns.
References Isis::ImageTreeWidget::getViewActions().
| void Isis::ImageFileListWidget::load | ( | XmlStackedHandlerReader * | xmlReader | ) |
This method pushes a new XmlHandler into the parser stack.
| xmlReader | This is the parser stack. |
References Isis::XmlStackedHandlerReader::pushContentHandler().
|
slot |
Removes an imagelist from the FileListWidget.
This would normally be handled elsewhere but for IPCE it needs a method to hide images and update the tree.
| ImageList | containing the images to remove from the tree |
References Isis::ImageTreeWidgetItem::image().
| void Isis::ImageFileListWidget::save | ( | QXmlStreamWriter & | stream, |
| Project * | project, | ||
| FileName | newProjectRoot | ||
| ) | const |
This method saves the FootprintColumns in the project and the settings associated with every column.
| stream | The QXmlStreamWriter that saves the FootprintColumns. |
| project | The current project being saved. |
| newProjectRoot | This is not used. |
References Isis::ImageTreeWidgetItem::BlankColumn, Isis::ImageTreeWidgetItem::FootprintColumn, and Isis::ImageTreeWidgetItem::treeColumnToString().
Referenced by Isis::Footprint2DView::save(), and Isis::Directory::save().
| PvlObject Isis::ImageFileListWidget::toPvl | ( | ) | const |
This method writes the state of this class to a pvl.
References Isis::ImageTreeWidgetItem::BlankColumn, Isis::IString::Convert(), Isis::ImageTreeWidgetItem::FootprintColumn, Isis::Image::id(), Isis::ImageTreeWidgetItem::image(), Isis::ImageTreeWidgetItem::NameColumn, Isis::IString::ToQt(), Isis::toString(), and Isis::ImageTreeWidgetItem::treeColumnToString().
