A colored, grouped cube list. More...

#include <ImageFileListWidget.h>

Inheritance diagram for Isis::ImageFileListWidget:

Collaboration diagram for Isis::ImageFileListWidget:

Classes
class	XmlHandler

Public Slots
void	addImages (ImageList *images)
	This method adds the new images to the tree. More...

void	removeImages (ImageList *images)
	Removes an imagelist from the FileListWidget. More...

void	clear ()

void	filterFileList ()

Public Member Functions
	ImageFileListWidget (Directory directory=0, QWidget parent=0)
	Constructor. More...

virtual	~ImageFileListWidget ()
	Destructor. More...

QProgressBar *	getProgress ()
	This method returns the progress bar. More...

void	fromPvl (PvlObject &pvl)
	This method loads the state of this class from the pvl. More...

PvlObject	toPvl () const
	This method writes the state of this class to a pvl. More...

void	load (XmlStackedHandlerReader *xmlReader)
	This method pushes a new XmlHandler into the parser stack. More...

void	save (QXmlStreamWriter &stream, Project *project, FileName newProjectRoot) const
	This method saves the FootprintColumns in the project and the settings associated with every column. More...

QList< QAction * >	actions ()
	This method calls ImageTreeWidget::actions() which sets up a QAction that sets a default for the file list columns and returns a QList of QPointers that point to the QAction. More...

QList< QAction * >	getViewActions ()
	This method calls ImageTreeWidget::getViewActions() which returns a list of FootprintColumns. More...

QList< QAction * >	getExportActions ()
	This method creates a new QAction which is connected and when triggered will save the cube list. More...

Static Public Member Functions
static QWidget *	getLongHelp (QWidget *fileListContainer=NULL)
	This method creates a QWidget that displays a long help message explaining the tool. More...

Protected Member Functions
void	contextMenuEvent (QContextMenuEvent *event)
	This method takes an event and gets all of the FootprintColumns, adds them to the menu, then it pops up the menu at the location of event. More...

Private Slots
void	saveList ()
	This method saves the list to the choosen output file. More...

Private Member Functions
void	save (QXmlStreamWriter &stream, QTreeWidgetItem *itemToWrite) const
	This method saves the QTreeWidgetItem and the settings associated with the QTreeWidgetItem to the stream. More...

ImageTreeWidget::ImagePosition	find (const Image *image) const
	This method takes an image and finds it's position. More...

void	restoreExpandedStates (QVariant expandedStates, QTreeWidgetItem *item)
	This method returns the QTreeWidgetItem to it's expanded state. More...

QVariant	saveExpandedStates (QTreeWidgetItem *item)
	This method saves the the expanded state of item. More...

Private Attributes
QPointer< ProgressBar >	m_progress
	The ProgressBar of the ImageFileListWidget Serialized (file) version of this object. More...

QScopedPointer< PvlObject >	m_serialized

QToolBar *	m_searchToolbar
	Tool bar for the FileList widget to search. More...

QLineEdit *	m_searchLineEdit

QLabel *	m_fileCount

ImageTreeWidget *	m_tree
	Tree item associated with this mosaic item. More...

Directory *	m_directory
	The directory of the project. More...

Detailed Description

A colored, grouped cube list.

Author: 2011-07-29 Steven Lambright

History:: 2011-07-29 Steven Lambright - Expansion state is now stored in the project file. This change will cause older versions of qmos to fail to read newer project files. References #275.

History:: 2011-08-12 Steven Lambright - Added export options, references #342

History:: 2011-08-29 Steven Lambright - Reworded save file list export action, references #342

History:: 2011-09-27 Steven Lambright - Improved user documentation

History:: 2012-06-22 Tracie Sucharski - Adapted from MosaicFileListWidget.

History:: 2012-09-12 Steven Lambright - Added save/load from XML capabilities.

History:: 2012-10-02 Steven Lambright - Added context menu to show/hide the various columns

History:: 2013-03-19 Steven Lambright - Added setDefaultFileListCols().

History:: 2013-06-17 Jeannie Backer, Tracie Sucharski, and Stuart Sides - replaced setDefaultFileListCols() with actions() to call setDefaultFileListCols() from ImageTreeWidget.

History:: 2014-09-05 Kim Oyama - Modified XmlHandler::startElement and save().

History:: 2016-04-28 Tracie Sucharski - Modified to use Qt5 and v006 libraries.

History:: 2016-06-07 Makayla Shepherd - Updated documentation. Fixes #3962.

History:: 2016-09-14 Ian Humphrey - Modified getLongHelp() - replaced deprecated static QPixmap::grabWidget with QWidget::grab (Qt5). Fixes #4304.

History:: 2017-07-18 Cole Neubauer - Added removeImages slot to be able to remove from the ImageFileList in IPCE Fixes #4996

History:: 2017-08-22 Cole Neuabuer - Added ability to search ImageFileListWidget. Fixes #1556

History:: 2018-05-15 Tracie Sucharski - Fixed xml serialization for Ipce project saves. Fixes #5422.

History:: 2018-07-09 Tracie Sucharski - Serialize the objectName for this view so that the view can be re-created with the same objectName for restoring the project state. Qt's save/restoreState use the objectName.

History:: 2018-10-04 Tracie Sucharski - When serializing images for ipce project saving, check for shapes in project if image for given id cannot be found. References #5495.

Definition at line 64 of file ImageFileListWidget.h.

Constructor & Destructor Documentation

◆ ImageFileListWidget()

Isis::ImageFileListWidget::ImageFileListWidget	(	Directory *	directory = `0`,
		QWidget *	parent = `0`
	)

Constructor.

This method sets up the QWidget to show the ImageTreeWidget that is created using directory.

Parameters

directory	The directory where you want the ImageTreeWidget to be made
parent	The QWidget parent

Definition at line 46 of file ImageFileListWidget.cpp.

References m_directory, m_progress, m_searchToolbar, and m_tree.

Referenced by getLongHelp().

◆ ~ImageFileListWidget()

Isis::ImageFileListWidget::~ImageFileListWidget ( )

virtual

Destructor.

Definition at line 98 of file ImageFileListWidget.cpp.

References m_directory, and m_progress.

Member Function Documentation

◆ actions()

QList< QAction * > Isis::ImageFileListWidget::actions ( )

This method calls ImageTreeWidget::actions() which sets up a QAction that sets a default for the file list columns and returns a QList of QPointers that point to the QAction.

Returns: QList<QAction *> The QList of QPointers that point to the QAction set up by ImageTreeWidget::actions().

Definition at line 230 of file ImageFileListWidget.cpp.

References m_tree.

Referenced by contextMenuEvent().

◆ addImages

void Isis::ImageFileListWidget::addImages ( ImageList * images )

slot

This method adds the new images to the tree.

Parameters

images ImageList containing all of the images that need to be added to the tree.

Definition at line 342 of file ImageFileListWidget.cpp.

References find(), m_progress, m_tree, Isis::ImageList::name(), restoreExpandedStates(), and saveExpandedStates().

Referenced by Isis::ImageFileListViewWorkOrder::execute(), and Isis::Footprint2DView::onItemsAdded().

◆ contextMenuEvent()

void Isis::ImageFileListWidget::contextMenuEvent ( QContextMenuEvent * event )

protected

This method takes an event and gets all of the FootprintColumns, adds them to the menu, then it pops up the menu at the location of event.

Parameters

event A QContextMenuEvent that is used to find the position of the mouse.

Definition at line 474 of file ImageFileListWidget.cpp.

References actions(), and m_tree.

◆ find()

ImageTreeWidget::ImagePosition Isis::ImageFileListWidget::find ( const Image * image ) const

private

This method takes an image and finds it's position.

Parameters

image The image we are trying to find.

Returns: ImageTreeWidget::ImagePosition The position of the image.

Definition at line 525 of file ImageFileListWidget.cpp.

References Isis::Image::id(), Isis::PvlKeyword::isNamed(), and Isis::PvlContainer::keywords().

Referenced by addImages().

◆ fromPvl()

void Isis::ImageFileListWidget::fromPvl ( PvlObject & pvl )

This method loads the state of this class from the pvl.

Parameters

pvl	The pvl that we are reading the state from.

Exceptions

IException::Io "Unable to read image file's list widget settings from Pvl"

Definition at line 119 of file ImageFileListWidget.cpp.

References Isis::IString::Convert(), Isis::PvlObject::hasKeyword(), Isis::IException::Io, m_tree, Isis::PvlContainer::name(), Isis::PvlObject::object(), Isis::PvlObject::objects(), Isis::toBool(), and Isis::IString::ToQt().

◆ getExportActions()

QList< QAction * > Isis::ImageFileListWidget::getExportActions ( )

This method creates a new QAction which is connected and when triggered will save the cube list.

Returns: QList<QAction *> The QList of the new QAction.

Definition at line 250 of file ImageFileListWidget.cpp.

References saveList().

◆ getLongHelp()

QWidget * Isis::ImageFileListWidget::getLongHelp ( QWidget * fileListContainer = NULL )

static

This method creates a QWidget that displays a long help message explaining the tool.

Returns: QWidget Returns the message QWidget that was made.

Definition at line 268 of file ImageFileListWidget.cpp.

References ImageFileListWidget().

◆ getProgress()

QProgressBar * Isis::ImageFileListWidget::getProgress ( )

This method returns the progress bar.

Returns: QProgressBar * Returns the ProgressBar

Definition at line 108 of file ImageFileListWidget.cpp.

References m_progress.

◆ getViewActions()

QList< QAction * > Isis::ImageFileListWidget::getViewActions ( )

This method calls ImageTreeWidget::getViewActions() which returns a list of FootprintColumns.

Returns: QList<QAction *> The QList of FootprintColumns.

Definition at line 240 of file ImageFileListWidget.cpp.

References m_tree.

◆ load()

void Isis::ImageFileListWidget::load ( XmlStackedHandlerReader * xmlReader )

This method pushes a new XmlHandler into the parser stack.

Parameters

xmlReader This is the parser stack.

Definition at line 613 of file ImageFileListWidget.cpp.

References Isis::XmlStackedHandlerReader::pushContentHandler().

◆ removeImages

void Isis::ImageFileListWidget::removeImages ( ImageList * images )

slot

Removes an imagelist from the FileListWidget.

This would normally be handled elsewhere but for IPCE it needs a method to hide images and update the tree.

Parameters

ImageList containing the images to remove from the tree

Definition at line 446 of file ImageFileListWidget.cpp.

References m_tree.

Referenced by Isis::Footprint2DView::onItemRemoved(), and Isis::Footprint2DView::onMosItemRemoved().

◆ restoreExpandedStates()

void Isis::ImageFileListWidget::restoreExpandedStates	(	QVariant	expandedStates,
		QTreeWidgetItem *	item
	)

private

This method returns the QTreeWidgetItem to it's expanded state.

Parameters

expandedStates	The expanded state that needs to be restored.
item	The QTreeWidgetItem that will be restored to it's expanded state.

Definition at line 558 of file ImageFileListWidget.cpp.

References Isis::toBool().

Referenced by addImages().

◆ save() [1/2]

void Isis::ImageFileListWidget::save	(	QXmlStreamWriter &	stream,
		Project *	project,
		FileName	newProjectRoot
	)		const

This method saves the FootprintColumns in the project and the settings associated with every column.

Parameters

stream	The QXmlStreamWriter that saves the FootprintColumns.
project	The current project being saved.
newProjectRoot	This is not used.

Definition at line 626 of file ImageFileListWidget.cpp.

References m_tree.

Referenced by Isis::Directory::save(), Isis::Footprint2DView::save(), and save().

◆ save() [2/2]

void Isis::ImageFileListWidget::save	(	QXmlStreamWriter &	stream,
		QTreeWidgetItem *	itemToWrite
	)		const

private

This method saves the QTreeWidgetItem and the settings associated with the QTreeWidgetItem to the stream.

Parameters

stream	The stream that is saving the QTreeWidgetItem and the settings.
itemToWrite	The QTreeWidgetItem that is being saved.

Definition at line 689 of file ImageFileListWidget.cpp.

References Isis::Image::id(), m_tree, and save().

◆ saveExpandedStates()

QVariant Isis::ImageFileListWidget::saveExpandedStates ( QTreeWidgetItem * item )

private

This method saves the the expanded state of item.

Parameters

item	The QTreeWidgetItem that we will save the expanded state of.

Returns: QVariant The expanded state of item.

Definition at line 589 of file ImageFileListWidget.cpp.

Referenced by addImages().

◆ saveList

void Isis::ImageFileListWidget::saveList ( )

privateslot

This method saves the list to the choosen output file.

Definition at line 494 of file ImageFileListWidget.cpp.

References Isis::Image::fileName(), m_tree, and Isis::TextFile::PutLine().

Referenced by getExportActions().

◆ toPvl()

PvlObject Isis::ImageFileListWidget::toPvl ( ) const

This method writes the state of this class to a pvl.

Returns: PvlObject The pvl that we are writing too.

Definition at line 183 of file ImageFileListWidget.cpp.

References Isis::IString::Convert(), Isis::Image::id(), m_tree, Isis::IString::ToQt(), and Isis::toString().

Member Data Documentation

◆ m_directory

Directory* Isis::ImageFileListWidget::m_directory

private

The directory of the project.

Definition at line 137 of file ImageFileListWidget.h.

Referenced by ImageFileListWidget(), and ~ImageFileListWidget().

◆ m_progress

QPointer<ProgressBar> Isis::ImageFileListWidget::m_progress

private

The ProgressBar of the ImageFileListWidget Serialized (file) version of this object.

Definition at line 127 of file ImageFileListWidget.h.

Referenced by addImages(), getProgress(), ImageFileListWidget(), and ~ImageFileListWidget().

◆ m_searchToolbar

QToolBar* Isis::ImageFileListWidget::m_searchToolbar

private

Tool bar for the FileList widget to search.

Definition at line 131 of file ImageFileListWidget.h.

Referenced by ImageFileListWidget().

◆ m_tree

ImageTreeWidget* Isis::ImageFileListWidget::m_tree

private

Tree item associated with this mosaic item.

Definition at line 136 of file ImageFileListWidget.h.

Referenced by actions(), addImages(), contextMenuEvent(), fromPvl(), getViewActions(), ImageFileListWidget(), removeImages(), save(), saveList(), and toPvl().

The documentation for this class was generated from the following files:

src/qisis/objs/ImageFileListWidget/ImageFileListWidget.h
src/qisis/objs/ImageFileListWidget/ImageFileListWidget.cpp

Classes

Public Slots

Public Member Functions

Static Public Member Functions

Protected Member Functions

Private Slots

Private Member Functions

Private Attributes

Detailed Description

Constructor & Destructor Documentation

◆ ImageFileListWidget()

◆ ~ImageFileListWidget()

Member Function Documentation

◆ actions()

◆ addImages

◆ contextMenuEvent()

◆ find()

◆ fromPvl()

◆ getExportActions()

◆ getLongHelp()

◆ getProgress()

◆ getViewActions()

◆ load()

◆ removeImages

◆ restoreExpandedStates()

◆ save() [1/2]

◆ save() [2/2]

◆ saveExpandedStates()

◆ saveList

◆ toPvl()

Member Data Documentation

◆ m_directory

◆ m_progress

◆ m_searchToolbar

◆ m_tree
