Obtain SPICE information for a spacecraft. More...

#include <Spice.h>

Inheritance diagram for Isis::Spice:

Collaboration diagram for Isis::Spice:

Public Member Functions
	Spice (Pvl &cubeLabel)
	Constructs a Spice object and loads SPICE kernels using information from the label object. More...

	Spice (Cube &cube)
	Constructs a Spice object and loads SPICE kernels using information from the label object. More...

	Spice (Cube &cube, bool noTables)
	Constructs a Spice object. More...

virtual	~Spice ()
	Destroys the Spice object. More...

void	setTime (const iTime &time)
	Sets the ephemeris time and reads the spacecraft and sun position from the kernels at that instant in time. More...

void	instrumentPosition (double p[3]) const
	Returns the spacecraft position in body-fixed frame km units. More...

void	instrumentBodyFixedPosition (double p[3]) const
	Returns the spacecraft position in body-fixed frame km units. More...

void	sunPosition (double p[3]) const
	Fills the input vector with sun position information, in either body-fixed or J2000 reference frame and km units. More...

double	targetCenterDistance () const
	Calculates and returns the distance from the spacecraft to the target center. More...

Longitude	solarLongitude ()
	Returns the solar longitude. More...

void	instrumentBodyFixedVelocity (double v[3]) const
	Returns the spacecraft velocity in body-fixed frame km/sec units. More...

iTime	time () const
	Returns the ephemeris time in seconds which was used to obtain the spacecraft and sun positions. More...

void	radii (Distance r[3]) const
	Returns the radii of the body in km. More...

void	createCache (iTime startTime, iTime endTime, const int size, double tol)
	This method creates an internal cache of spacecraft and sun positions over a specified time range. More...

iTime	cacheStartTime () const
	Accessor method for the cache start time. More...

iTime	cacheEndTime () const
	Accessor method for the cache end time. More...

void	subSpacecraftPoint (double &lat, double &lon)
	Returns the sub-spacecraft latitude/longitude in universal coordinates (0-360 positive east, ocentric) More...

void	subSolarPoint (double &lat, double &lon)
	Returns the sub-solar latitude/longitude in universal coordinates (0-360 positive east, ocentric) More...

Target *	target () const
	Returns a pointer to the target object. More...

QString	targetName () const
	Returns the QString name of the target. More...

iTime	getClockTime (QString clockValue, int sclkCode=-1, bool clockTicks=false)
	This converts the spacecraft clock ticks value (clockValue) to an iTime. More...

SpiceDouble	getDouble (const QString &key, int index=0)
	This returns a value from the NAIF text pool. More...

SpiceInt	getInteger (const QString &key, int index=0)
	This returns a value from the NAIF text pool. More...

QString	getString (const QString &key, int index=0)
	This returns a value from the NAIF text pool. More...

SpicePosition *	sunPosition () const
	Accessor method for the sun position. More...

SpicePosition *	instrumentPosition () const
	Accessor method for the instrument position. More...

SpiceRotation *	bodyRotation () const
	Accessor method for the body rotation. More...

SpiceRotation *	instrumentRotation () const
	Accessor method for the instrument rotation. More...

bool	hasKernels (Pvl &lab)
	Returns true if the kernel group has kernel files. More...

bool	isTimeSet ()
	Returns true if time has been initialized. More...

SpiceInt	naifBodyCode () const
	This returns the NAIF body code of the target indicated in the labels. More...

SpiceInt	naifSpkCode () const
	This returns the NAIF SPK code to use when reading from SPK kernels. More...

SpiceInt	naifCkCode () const
	This returns the NAIF CK code to use when reading from CK kernels. More...

SpiceInt	naifIkCode () const
	This returns the NAIF IK code to use when reading from instrument kernels. More...

SpiceInt	naifSclkCode () const
	This returns the NAIF SCLK code to use when reading from instrument kernels. More...

SpiceInt	naifBodyFrameCode () const
	This returns the NAIF body frame code. More...

PvlObject	getStoredNaifKeywords () const
	This returns the PvlObject that stores all of the requested Naif data and can be a replacement for furnishing text kernels. More...

virtual double	resolution ()
	Virtual method that returns the pixel resolution of the sensor in meters/pix. More...

Protected Types
enum	SpiceValueType { SpiceDoubleType, SpiceStringType, SpiceIntType, SpiceByteCodeType }
	NAIF value primitive type. More...

Protected Member Functions
QVariant	readValue (QString key, SpiceValueType type, int index=0)
	This should be used for reading ALL text naif kernel values. More...

void	storeResult (QString name, SpiceValueType type, QVariant value)

QVariant	getStoredResult (QString name, SpiceValueType type)

void	storeValue (QString key, int index, SpiceValueType type, QVariant value)

QVariant	readStoredValue (QString key, SpiceValueType type, int index)

Protected Attributes
SpiceDouble	m_uB [3]
	This contains the sun position (u) in the bodyfixed reference frame (B). More...

SpiceDouble	m_BJ [3][3]
	This contains the transformation matrix from J2000 (J) to Body fixed (B). More...

Detailed Description

Obtain SPICE information for a spacecraft.

This class initializes standard NAIF SPICE kernels in order to allow queries of a spacecraft's position and attitude at a given time. It also allows for access to the position of the sun and transformation matrices from J2000 to a body-fixed reference frame for a given target (e.g., Mars). The constructor for this class expects a PVL object with the following minimum information:

Group = Instrument
  TargetName = Mars
EndGroup
Group = Kernels
  NaifFrameCode       = -94030
  LeapSecond          = naif0007.tls
  TargetAttitudeShape = pck00006.tpc
  TargetPosition      = de405.bsp
  InstrumentPointing  = (mgs_sc_ab1.bc,
  Instrument          = moc13.ti
  SpacecraftClock     = MGS_SCLKSCET.00045.tsc
  InstrumentPosition  = mgs_ab1.bsp
  InstrumentAddendum  = mocAddendum.ti
EndGroup

This group is typically found in the image labels after it has been run through the program "spiceinit" It is recommended you read NAIF documentation to obtain a better understanding about the various types of SPICE kernels. The NAIF toolkit accesses information from kernels on a last-in-first-out (LIFO) basis. This means that the creation of a second object can cause problems with the first object. To alleviate this problem we have supplied the CreateCache method which should be invoked immediately after the object is constructed. This caches information (spacecraft position, pointing, etc) internally in the object and unloads all NAIF kernels.

Author: 2003-03-13 Jeff Anderson

Member Enumeration Documentation

◆ SpiceValueType

enum Isis::Spice::SpiceValueType

protected

NAIF value primitive type.

Enumerator
SpiceDoubleType	SpiceDouble type.
SpiceStringType	SpiceString type.
SpiceIntType	SpiceInt type.
SpiceByteCodeType	SpiceByteCode type.

Constructor & Destructor Documentation

◆ Spice() [1/3]

Isis::Spice::Spice ( Pvl & lab )

Constructs a Spice object and loads SPICE kernels using information from the label object.

The constructor expects an Instrument and Kernels group to be in the labels.

Parameters

lab	Label containing Instrument and Kernels groups.

References Isis::PvlObject::findGroup().

◆ Spice() [2/3]

Isis::Spice::Spice ( Cube & cube )

Constructs a Spice object and loads SPICE kernels using information from the label object.

The constructor expects an Instrument and Kernels group to be in the labels.

Parameters

lab	Label containing Instrument and Kernels groups.

References Isis::PvlObject::findGroup(), and Isis::Cube::label().

◆ Spice() [3/3]

Isis::Spice::Spice	(	Cube &	cube,
		bool	noTables
	)

Constructs a Spice object.

Parameters

lab	Pvl labels.
noTables	Indicates the use of tables.

References Isis::Cube::label().

◆ ~Spice()

Isis::Spice::~Spice ( )

virtual

Destroys the Spice object.

References Isis::FileName::expanded().

Member Function Documentation

◆ bodyRotation()

SpiceRotation * Isis::Spice::bodyRotation ( ) const

Accessor method for the body rotation.

Returns: iTime Body rotation for the image.

Author: Steven Lambright

Referenced by Isis::Sensor::EmissionAngle(), Isis::RadarGroundMap::GetdXYdPosition(), Isis::RadarGroundMap::GetXY(), Isis::Camera::LocalPhotometricAngles(), Isis::Sensor::lookDirectionJ2000(), Isis::MiniRF::MiniRF(), Isis::Sensor::PhaseAngle(), Isis::RadarGroundMap::SetFocalPlane(), Isis::RadarGroundMap::SetGround(), Isis::Sensor::SetGround(), Isis::Sensor::SetLookDirection(), Isis::Sensor::SetUniversalGround(), and Isis::Sensor::SlantDistance().

◆ cacheEndTime()

iTime Isis::Spice::cacheEndTime ( ) const

Accessor method for the cache end time.

Returns: iTime End time for the image.

Author: Steven Lambright

◆ cacheStartTime()

iTime Isis::Spice::cacheStartTime ( ) const

Accessor method for the cache start time.

Returns: iTime Start time for the image.

Author: Steven Lambright

◆ createCache()

void Isis::Spice::createCache	(	iTime	startTime,
		iTime	endTime,
		const int	size,
		double	tol
	)

This method creates an internal cache of spacecraft and sun positions over a specified time range.

The SPICE kernels are then immediately unloaded. This allows multiple instances of the Spice object to be created as the NAIF toolkit can clash if multiple sets of SPICE kernels are loaded. Note that the cache size is specified as an argument. Therefore, times requested via setTime() which are not directly loaded in the cache will be interpolated. If the instrument position is not cached and cacheSize is greater than 3, the tolerance is passed to the SpicePosition Memcache2HermiteCache() method.

Note: Before this method is called, the private variables m_cacheSize, m_startTime and m_endTime must be set. This is done in the Camera classes using the methods SetCacheSize() and SetStartEndEphemerisTime().

Parameters

startTime	Starting ephemeris time to cache
endTime	Ending ephemeris time to cache
size	Size of the cache.
tol	Tolerance.

Exceptions

Isis::IException::Programmer	- "Argument cacheSize must be greater than zero"
Isis::IException::Programmer	- "Argument startTime must be less than or equal to endTime"
Isis::IException::User	- "This instrument does not support time padding"

References _FILEINFO_, Isis::iTime::Et(), and Isis::FileName::expanded().

Referenced by Isis::CrismCamera::CrismCamera(), Isis::Camera::LoadCache(), and Isis::MiniRF::MiniRF().

◆ getClockTime()

iTime Isis::Spice::getClockTime	(	QString	clockValue,
		int	sclkCode = `-1`,
		bool	clockTicks = `false`
	)

This converts the spacecraft clock ticks value (clockValue) to an iTime.

If the clock ticks value is provided directly, rather than the spacecraft clock string, set clockTicks=true.
Use this when possible because naif calls (such as scs2e_c) cannot be called when not using naif.

References Isis::toString().

Referenced by Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HayabusaAmicaCamera::HayabusaAmicaCamera(), Isis::HayabusaNirsCamera::HayabusaNirsCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::Hyb2OncCamera::Hyb2OncCamera(), Isis::VimsSkyMap::Init(), Isis::VimsGroundMap::Init(), Isis::JunoCamera::JunoCamera(), Isis::KaguyaTcCamera::KaguyaTcCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::MarciCamera::MarciCamera(), Isis::MdisCamera::MdisCamera(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::OsirisRexOcamsCamera::OsirisRexOcamsCamera(), Isis::RosettaOsirisCamera::RosettaOsirisCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::VikingCamera::VikingCamera(), and Isis::VimsCamera::VimsCamera().

◆ getDouble()

SpiceDouble Isis::Spice::getDouble	(	const QString &	key,
		int	index = `0`
	)

This returns a value from the NAIF text pool.

It is a static convience method

Parameters

key	Name of NAIF keyword to obtain from the pool
index	If the keyword is an array, the element to obtain. Defaults to 0

Returns: SpiceDouble Spice double from NAIF text pool

Exceptions

Isis::iException::Io - "Can not find key in instrument kernels."

Referenced by Isis::LroWideAngleCameraFocalPlaneMap::addFilter(), Isis::LroWideAngleCameraDistortionMap::addFilter(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::DawnVirCamera::DawnVirCamera(), Isis::HayabusaAmicaCamera::HayabusaAmicaCamera(), Isis::HayabusaNirsCamera::HayabusaNirsCamera(), Isis::HiresCamera::HiresCamera(), Isis::HrscCamera::HrscCamera(), Isis::Hyb2OncCamera::Hyb2OncCamera(), Isis::RosettaOsirisCamera::initDistortion(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::JunoCamera::JunoCamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::KaguyaTcCamera::KaguyaTcCamera(), Isis::KaguyaTcCameraDistortionMap::KaguyaTcCameraDistortionMap(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::MarciDistortionMap::MarciDistortionMap(), Isis::Mariner10Camera::Mariner10Camera(), Isis::MdisCamera::MdisCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::OsirisRexOcamsCamera::OsirisRexOcamsCamera(), Isis::RosettaOsirisCamera::RosettaOsirisCamera(), Isis::RosettaVirtisCamera::RosettaVirtisCamera(), Isis::KaguyaMiCameraDistortionMap::SetDistortion(), Isis::TaylorCameraDistortionMap::SetDistortion(), Isis::LroNarrowAngleDistortionMap::SetDistortion(), Isis::Camera::SetFocalLength(), Isis::Camera::SetPixelPitch(), Isis::SsiCamera::SsiCamera(), Isis::TgoCassisCamera::TgoCassisCamera(), Isis::TgoCassisDistortionMap::TgoCassisDistortionMap(), and Isis::UvvisCamera::UvvisCamera().

◆ getInteger()

SpiceInt Isis::Spice::getInteger	(	const QString &	key,
		int	index = `0`
	)

This returns a value from the NAIF text pool.

It is a static convience

Parameters

key	Name of NAIF keyword to obtain from the pool
index	If the keyword is an array, the element to obtain. Defaults to 0

Returns: SpiceInt Spice integer from NAIF text pool

Exceptions

Isis::iException::Io - "Can not find key in instrument kernels

Referenced by Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), and Isis::LroWideAngleCamera::LroWideAngleCamera().

◆ getStoredNaifKeywords()

PvlObject Isis::Spice::getStoredNaifKeywords ( ) const

This returns the PvlObject that stores all of the requested Naif data and can be a replacement for furnishing text kernels.

◆ getStoredResult()

QVariant Isis::Spice::getStoredResult	(	QString	name,
		SpiceValueType	type
	)

protected

References Isis::EndianSwapper::Double().

◆ getString()

QString Isis::Spice::getString	(	const QString &	key,
		int	index = `0`
	)

This returns a value from the NAIF text pool.

It is a static convience method

Parameters

key	Name of NAIF keyword to obtain from the pool
index	If the keyword is an array, the element to obtain. Defaults to 0

Returns: QString Value from the NAIF text pool

Exceptions

Isis::IException::Io - "Can not find key in instrument kernels."

Referenced by Isis::LightTimeCorrectionState::checkAberrationCorrection(), Isis::LightTimeCorrectionState::checkLightTimeToSurfaceCorrect(), Isis::LightTimeCorrectionState::checkObserverTargetSwap(), Isis::MdisCamera::MdisCamera(), and Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera().

◆ hasKernels()

bool Isis::Spice::hasKernels ( Pvl & lab )

Returns true if the kernel group has kernel files.

Parameters

lab	Label containing Instrument and Kernels groups.

Returns: bool status of kernel files in the kernel group

References Isis::PvlObject::findGroup(), Isis::PvlContainer::hasKeyword(), and Isis::PvlKeyword::size().

◆ instrumentBodyFixedPosition()

void Isis::Spice::instrumentBodyFixedPosition ( double p[3] ) const

Returns the spacecraft position in body-fixed frame km units.

Parameters

p[]	Spacecraft position

See also: setTime()

Exceptions

Isis::iException::Programmer - "You must call SetTime first"

References _FILEINFO_.

◆ instrumentBodyFixedVelocity()

void Isis::Spice::instrumentBodyFixedVelocity ( double v[3] ) const

Returns the spacecraft velocity in body-fixed frame km/sec units.

Parameters

v[]	Spacecraft velocity

References _FILEINFO_.

◆ instrumentPosition() [1/2]

void Isis::Spice::instrumentPosition ( double p[3] ) const

Returns the spacecraft position in body-fixed frame km units.

Parameters

p[]	Spacecraft position

See also: setTime()

Exceptions

Isis::iException::Programmer - "You must call SetTime first"

Referenced by Isis::RadarGroundMap::GetdXYdPosition(), Isis::RadarGroundMap::GetXY(), Isis::RadarGroundMap::SetFocalPlane(), and Isis::RadarGroundMap::SetGround().

◆ instrumentPosition() [2/2]

SpicePosition * Isis::Spice::instrumentPosition ( ) const

Accessor method for the instrument position.

Returns: iTime Instrument position for the image.

Author: Steven Lambright

Referenced by Isis::Camera::DetectorResolution(), Isis::Sensor::EmissionAngle(), Isis::Camera::LocalPhotometricAngles(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::Mariner10Camera::Mariner10Camera(), Isis::MiniRF::MiniRF(), Isis::Camera::OffNadirAngle(), Isis::Sensor::PhaseAngle(), Isis::Sensor::SetGround(), Isis::Sensor::SetLookDirection(), Isis::Sensor::SetUniversalGround(), Isis::Sensor::SlantDistance(), and Isis::Sensor::SpacecraftAltitude().

◆ instrumentRotation()

SpiceRotation * Isis::Spice::instrumentRotation ( ) const

Accessor method for the instrument rotation.

Returns: iTime Instrument rotation for the image.

Author: Steven Lambright

Referenced by Isis::DawnVirCamera::DawnVirCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::JunoCamera::JunoCamera(), Isis::Sensor::LookDirection(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::Mariner10Camera::Mariner10Camera(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::RosettaVirtisCamera::RosettaVirtisCamera(), Isis::RadarGroundMap::SetFocalPlane(), Isis::RadarGroundMap::SetGround(), Isis::Sensor::SetLookDirection(), Isis::Sensor::SetRightAscensionDeclination(), and Isis::TgoCassisCamera::TgoCassisCamera().

◆ isTimeSet()

bool Isis::Spice::isTimeSet ( )

Returns true if time has been initialized.

Author: 2016-10-19 Kristin Berry

Returns: bool true if time has been set

Referenced by Isis::CameraDetectorMap::SetParent().

◆ naifBodyCode()

SpiceInt Isis::Spice::naifBodyCode ( ) const

This returns the NAIF body code of the target indicated in the labels.

Returns: SpiceInt NAIF body code

Referenced by Isis::Camera::SpkCenterId().

◆ naifBodyFrameCode()

SpiceInt Isis::Spice::naifBodyFrameCode ( ) const

This returns the NAIF body frame code.

It is read from the labels, if it exists. Otherwise, it's calculated by the init() method.

Returns: SpiceInt NAIF body frame code

◆ naifCkCode()

SpiceInt Isis::Spice::naifCkCode ( ) const

This returns the NAIF CK code to use when reading from CK kernels.

Returns: SpiceInt NAIF CK code

◆ naifIkCode()

SpiceInt Isis::Spice::naifIkCode ( ) const

This returns the NAIF IK code to use when reading from instrument kernels.

Returns: SpiceInt NAIF IK code

Referenced by Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::DawnVirCamera::DawnVirCamera(), Isis::HayabusaAmicaCamera::HayabusaAmicaCamera(), Isis::HayabusaNirsCamera::HayabusaNirsCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::Hyb2OncCamera::Hyb2OncCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::JunoCamera::JunoCamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::KaguyaTcCamera::KaguyaTcCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), Isis::MdisCamera::MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::OsirisRexOcamsCamera::OsirisRexOcamsCamera(), Isis::RosettaOsirisCamera::RosettaOsirisCamera(), Isis::RosettaVirtisCamera::RosettaVirtisCamera(), Isis::Camera::SetFocalLength(), Isis::Camera::SetPixelPitch(), Isis::SsiCamera::SsiCamera(), Isis::TgoCassisCamera::TgoCassisCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

◆ naifSclkCode()

SpiceInt Isis::Spice::naifSclkCode ( ) const

This returns the NAIF SCLK code to use when reading from instrument kernels.

Returns: SpiceInt NAIF SCLK code

Referenced by Isis::CrismCamera::CrismCamera().

◆ naifSpkCode()

SpiceInt Isis::Spice::naifSpkCode ( ) const

This returns the NAIF SPK code to use when reading from SPK kernels.

Returns: SpiceInt NAIF SPK code

Referenced by Isis::Camera::SpkTargetId().

◆ radii()

void Isis::Spice::radii ( Distance r[3] ) const

Returns the radii of the body in km.

The radii are obtained from the appropriate SPICE kernel for the body specified by TargetName in the Instrument group of the labels.

Parameters

r[]	Radii of the target in kilometers

Referenced by Isis::Camera::BasicMapping(), Isis::Camera::GroundRange(), Isis::VimsGroundMap::Init(), Isis::MiniRF::MiniRF(), and Isis::RadarGroundMap::SetFocalPlane().

◆ readStoredValue()

QVariant Isis::Spice::readStoredValue	(	QString	key,
		SpiceValueType	type,
		int	index
	)

protected

References Isis::toDouble(), and Isis::toInt().

◆ readValue()

QVariant Isis::Spice::readValue	(	QString	key,
		SpiceValueType	type,
		int	index = `0`
	)

protected

This should be used for reading ALL text naif kernel values.

This will read it from Naif if we're using naif/not attached kernels. If we have attached kernels and a NaifKeywords label object we will grab it from there instead. This allows us to not furnish kernels after spiceinit.

Parameters

key	The naif keyword,value name
type	The naif value's primitive type
index	The index into the naif keyword array to read

References _FILEINFO_.

Referenced by Isis::IdealCamera::IdealCamera().

◆ resolution()

double Isis::Spice::resolution ( )

virtual

Virtual method that returns the pixel resolution of the sensor in meters/pix.

Returns: double Resolution value of 1.0

Reimplemented in Isis::Camera, and Isis::Sensor.

◆ setTime()

void Isis::Spice::setTime ( const iTime & et )

Sets the ephemeris time and reads the spacecraft and sun position from the kernels at that instant in time.

Parameters

et	Ephemeris time (read NAIF documentation for a detailed description)

See also: http://naif.jpl.nasa.gov/naif/

References Isis::iTime::Et().

Referenced by Isis::Sensor::setTime().

◆ solarLongitude()

Longitude Isis::Spice::solarLongitude ( )

Returns the solar longitude.

Returns: double The Solar Longitude

◆ storeResult()

void Isis::Spice::storeResult	(	QString	name,
		SpiceValueType	type,
		QVariant	value
	)

protected

References Isis::EndianSwapper::Double().

◆ storeValue()

void Isis::Spice::storeValue	(	QString	key,
		int	index,
		SpiceValueType	type,
		QVariant	value
	)

protected

References _FILEINFO_, Isis::PvlKeyword::addValue(), Isis::PvlKeyword::size(), and Isis::toString().

Referenced by Isis::IdealCamera::IdealCamera().

◆ subSolarPoint()

void Isis::Spice::subSolarPoint	(	double &	lat,
		double &	lon
	)

Returns the sub-solar latitude/longitude in universal coordinates (0-360 positive east, ocentric)

Parameters

lat	Sub-solar latitude
lon	Sub-solar longitude

See also: setTime()

Exceptions

Isis::IException::Programmer - "You must call SetTime first."

References _FILEINFO_, and Isis::PI.

Referenced by Isis::Sensor::LocalSolarTime(), and Isis::Camera::SunAzimuth().

◆ subSpacecraftPoint()

void Isis::Spice::subSpacecraftPoint	(	double &	lat,
		double &	lon
	)

Returns the sub-spacecraft latitude/longitude in universal coordinates (0-360 positive east, ocentric)

Parameters

lat	Sub-spacecraft latitude
lon	Sub-spacecraft longitude

See also: setTime()

Exceptions

Isis::IException::Programmer - "You must call SetTime first."

References _FILEINFO_, and Isis::PI.

Referenced by Isis::Sensor::SpacecraftAltitude(), and Isis::Camera::SpacecraftAzimuth().

◆ sunPosition() [1/2]

void Isis::Spice::sunPosition ( double p[3] ) const

Fills the input vector with sun position information, in either body-fixed or J2000 reference frame and km units.

Parameters

p[]	Sun position

See also: setTime()

References _FILEINFO_.

◆ sunPosition() [2/2]

SpicePosition * Isis::Spice::sunPosition ( ) const

Accessor method for the sun position.

Returns: iTime Sun position for the image.

Author: Steven Lambright

Referenced by Isis::Sensor::SolarDistance().

◆ target()

Target * Isis::Spice::target ( ) const

Returns a pointer to the target object.

Returns: string

Referenced by Isis::Camera::BasicMapping(), Isis::Camera::basicRingMapping(), Isis::Sensor::Coordinate(), Isis::Sensor::EmissionAngle(), Isis::Sensor::GetLatitude(), Isis::Camera::GetLocalNormal(), Isis::Sensor::GetLongitude(), Isis::Sensor::GetSurfacePoint(), Isis::UniversalGroundMap::GroundRange(), Isis::Sensor::HasSurfaceIntersection(), Isis::Sensor::IgnoreElevationModel(), Isis::Sensor::IncidenceAngle(), Isis::Camera::LoadCache(), Isis::Sensor::LocalRadius(), Isis::Camera::NorthAzimuth(), Isis::Sensor::PhaseAngle(), Isis::VimsGroundMap::SetGround(), Isis::RadarGroundMap::SetGround(), Isis::Sensor::SetGround(), Isis::Camera::SetGround(), Isis::Camera::SetImage(), Isis::Sensor::SetLookDirection(), Isis::Camera::SetRightAscensionDeclination(), Isis::Sensor::setTime(), Isis::Sensor::SetUniversalGround(), Isis::Camera::SetUniversalGround(), Isis::Sensor::SlantDistance(), and Isis::Sensor::SolarDistance().

◆ targetCenterDistance()

double Isis::Spice::targetCenterDistance ( ) const

Calculates and returns the distance from the spacecraft to the target center.

Returns: double Distance to the center of the target from the spacecraft

◆ targetName()

QString Isis::Spice::targetName ( ) const

Returns the QString name of the target.

Returns: QString

References Isis::Target::name().

◆ time()

iTime Isis::Spice::time ( ) const

Returns the ephemeris time in seconds which was used to obtain the spacecraft and sun positions.

Returns: iTime the currently set ephemeris time

Exceptions

IException::Programmer "Unable to retrieve the time Spice::setTime must be called first."

References _FILEINFO_.

Member Data Documentation

◆ m_BJ

SpiceDouble Isis::Spice::m_BJ[3][3]

protected

This contains the transformation matrix from J2000 (J) to Body fixed (B).

Recall that the transpose of this matrix JB will convert from body-fixed to J2000. It is left in protected space so that conversions between double and SpiceDouble do not have to occur in inheriting classes.

◆ m_uB

SpiceDouble Isis::Spice::m_uB[3]

protected

This contains the sun position (u) in the bodyfixed reference frame (B).

It is left protected so that conversions between double and SpiceDouble do not have to occur in inheriting classes. Units are km

Referenced by Isis::Sensor::IncidenceAngle(), Isis::Camera::LocalPhotometricAngles(), and Isis::Sensor::PhaseAngle().

The documentation for this class was generated from the following files:

/usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/base/objs/Spice/Spice.h
/usgs/pkgs/isis3.9.0_docs/ISIS3/isis/src/base/objs/Spice/Spice.cpp

Public Member Functions

Protected Types

Protected Member Functions

Protected Attributes

Detailed Description

Member Enumeration Documentation

◆ SpiceValueType

Constructor & Destructor Documentation

◆ Spice() [1/3]

◆ Spice() [2/3]

◆ Spice() [3/3]

◆ ~Spice()

Member Function Documentation

◆ bodyRotation()

◆ cacheEndTime()

◆ cacheStartTime()

◆ createCache()

◆ getClockTime()

◆ getDouble()

◆ getInteger()

◆ getStoredNaifKeywords()

◆ getStoredResult()

◆ getString()

◆ hasKernels()

◆ instrumentBodyFixedPosition()

◆ instrumentBodyFixedVelocity()

◆ instrumentPosition() [1/2]

◆ instrumentPosition() [2/2]

◆ instrumentRotation()

◆ isTimeSet()

◆ naifBodyCode()

◆ naifBodyFrameCode()

◆ naifCkCode()

◆ naifIkCode()

◆ naifSclkCode()

◆ naifSpkCode()

◆ radii()

◆ readStoredValue()

◆ readValue()

◆ resolution()

◆ setTime()

◆ solarLongitude()

◆ storeResult()

◆ storeValue()

◆ subSolarPoint()

◆ subSpacecraftPoint()

◆ sunPosition() [1/2]

◆ sunPosition() [2/2]

◆ target()

◆ targetCenterDistance()

◆ targetName()

◆ time()

Member Data Documentation

◆ m_BJ

◆ m_uB
