Ipce (Qnet) tool operations. More...

#include <IpceTool.h>

Inheritance diagram for Isis::IpceTool:

Collaboration diagram for Isis::IpceTool:

Public Slots
void	refresh ()
	Refresh all necessary widgets in IpceTool including the PointEditor and CubeViewports. More...

void	activate (bool)
	Activates the tool. More...

virtual void	updateTool ()
	Updates the tool. More...

void	setCubeViewport (MdiCubeViewport *cvp)
	Sets the current viewport to the given cvp. More...

Signals
void	modifyControlPoint (ControlPoint *controlPoint)

void	deleteControlPoint (ControlPoint *controlPoint)

void	createControlPoint (double latitude, double longitude, Cube *cube, bool isGroundSource=false)

void	clearWarningSignal ()

void	toolActivated ()

void	viewportChanged ()

Public Member Functions
	IpceTool (Directory directory, QWidget parent)
	Ipce (Qnet) tool - Handles mouse button actions and drawing control points on viewports. More...

void	setControlNet (ControlNet *controlNet)

void	paintViewport (MdiCubeViewport cvp, QPainter painter)

void	addTo (ViewportMainWindow *mw)
	Adds the tool to the application. More...

void	addTo (ToolPad *toolpad)
	Adds the tool to the toolpad. More...

virtual void	addTo (QMenu *menu)

virtual void	addTo (Workspace *ws)
	Adds the given workspace to the cubeviewport list. More...

virtual QString	menuName () const
	Anytime a tool is created, you must give it a name for the menu. More...

virtual void	addToPermanent (QToolBar *toolbar)

void	addToActive (QToolBar *toolbar)

QString	toolIconDir () const
	returns the path to the icon directory. More...

RubberBandTool *	rubberBandTool ()

void	setList (ToolList *currentList)

Protected Types
typedef QVector < MdiCubeViewport * >	CubeViewportList
	A list of cubeviewports. More...

Protected Slots
void	mouseButtonRelease (QPoint p, Qt::MouseButton s)
	Handle mouse events on CubeViewport. More...

virtual void	rubberBandComplete ()

virtual void	screenPixelsChanged ()
	This is called when actions change which pixels from the cube are displayed. More...

virtual void	mouseEnter ()

virtual void	mouseMove (QPoint p)

virtual void	mouseMove (QPoint p, Qt::MouseButton)

virtual void	mouseLeave ()

virtual void	mouseDoubleClick (QPoint p)

virtual void	mouseButtonPress (QPoint p, Qt::MouseButton s)

virtual void	updateMeasure ()

virtual void	scaleChanged ()

virtual void	stretchRequested (MdiCubeViewport *, int)

void	registerTool (MdiCubeViewport *viewport)
	Registers the tool to the viewport. More...

Protected Member Functions
QAction *	toolPadAction (ToolPad *pad)
	Adds the Ipce tool action to the tool pad. More...

MdiCubeViewport *	cubeViewport () const
	Return the current cubeviewport. More...

CubeViewportList *	cubeViewportList () const
	Return the list of cubeviewports. More...

virtual QWidget *	createToolBarWidget (QStackedWidget *parent)
	Anytime a tool is created, you must add it to the tool bar. More...

virtual void	addConnections (MdiCubeViewport *cvp)
	Anytime a tool is created, you must add the connections for it. More...

virtual void	removeConnections (MdiCubeViewport *cvp)
	Anytime a tool is created, you must be able to remove it's connections. More...

virtual void	enableRubberBandTool ()
	Anytime a tool is created, you may use the rubber band tool. More...

Workspace *	workspace ()

Private Slots
void	paintAllViewports (QString pointId)
	This method will repaint the given Point ID in each viewport Note: The pointId parameter is here even though it's not used because the signal (IpceTool::editPointChanged connected to this slot is also connected to another slot (QnetNavTool::updateEditPoint which needs the point Id. More...

Private Member Functions
void	createActions ()

void	createMenus ()

void	drawAllMeasurements (MdiCubeViewport vp, QPainter painter)
	Draw all measurments which are on this viewPort. More...

Private Attributes
QPointer< MainWindow >	m_ipceTool

Directory *	m_directory

CubeDnView *	m_view

QPointer< ControlNet >	m_controlNet

QPointer< Workspace >	m_workspace

Detailed Description

Ipce (Qnet) tool operations.

Author: 2016-09-01 Tracie Sucharski

History:

2016-09-30 Tracie Sucharski - Pass in directory to constructor, so that we can query for shapes and other data from the project.

2016-10-25 Tracie Sucharski - Check for existence of Control net in the paintViewport method.

Definition at line 44 of file IpceTool.h.

Member Typedef Documentation

typedef QVector< MdiCubeViewport * > Isis::Tool::CubeViewportList

protectedinherited

A list of cubeviewports.

Definition at line 219 of file Tool.h.

Constructor & Destructor Documentation

Isis::IpceTool::IpceTool	(	Directory *	directory,
		QWidget *	parent
	)

Ipce (Qnet) tool - Handles mouse button actions and drawing control points on viewports.

Parameters

parent Pointer to the parent widget for the Ipce tool

Author: 2016-09-01 Tracie Sucharski

Definition at line 44 of file IpceTool.cpp.

Member Function Documentation

void Isis::Tool::activate ( bool on )

slotinherited

Activates the tool.

Parameters

on

Definition at line 131 of file Tool.cpp.

References Isis::Tool::addViewportConnections(), Isis::Tool::disableToolBar(), Isis::Tool::enableToolBar(), Isis::Tool::m_active, Isis::Tool::m_toolPadAction, and Isis::Tool::removeViewportConnections().

Referenced by Isis::Tool::addTo(), Isis::AdvancedTrackTool::AdvancedTrackTool(), Isis::RubberBandTool::disable(), Isis::RubberBandTool::enable(), Isis::AdvancedTrackTool::eventFilter(), Isis::FileTool::FileTool(), Isis::RubberBandTool::RubberBandTool(), Isis::TrackTool::TrackTool(), Isis::WindowTool::WindowTool(), and Isis::Workspace::Workspace().

virtual void Isis::Tool::addConnections ( MdiCubeViewport * cvp )

inlineprotectedvirtualinherited

Anytime a tool is created, you must add the connections for it.

Parameters

cvp

Reimplemented in Isis::TrackTool, and Isis::WindowTool.

Definition at line 253 of file Tool.h.

Referenced by Isis::Tool::addViewportConnections().

void Isis::Tool::addTo ( ViewportMainWindow * pViewPortMnWin )

inherited

Adds the tool to the application.

Parameters

pViewPortMnWin

Definition at line 78 of file Tool.cpp.

References Isis::ViewportMainWindow::activeToolBar(), Isis::Tool::addToActive(), Isis::Tool::addToPermanent(), Isis::ViewportMainWindow::getMenu(), Isis::Tool::menuName(), Isis::ViewportMainWindow::permanentToolBar(), Isis::ViewportMainWindow::toolPad(), and Isis::ViewportMainWindow::workspace().

Referenced by Isis::WindowTool::addTo(), Isis::SpecialPixelTool::addTo(), Isis::FileTool::addTo(), Isis::EditTool::addTo(), Isis::CubeDnView::CubeDnView(), Isis::ViewportMainWindow::ViewportMainWindow(), and Isis::Workspace::Workspace().

void Isis::Tool::addTo ( ToolPad * toolpad )

inherited

Adds the tool to the toolpad.

Parameters

toolpad

Definition at line 98 of file Tool.cpp.

References Isis::Tool::activate(), Isis::ToolPad::addAction(), Isis::Tool::m_toolPadAction, and Isis::Tool::toolPadAction().

virtual void Isis::Tool::addTo ( QMenu * menu )

inlinevirtualinherited

Parameters

menu

Reimplemented in Isis::FindTool, Isis::FeatureNomenclatureTool, Isis::StretchTool, Isis::QnetFileTool, Isis::AdvancedTrackTool, Isis::ZoomTool, Isis::SpectralPlotTool, Isis::MeasureTool, Isis::FileTool, Isis::SunShadowTool, Isis::HelpTool, Isis::SpecialPixelTool, Isis::BlinkTool, Isis::WindowTool, and Isis::PanTool.

Definition at line 105 of file Tool.h.

void Isis::Tool::addTo ( Workspace * ws )

virtualinherited

Adds the given workspace to the cubeviewport list.

Parameters

ws

Reimplemented in Isis::EditTool, Isis::FileTool, Isis::SpecialPixelTool, and Isis::WindowTool.

Definition at line 45 of file Tool.cpp.

References Isis::Tool::registerTool(), and Isis::Tool::setCubeViewport().

void Isis::Tool::addToActive ( QToolBar * toolbar )

inherited

Parameters

toolbar

Definition at line 112 of file Tool.cpp.

References Isis::Tool::createToolBarWidget(), Isis::Tool::disableToolBar(), and Isis::Tool::m_toolBarWidget.

Referenced by Isis::Tool::addTo(), Isis::CubeDnView::CubeDnView(), and Isis::Workspace::Workspace().

virtual void Isis::Tool::addToPermanent ( QToolBar * toolbar )

inlinevirtualinherited

Parameters

toolbar

Reimplemented in Isis::AdvancedTrackTool, Isis::FileTool, Isis::HelpTool, Isis::SpecialPixelTool, Isis::BlinkTool, and Isis::WindowTool.

Definition at line 111 of file Tool.h.

Referenced by Isis::Tool::addTo(), Isis::CubeDnView::CubeDnView(), and Isis::Workspace::Workspace().

virtual QWidget* Isis::Tool::createToolBarWidget ( QStackedWidget * parent )

inlineprotectedvirtualinherited

Anytime a tool is created, you must add it to the tool bar.

Parameters

parent

Returns: QWidget*

Reimplemented in Isis::StretchTool, Isis::FindTool, Isis::StatisticsTool, Isis::FeatureNomenclatureTool, Isis::EditTool, Isis::ZoomTool, Isis::MeasureTool, Isis::StereoTool, Isis::SpatialPlotTool, Isis::SpectralPlotTool, Isis::AbstractPlotTool, Isis::BandTool, Isis::SunShadowTool, Isis::HistogramTool, Isis::ScatterPlotTool, and Isis::PanTool.

Definition at line 243 of file Tool.h.

Referenced by Isis::Tool::addToActive().

MdiCubeViewport* Isis::Tool::cubeViewport ( ) const

inlineprotectedinherited

Return the current cubeviewport.

Returns: CubeViewport*

Definition at line 211 of file Tool.h.

References Isis::Tool::m_cvp.

Tool::CubeViewportList * Isis::Tool::cubeViewportList ( ) const

protectedinherited

Return the list of cubeviewports.

Returns: CubeViewportList*

Definition at line 390 of file Tool.cpp.

References Isis::Workspace::cubeViewportList().

Referenced by Isis::BlinkTool::advance(), Isis::SpecialPixelTool::apply(), Isis::FindTool::centerLinkedViewports(), Isis::WindowTool::changeCursor(), Isis::FileTool::closeAll(), Isis::BandTool::copyAllViewports(), Isis::BandTool::copyLinkedViewports(), Isis::MatchTool::createPoint(), Isis::BlinkTool::eventFilter(), Isis::FeatureNomenclatureTool::featuresIdentified(), Isis::FeatureNomenclatureTool::findMissingNomenclature(), Isis::FeatureNomenclatureTool::findNomenclatureStateChanged(), Isis::FindTool::handleLinkClicked(), Isis::WindowTool::linkWindows(), Isis::RubberBandTool::mouseButtonRelease(), Isis::RubberBandTool::mouseMove(), Isis::QnetTool::openGround(), paintAllViewports(), Isis::StereoTool::paintAllViewports(), Isis::MatchTool::paintAllViewports(), Isis::QnetTool::paintAllViewports(), Isis::FindTool::refresh(), Isis::ScatterPlotTool::repaintViewports(), Isis::AbstractPlotTool::repaintViewports(), Isis::WindowTool::resizeWindows(), Isis::BlinkTool::reverse(), Isis::ZoomTool::rubberBandComplete(), Isis::MatchTool::serialNumberList(), Isis::FeatureNomenclatureTool::setFontColor(), Isis::FeatureNomenclatureTool::setFontSize(), Isis::FeatureNomenclatureTool::setShowApprovedOnly(), Isis::StretchTool::setStretchAllViewports(), Isis::FeatureNomenclatureTool::setVectorType(), Isis::StretchTool::stretchGlobalAllViewports(), Isis::BlinkTool::toggleLink(), Isis::WindowTool::unlinkWindows(), Isis::MeasureTool::updateMeasure(), Isis::AdvancedTrackTool::updateRow(), Isis::WindowTool::updateTool(), Isis::BlinkTool::updateTool(), Isis::FindTool::updateTool(), Isis::AbstractPlotTool::viewportsToPlot(), Isis::ZoomTool::zoomBy(), Isis::ZoomTool::zoomFit(), Isis::ZoomTool::zoomFitHeight(), Isis::ZoomTool::zoomFitWidth(), and Isis::ZoomTool::zoomManual().

void Isis::IpceTool::drawAllMeasurements	(	MdiCubeViewport *	vp,
		QPainter *	painter
	)

private

Draw all measurments which are on this viewPort.

Parameters

vp	Viewport whose measurements will be drawn
painter

History:

2010-06-03 Jeannie Walldren - Removed "std::" since "using namespace std"

2010-06-08 Jeannie Walldren - Fixed bug that was causing ignored measures not be drawn as yellow unless IpceTool was open

2010-07-01 Jeannie Walldren - Modified to draw points selected in IpceTool last so they lay on top of all other points in the image.

2011-04-15 Tracie Sucharski - Fixed bug which was causing all measures to be drawn on all cubes. Also removed loop through measures, instead just get measure for given serial number.

2011-10-20 Tracie Sucharski - Add check for a control network that does not yet have any control points.

2011-11-09 Tracie Sucharski - If there are no measures for this cube, return.

Definition at line 238 of file IpceTool.cpp.

References Isis::SerialNumber::Compose(), Isis::CubeViewport::cube(), Isis::CubeViewport::cubeToViewport(), Isis::ControlPoint::Free, and Isis::ControlPoint::GetType().

Referenced by paintViewport().

void Isis::Tool::enableRubberBandTool ( )

protectedvirtualinherited

Anytime a tool is created, you may use the rubber band tool.

Enable the use of the rubberband tool.

Reimplemented in Isis::RubberBandTool, Isis::ZoomTool, Isis::MeasureTool, Isis::StereoTool, Isis::SpatialPlotTool, Isis::SpectralPlotTool, and Isis::HistogramTool.

Definition at line 339 of file Tool.cpp.

References Isis::RubberBandTool::disable().

Referenced by Isis::Tool::addViewportConnections().

virtual QString Isis::Tool::menuName ( ) const

inlinevirtualinherited

Anytime a tool is created, you must give it a name for the menu.

Returns: QString

Reimplemented in Isis::FindTool, Isis::StretchTool, Isis::FeatureNomenclatureTool, Isis::AdvancedTrackTool, Isis::FileTool, Isis::ZoomTool, Isis::MeasureTool, Isis::BandTool, Isis::HelpTool, Isis::SpecialPixelTool, Isis::BlinkTool, Isis::WindowTool, and Isis::PanTool.

Definition at line 97 of file Tool.h.

Referenced by Isis::Tool::addTo(), Isis::CubeDnView::CubeDnView(), and Isis::Workspace::Workspace().

void Isis::Tool::mouseButtonPress	(	QPoint	p,
		Qt::MouseButton	s
	)

protectedvirtualslotinherited

Parameters

p
s

Definition at line 367 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::IpceTool::mouseButtonRelease	(	QPoint	p,
		Qt::MouseButton	s
	)

protectedslot

Handle mouse events on CubeViewport.

Parameters

p[in]	(QPoint) Point under cursor in cubeviewport
s[in]	(Qt::MouseButton) Which mouse button was pressed

Author: 2016-09-01 Tracie Sucharski

Definition at line 89 of file IpceTool.cpp.

References Isis::SerialNumber::Compose(), Isis::CubeViewport::cube(), Isis::Tool::cubeViewport(), Isis::Cube::fileName(), Isis::UniversalGroundMap::SetImage(), Isis::CubeViewport::universalGroundMap(), Isis::UniversalGroundMap::UniversalLatitude(), Isis::UniversalGroundMap::UniversalLongitude(), and Isis::CubeViewport::viewportToCube().

void Isis::Tool::mouseDoubleClick ( QPoint p )

protectedvirtualslotinherited

Parameters

p

Definition at line 358 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::Tool::mouseMove ( QPoint p )

protectedvirtualslotinherited

Parameters

p

Definition at line 352 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::IpceTool::paintAllViewports ( QString pointId )

privateslot

This method will repaint the given Point ID in each viewport Note: The pointId parameter is here even though it's not used because the signal (IpceTool::editPointChanged connected to this slot is also connected to another slot (QnetNavTool::updateEditPoint which needs the point Id.

TODO: Clean this up, use 2 different signals?

Parameters

pointId
