Isis 3 Programmer Reference
|
NoNormalization - perform simple correction without normalization (a*dn +b) More...
#include <NoNormalization.h>
Public Member Functions | |
NoNormalization (Pvl &pvl, PhotoModel &pmodel) | |
std::string | AlgorithmName () const |
Return normalization algorithm name. | |
void | CalcNrmAlbedo (double pha, double inc, double ema, double dn, double &albedo, double &mult, double &base) |
Calculate the albedo normalization. | |
void | CalcNrmAlbedo (double pha, double inc, double ema, double deminc, double demema, double dn, double &albedo, double &mult, double &base) |
Calculate the normalization albedo using photometric angle information. | |
virtual void | SetNormWavelength (double wavelength) |
Set the wavelength parameter. | |
Protected Member Functions | |
virtual void | NormModelAlgorithm (double pha, double inc, double ema, double dn, double &albedo, double &mult, double &base) |
virtual void | NormModelAlgorithm (double pha, double inc, double ema, double deminc, double demema, double dn, double &albedo, double &mult, double &base) |
void | SetAlgorithmName (std::string name) |
PhotoModel * | GetPhotoModel () |
AtmosModel * | GetAtmosModel () |
Protected Attributes | |
double | p_normWavelength |
Private Attributes | |
std::string | p_normAlgorithmName |
PhotoModel * | p_normPM |
AtmosModel * | p_normAM |
NoNormalization - perform simple correction without normalization (a*dn +b)
2008-03-17 Janet Barrett - Original version
2008-06-18 Steven Koechle - Fixed Documentation Errors
2010-05-18 Janet Barrett - Modified class so that it does nothing to the incoming dn value. The outgoing albedo value will be the same as the incoming dn value.
2010-11-30 Janet Barrett - Added ability to use photometric angles from the ellipsoid or the DEM
2011-01-28 Janet Barrett - Fixed NormModelAlgorithm so that it applies the photometric correction to the incoming dn value
Definition at line 32 of file NoNormalization.h.
Isis::NoNormalization::NoNormalization | ( | Pvl & | pvl, |
PhotoModel & | pmodel ) |
Definition at line 13 of file NoNormalization.cpp.
|
inlinevirtual |
Definition at line 35 of file NoNormalization.h.
|
inlineinherited |
Return normalization algorithm name.
Definition at line 43 of file NormModel.h.
|
inherited |
Calculate the normalization albedo using photometric angle information.
pha | input phase angle |
inc | input incidence angle for ellipsoid |
ema | input emission angle for ellipsoid |
deminc | input incidence angle for dem |
demema | input emission angle for dem |
dn | input albedo value |
Definition at line 89 of file NormModel.cpp.
|
inherited |
Calculate the albedo normalization.
Calculate the normalization albedo using photometric angle information.
pha | input phase angle |
inc | input incidence angle |
ema | input emission angle |
dn | input albedo value |
Definition at line 64 of file NormModel.cpp.
|
inlineprotectedinherited |
Definition at line 69 of file NormModel.h.
|
inlineprotectedinherited |
Definition at line 66 of file NormModel.h.
|
protectedvirtual |
Implements Isis::NormModel.
Definition at line 17 of file NoNormalization.cpp.
|
inlineprotectedvirtual |
Implements Isis::NormModel.
Definition at line 38 of file NoNormalization.h.
|
inlineprotectedinherited |
Definition at line 63 of file NormModel.h.
|
virtualinherited |
Set the wavelength parameter.
This value is obtained from the BandBin Center keyword of the image. This must be set by the application.
Definition at line 51 of file NormModel.cpp.
|
privateinherited |
Definition at line 76 of file NormModel.h.
|
privateinherited |
Definition at line 78 of file NormModel.h.
|
privateinherited |
Definition at line 77 of file NormModel.h.
|
protectedinherited |
Definition at line 73 of file NormModel.h.
